  • Page 1 100 Series Instruction manual...

  • Page 3: Table Of Contents

    Overview of the displays of the EM 100 receiver ........................6 Overview of the SK 100 bodypack transmitter ......................... 7 Overview of the displays of the SK 100 bodypack transmitter ....................8 Overview of the SKM 100 radio microphone ..........................9 Overview of the displays of the SKM 100 radio microphone ....................

  • Page 4: Important Safety Instructions

    • WARNING: To reduce the risk of fire or electric shock, do not use the devices and the mains unit near water and do not expose them to rain or moisture.

  • Page 5: Bodypack Transmitter And Radio Microphone

    – You can hear ringing or whistling sounds in your ears. – You have the impression (even for a short time only) that you can no longer hear high notes. Bodypack transmitter and radio microphone Do not place the devices near any heat sources such as radiators, heat registers, stoves, or other devices (including amplifiers) that produce heat.

  • Page 6: The Ew 100 G3 Evolution Wireless Series

    Channel 2 – freely selectable frequency Frequency bank U Channel 12 – freely selectable frequency Each of the channels in the frequency banks “1” to “20” has been factory-preset to a fixed frequency (frequency preset). The factory-preset frequencies within one frequency bank are intermodulation-free. These frequencies cannot be changed.

  • Page 7: Product Overview

    ´ UP/DOWN button µ Audio output (AF OUT UNBAL), ² STANDBY button, ¼” (6.3 mm) jack socket, serves as the ESC (cancel) key in the unbalanced operating menu ¸ Service interface (DATA) ¹ Service interface (DATA) Antenna input I (ANT...

  • Page 8: Overview Of The Displays Of The Em 100 Receiver

    Overview of the displays of the EM 100 receiver After switch-on, the receiver displays the standard display “Receiver Parameters”. For further illustrations and examples of the different standard displays, please refer to 24. This stan- dard display displays the operating states of the receiver. PEAK 1. 1 EW100 G3 543.200...

  • Page 9: Overview Of The Sk 100 Bodypack Transmitter

    Product overview Overview of the SK 100 bodypack transmitter » ³ · ¿ ² ´ ² ¹ ¶ º ¸ ¾ µ ¸ Operating elements ³ ¶ SET Microphone/instrument input (MIC/LINE), button 3.5 mm jack socket, lockable º rocker button (UP/DOWN) ·...

  • Page 10: Overview Of The Displays Of The Sk 100 Bodypack Transmitter

    Overview of the displays of the SK 100 bodypack transmitter After switch-on, the bodypack transmitter displays the standard display “Frequency/Name”. For further illustrations and examples of the different standard displays, refer to 24. The display backlighting is automatically reduced after approx. 20 seconds.

  • Page 11: Overview Of The Skm 100 Radio Microphone

    Battery compartment (not visible from µ Charging contacts outside) ¸ Multi-function switch: ´ Display panel, backlit in orange (DOWN), (UP) and (SET) ² Infra-red interface ¹ ON/OFF button, ¶ Antenna serves as the ESC (cancel) key in the operating menu...

  • Page 12: Overview Of The Displays Of The Skm 100 Radio Microphone

    Overview of the displays of the SKM 100 radio microphone After switch-on, the radio microphone displays the standard display “Frequency/Name”. For further illustrations and examples of the different standard displays, refer to 24. The display backlighting is automatically reduced after approx. 20 seconds.

  • Page 13: Putting The Devices Into Operation

    Putting the devices into operation EM 100 receiver You can set up the receiver on a flat surface or mount it into a 19“ rack. For informa- tion on rack mounting, refer to the instruction manual of the EM 100 receiver avail- able on the ew G3 product page at www.sennheiser.com.
  • Page 14 – You can connect the rod antennas to the rear of the receiver. – You can use the optional AM 2 antenna front mount kit and mount the rod antennas to the front of the receiver (see the instruction manual of the EM 100 receiver avail- able on the ew G3 product page at www.sennheiser.com).

  • Page 15: Sk 100 Bodypack Transmitter

    ¶ º SK 100 bodypack transmitter Inserting the batteries/accupack For powering the bodypack transmitter, you can either use two 1.5 V AA size batteries or the rechargeable Sennheiser BA 2015 accupack. ¸ Push the two catches in the direction of the arrows and open the battery compart- ment cover µ.
  • Page 16 It is therefore not necessary to position it precisely. Attach the ME 2 microphone as close as possible to the sound source. The ME 4 clip-on microphone (shown on the left in the diagram) has a cardioid pick-up pattern.

  • Page 17: Skm 100 Radio Microphone

    To detach the belt clip: Lift one side of the belt clip as shown in the diagram on the right-hand side. Press down the belt clip at one fixing point and pull it out of the transmitter housing. Repeat for the other side.
  • Page 18 To charge the radio microphone with the inserted BA 2015 accupack (optional accessory): Use the LA 2 charging adapter to insert the radio microphone into the L 2015 charger (both the charger and the charging adapter are available as optional accessories).

  • Page 19: Using The Devices

    The transmission link is established and the receiver’s RF level display “RF” reacts. If you cannot establish a transmission link between transmitter and receiver: Make sure that transmitter and receiver are set to the same frequency bank and to the same channel.
  • Page 20 Using the devices completely switch the receiver off: Disconnect the receiver from the mains by unplugging the mains unit from the wall socket. SK 100 bodypack transmitter ¿ ¸ ¸ µ To switch the bodypack transmitter (online operation): ¸ and open the battery compartment cover µ.
  • Page 21 Using the devices 543.200 ew100 G3 MUTE Use this function to save battery power or to prepare a bodypack transmitter for use during live operation without causing interference to existing transmission links. activate signal: Briefly press the ON/OFF button ON/OFF “RF Mute...

  • Page 22: Synchronizing A Transmitter With The Receiver

    “Sync” appears on the display panel of the receiver. Place the infra-red interface of the transmitter (see page 7 and 9) in front of the infra- red interface of the receiver ·. The parameters are transferred to the transmitter. When the transfer is completed, “ ”...

  • Page 23: Deactivating The Lock Mode Temporarily

    You can activate or deactivate the automatic lock mode via the “Auto Lock” menu item (see page 25). If the lock mode is activated, you have to temporarily deactivate it In order to be able to operate the devices: EM 100...

  • Page 24: Muting The Audio Signal Or Deactivating The Rf Signal

    G3 MUTE · MUTE switch allows you to mute the audio signal or to deactivate the RF signal. Via the switch ·: “Mute Mode” menu item, you can set the desired function of the MUTE Slide the MUTE switch · ...
  • Page 25 Using the devices The current state of the muting function or the RF signal is displayed on the display panel of the bodypack transmitter. Audio signal is muted Transmitter’s display panel: “MUTE” is displayed Audio signal is activated (muting is canceled) Transmitter’s display panel:...

  • Page 26: Selecting A Standard Display

    (see page 26). Information on the soundcheck function and the guitar tuner function can be found in the instruction manual of the EM 100 receiver available on the ew G3 product page at www.sennheiser.com.

  • Page 27: Overview Of The Operating Menus

    Pilot Tone LCD Contrast Reset Software Revision Exit When one of the standard displays is shown on the display panel, you can get into the main button ¿. The extended menu menu by pressing the “Advanced Menu” and the submenu “Easy...
  • Page 28 Enters a freely selectable name AF Out Adjusts the audio output level Adjustment range: -24 dB to +24 dB, adjustable in 3-dB steps, 6 dB gain reserve Special function “gain reserve”: When you have adjusted a level of +18 dB, press the ´...

  • Page 29: Cleaning The Devices

    Keep all liquids away from the devices. EM 100 Before cleaning, disconnect the device from the mains. Use a slightly damp cloth to clean the receiver from time to time. Do not use any solvents or cleansing agents. SK 100 Use a slightly damp cloth to clean the bodypack transmitter from time to time.
  • Page 30 Remove the foam insert. There are two ways to clean the sound inlet basket: – Use a slightly damp cloth to clean the upper sound inlet basket from the inside and outside – or scrub with a brush and rinse with clear water.
  • Page 31 RF signal available, Transmitter is muted (“MUTE”) Cancels the muting (see page 22). no audio signal, Switch the pilot tone transmission on the trans- “MUTE” appears on the transmitter doesn’t transmit a pilot tone mitter on (see page 27). display panel Switch the pilot tone evaluation on the receiver off (see page 26).
  • Page 32 If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at...

  • Page 33: Specifications

    65 dB Intermodulation attenuation typ. 65 dB Blocking 70 dB Squelch Off, Low: 5 dB V, Middle: 15 dB V, High: 25 dB V Pilot tone squelch can be switched off Antenna inputs 2 BNC sockets AF characteristics Compander system...
  • Page 34 USA: 47 CFR 15 subpart B Canada: ICES 003 Certified by cCSAus KL, 60065, CSA. For accessories and information on connector assignment, visit the ew G3 product page at www.sennheiser.com. SK 100 and SKM 100 RF characteristics Modulation wideband FM Frequency ranges 516–558, 566–608, 626–668, 734–776,...
  • Page 35 40 k unbalanced/1 M Input capacitance (SK) switchable Adjustment range of input sensitivity SK: 60 dB, adjustable in steps of 3 dB SKM: 48 dB, adjustable in steps of 6 dB Overall device Temperature range –10 °C to +55 °C Power supply 2 AA size batteries, 1.5 V...
  • Page 36 Max. SPL 154 dB SPL 154 dB SPL 152 dB SPL Polar diagrams and frequency response curves of the microphone heads (SKM 100) Polar diagram MMD 835-1 Frequency response curve MMD 835-1 0° 30° 30° 60° 60°...

  • Page 37: Manufacturer Declarations

    90° Manufacturer Declarations Warranty Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our web site at www.sennheiser.com or contact your Sennheiser partner. In compliance with the following requirements •...
  • Page 38 •...
  • Page 40 Sennheiser electronic GmbH & Co. KG Printed in Germany Am Labor 1, 30900 Wedemark, Germany Publ. 01/09 www.sennheiser.com 529659/A01...
