- Page 1 ENJOY SMART LIFE Installation Manual Model:G20PRO/G27PRO Thank you for choosing our products. Please read the instructions carefully before installation and keep it available for future maintenance or reference. E-mail:service@eplo.com...
-
Page 2: Table Of Contents
Content Safety instructions Technical specification List of materials Technical drawing Parts identification Toilet installation Preparation Lid auto open/close Maintenance 1. Main unit care and maintenance 2. Spray nozzle maintenance and care 3. Filter maintenance Emergency troubleshooting 1. Power and water failure 2. - Page 3 IMPORTANT SAFEGUARDS When using electrical products, especially when children are present, basic safety precautions should always be followed, including the following: 1. The appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.
-
Page 4: Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS CAUTION – Indicates that failure to follow the instruction may cause body injury or property damage. 1. Do not install or use the product in wet places as steam room etc. 2. It is recommended to use water-proof electrical outlet which should be lnstalled in the place where is not easily got wet. -
Page 5: Technical Specification
Technical specification Rated voltage 120V, 60Hz Rated power 1120W Main Unit Water proof IPX4 Water pressure 0.08MPa - 0.8MPa range Power cord length About 2.2m Flush volume 1.6/1.1Gpf, 6.0L(full flush)/4.1L(half flush) Flushing mode Siphonic jet Toilet Rough-in 305mm Outlet outside ≤100mm diameter Drainage method... - Page 6 Surface 6-level adjustment temperature Heating power Heated seat After 10 minutes of use, the seat temperature will Burn protection automatically drop slowly to a low level Seat sensor, Temperature sensor, Bimetallic thermostat, Safety device Thermal fuse, Leakage protection plug Night light Intelligent, Always on, Always off assembly User ID setting...
-
Page 7: List Of Materials
List of materials Main Unit Remote Control Components Installation Manual Thank you for choosing our products.Please read the instructions carefully before installation and keep it available for future maintenance or reference. Installation Manual Installation Cardboard Sealing Flange Hose(Installed) NPT 1/2 Angle Valve Mounting accessory kit... -
Page 8: Technical Drawing
Technical drawing 700mm 1. The drawing is for reference only, and we reserve the right to modify the product appearance. 2. Product appearance is subject to change in kind. -
Page 9: Parts Identification
Parts identification Bumper Left side Knob Seat Front washing Rear washing button button Ceramic toilet Dryer shield Rear washing Front washing Power cord Spray Manual flushing nozzle button Deodorizer Right side Remote control sensor Touch the sensing area with foot... -
Page 10: Toilet Installation
Toilet installation 1. Installation of angle valve 3. Connect hose to toilet water inlet Draw drain outlet centerline on the floor. Connect one end of hose to the water inlet Install angle valve at proper position on of the toilet and tighten the connection. the the wall according to dimension of toilet. - Page 11 5. Ceramic toilet installtion 7. Connect hose to angle valve Install a sealing flange into drain outlet. Connect the other end of hose to angle valve and tighten the connection. Install ceramic toilet on the corresponding position. Toilet drain outlet Sealing flange 8.
-
Page 12: Preparation
Preparation 1. Turn on the angle valve Check the threaded connection for leaks to ensure complete sealing. Turn the angle valve counterclockwise to the full open position. (Note: The angle valve opens with a large torque for the first time.) Angle valve 2. -
Page 13: Lid Auto Open/Close
Lid auto open/close 1. Only for the product with auto lid opening/closing function. Approaching the toilet 1. When user enters the sensing range, the power and energy-saving indicators light up and then the seat lid opens automatically. Leaving the toilet The seat lid closes automatically 180 seconds after user leaves. -
Page 14: Maintenance
Maintenance Main unit care and maintenance Spray nozzle maintenance and care 1. Shut off power supply before doing 1. Nozzle self-cleaning maintenance. When no one is seated, turn the knob clockwise. The nozzle will automatically 2. Use only a soft, damp cloth to clean. stretch out to allow access for cleaning. -
Page 15: Filter Maintenance
Emergency troubleshooting Filter maintenance Power and water failure If poor spray perfomance occurs under 1. No power normal conditions: Press and hold the manual flushing button for 4 seconds to flush 1. Unscrew angle valve nut Manual flushing button 2. No water supply 2. -
Page 16: Failure Of Remote Control
Failure of remote control Product unused for a period of time 1. Operate via buttons on the main unit When the product is left unused for a long time, especially in cold weather, it is highly recommended to drain the water to prevent freezing. -
Page 17: Description Of The Knob Function
Description of the knob function 1. When seated, turn the knob clockwise to start rear washing function, and turn counterclockwise to start front washing function. Rear and front washing function will automatically enter into the drying function after completion. ( Note: default water pressure, water temperature, air temperature, seat temperature, wand position are intermediate. -
Page 18: Troubleshooting Guide
Troubleshooting guide Problem Cause Solution Straighten the hose to remove Water supply hose is kinked the kink No water from Turn on the angle valve Angle valve is off nozzle A water failure occurred Restore the water supply Straighten the hose to remove Water supply hose is kinked the kink Poor water... - Page 19 The picture of product may not be entirely consistent with actual appearance and color because of product improvements, please in kind prevail. ASVFAF0401011A-1.0...
