ASSEMBLY INSTRUCTIONS
Quadro Loop
L-Shaped Desk
STEP 01
Using Allen Key provided, attach 2 plastic brackets (H) per legs (C & E)
(as per picture above) using M6x20MM (L) Socket head screw. Connect
Loop Legs (D) to Bottom of Quadro Legs (C & E) by using 4 bolts per leg.
Need help!
Call us on
L
1300 527 665
STEP 02
Using Allen Key provided, attach M8x20MM Socket head (K)-
screw socket half way into leg for three legs (C & E)
K
www.jasonl.com.au
3 of 8
