- Page 1 100- P Series Bedienungsanleitung Instruction manual Notice d’emploi Istruzioni per l’uso Instrucciones de uso Gebruiksaanwijzing Manual de instruções...
-
Page 2: Table Of Contents
Synchronizing transmitters with diversity receivers ........................26 Cleaning the devices ..................................... 28 If a problem occurs ....................................29 Specifications ......................................31 Manufacturer Declarations ................................. 34 Detailed instruction manuals for the individual products can be found on the corresponding product pages at www.sennheiser.com. -
Page 3: Important Safety Instructions
• WARNING: To reduce the risk of fire or electric shock, do not use the products near water and do not expose them to rain or moisture. -
Page 4: The Ew 100 G3 Evolution Wireless Series
Channel 2 – freely selectable frequency Frequency bank U Channel 12 – freely selectable frequency Each of the channels in the frequency banks “1” to “20” has been factory-preset to a fixed frequency (frequency preset). The factory-preset frequencies within one frequency bank are intermodulation-free. -
Page 5: Product Overviews
Product overviews Product overviews Overview of the EK 100 G3 diversity receiver » Operating elements button 3.5 mm jack socket, lockable OUT) (the shielding is used by antenna II) rocker button (UP/DOWN) Antenna I Battery compartment Operation and battery status indicator,... -
Page 6: Overview Of The Sk 100 G3 Bodypack Transmitter
Product overviews Overview of the SK 100 G3 bodypack transmitter » Operating elements button Microphone/instrument input (MIC/LINE), 3.5 mm jack socket, lockable rocker button (UP/DOWN) MUTE switch Battery compartment Antenna Battery compartment cover Operation and battery status indicator, Battery compartment catches... -
Page 7: Overview Of The Skm 100 G3 Radio Microphone
Product overviews Overview of the SKM 100 G3 radio microphone » Operating elements Color-coded protection ring; Microphone head (interchangeable) available in different colors Name and pick-up pattern of the Operation and battery status indicator, microphone head (not visible here) red LED... -
Page 8: Overview Of The Skp 100 G3 Plug-On Transmitter
Product overviews Overview of the SKP 100 G3 plug-on transmitter » Operating elements Operation and battery status indicator, Microphone input, XLR-3 socket red LED (female, unbalanced) (lit = ON/flashing = BATTERY) Mechanical locking ring of ON/OFF button XLR-3 socket (serves as the ESC (cancel) key in the... -
Page 9: Overview Of The Displays Of The Ek 100 G3
Overview of the displays of the EK 100 G3 After switch-on, the diversity receiver displays the standard display “Frequency/Name”. For further illustrations and examples of the different standard displays, refer to page 22. The display backlighting is automatically reduced after approx. 20 seconds. -
Page 10: Overview Of The Displays Of The Sk 100/Skm 100/Skp 100 G3
Overview of the displays of the SK 100/SKM 100/SKP 100 G3 After switch-on, the transmitter displays the standard display “Frequency/Name”. For further illustrations and examples of the different standard displays, refer to page 22. The display backlighting is automatically reduced after approx. 20 seconds. -
Page 11: Putting The Devices Into Operation
Putting the devices into operation EK 100 G3 diversity receiver Inserting the batteries/accupack For powering the diversity receiver, you can either use two 1.5 V AA size batteries or the rechargeable Sennheiser BA 2015 accupack. Open the battery compartment by pushing the two catches... - Page 12 Reinsert the belt clip Use one of the supplied line cables to connect the line input of the camera to the socket The shield of the line cable serves as the antenna for the second diversity section.
-
Page 13: Sk 100 G3 Bodypack Transmitter
It is therefore not necessary to position it precisely. Attach the ME 2 microphone as close as possible to the sound source. The ME 4 clip-on microphone (shown on the left in the diagram) has a cardioid pick-up pattern. -
Page 14: Skm 100 G3 Radio Microphone
To detach the belt clip: Lift one side of the belt clip as shown in the diagram on the right-hand side. Press down the belt clip at one fixing point and pull it out of the transmitter housing. Repeat for the other side. - Page 15 Charging the accupack To charge the radio microphone with the BA 2015 accupack (optional accessory) installed: Use the LA 2 charging adapter to insert the radio microphone into the L 2015 charger (charger and charging adapter are available as optional accessories).
-
Page 16: Skp 100 G3 Plug-On Transmitter
Put on a new protection ring as shown in the right-hand diagram. SKP 100 G3 plug-on transmitter Inserting the batteries/accupack For powering the plug-on transmitter, you can either use two 1.5 V AA size batteries or the rechargeable Sennheiser BA 2015 accupack. Slide the battery compartment cover in the direction of the embossed arrow and open the cover. -
Page 17: Using The Devices
If you cannot establish a transmission link between transmitter and diversity receiver: Make sure that transmitter and diversity receiver are set to the same frequency bank and to the same channel. If necessary, read the chapter “If a problem occurs ...” on page 29. -
Page 18: Switching The Devices On/Off
» Press the ON/OFF button The red lights up and the standard display “Frequency/Name” appears on the display panel. To switch the diversity receiver off: Press the ON/OFF button until “OFF” appears on the display panel. - Page 19 The trans- mission icon displayed. You can switch your transmitter on and deactivate the RF signal on switch-on. For more information, refer to page 19. To switch your transmitter off: If necessary, deactivate the lock mode (see page 20).
-
Page 20: Synchronizing A Transmitter With The Diversity Receiver
G3 ew100 G3 ew100 G3 MUTE MUTE MUTE Use this function to save battery power or to prepare a transmitter for use during live operation without causing interference to existing transmission links. activate signal: Briefly press the ON/OFF Briefly press the... -
Page 21: Deactivating The Lock Mode Temporarily
ON/OFF button on the diversity receiver. “ ” appears on the display panel of the receiver. “ ” also appears if no suitable trans- mitter was found (wrong frequency range/wrong generation). Deactivating the lock mode temporarily You can activate or deactivate the automatic lock mode via the “Auto... -
Page 22: Muting The Audio Signal Or Deactivating The Rf Signal
The lock mode icon flashes prior to the lock mode being activated again. Muting the audio signal or deactivating the RF signal You can deactivate the RF signal of the transmitters (SKM 100 G3, SK 100 G3, SKP 100 G3) on switch-on. For more information, refer to the chapter “Switching the devices on/off”... -
Page 23: Selecting A Standard Display
Using the devices The current state of the muting function or the RF signal is displayed on the display panel of the transmitter: Audio signal is muted Transmitter’s display panel: “MUTE” is displayed Audio signal is activated (muting is canceled) Transmitter’s display panel:... -
Page 24: Overview Of The Operating Menus
B.Ch: 20.12 MUTE Overview of the operating menus For more detailed information on the operating menus, refer to the individual instruction manuals of the devices. These instruction manuals can be down- loaded from the corresponding product pages at www.sennheiser.com. EK 100 G3 Main menu “Menu”... - Page 25 Overview of the operating menus When one of the standard displays is shown on the display panel, you can get into the main menu by pressing the button . The extended menu “Advanced Menu” and the “Easy Setup” menu can be accessed via the corresponding menu items.
- Page 26 Extended menu “Advanced Menu” Tune Sets the transmission frequencies for the frequency bank “U” Sets a channel and a transmission frequency for the frequency bank “U” Select this menu item and call it up by pressing the button (SK, SKP)/the multi-function switch (SKM) until the channel selection appears.
-
Page 27: Synchronizing Transmitters With Diversity Receivers
(“Current List”, see page 24). If you want to set up a multi-channel system, select a frequency bank with a sufficient number of unused channels for all planned transmission links. Synchronize a transmitter with the diversity receiver (see page 19). - Page 28 (“Tune”, see page 24). Synchronize a transmitter with this receiver (see page 19). Manually set the transmitter to the same frequency bank and channel that you set on the receiver. Repeat for the remaining transmitters and receivers as described above.
-
Page 29: Cleaning The Devices
Liquids entering the housing of the devices can cause a short-circuit and damage the electronics. Keep all liquids away from the devices. Use a cloth to clean the devices from time to time. Do not use any solvents or cleansing agents. SKM 100 G3 To clean the radio microphone’s sound inlet basket:... -
Page 30: If A Problem Occurs
(see page 24). panel Transmitter doesn’t transmit a pilot tone Deactivate the pilot tone evaluation (see page 24). Audio signal has a high Transmitter sensitivity is adjusted too Adjust the transmitter sensitivity correctly level of background noise (“Sensitivity”, see page 25). - Page 31 If a problem occurs that is not listed in the above table or if the problem cannot be solved with the proposed solutions, please contact your local Sennheiser partner for assistance. To find a Sennheiser partner in your country, search at...
-
Page 32: Specifications
System Modulation wideband FM Frequency ranges 516–558, 566–608, 626–668, 734–776, 780–822, 823–865 MHz (A to E, G, see page 3) Frequencies 1,680 frequencies, tuneable in steps of 25 kHz 20 frequency banks, each with up to 12 factory-preset channels 1 frequency bank with up to 12 user programmable... - Page 33 Input capacitance SK switchable Adjustment range of input sensitivity SK: 60 dB, adjustable in steps of 3 dB SKM, SKP: 48 dB, adjustable in steps of 6 dB Power supply 2 AA size batteries, 1.5 V or BA 2015 accupack Nominal voltage 2.4 V...
- Page 34 FCC-ID: DMO G3SKMEM FCC-ID: DMOG3SKP limited to 698 MHz limited to 698 MHz limited to 698 MHz For accessories and information on connector assignment, visit the ew G3 product page at www.sennheiser.com. Microphones (SK 100 G3) ME 2 ME 4 Microphone type...
-
Page 35: Manufacturer Declarations
Manufacturer Declarations Manufacturer Declarations Warranty Sennheiser electronic GmbH & Co. KG gives a warranty of 24 months on this product. For the current warranty conditions, please visit our web site at www.sennheiser.com or contact your Sennheiser partner. In compliance with the following requirements •... - Page 36 •...
