- Page 1 ASSEMBLY INSTRUCTIONS Quadro Square Counter table Radius Corners Sizes: 1100L x 1100W Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation www.jasonl.com.au Need help! 1 of 7 1300 527 665 Call us on...
- Page 2 ASSEMBLY INSTRUCTIONS Quadro Square Counter table Radius Corners COMPONENTS Table top x1 Leg Quadro Square x2 Beam x1 Plastic bracket x4 SCREWS M8x20MM CSK x2 M8x20MM Socket head x2 M6x20MM Socket head x4 M6x30mm Socket head x 4 or M6x30 Wood screws x 4 and washers Allen key x2 Colour of the beam is always black, regardless desk frame colour.
- Page 3 ASSEMBLY INSTRUCTIONS Quadro Square Counter table Radius Corners STEP 02 STEP 01 TOP VIEW Using Allen Key provided, attach 2 plastic brackets per leg (D) (as per Using Allen Key provided, attach M8x20MM Socket head (G)- screw picture above) using M6x20MM (H) Socket head screw. Screw the feets socket half way into leg for both legs (B) (E) to the bottom of each leg (B) www.jasonl.com.au...
- Page 4 ASSEMBLY INSTRUCTIONS Quadro Square Counter table Radius Corners STEP 03 Adjust extendable beam (C) to desired length using markers and secure beam at that length using screws provided 2000 1900 1800 1700 1600 1500 1400 1300 1200 www.jasonl.com.au Need help! 4 of 7 1300 527 665 Call us on...
- Page 5 ASSEMBLY INSTRUCTIONS Quadro Square Counter table Radius Corners TOP VIEW STEP 05 STEP 04 Attach beam (C) to legs (B) using nut insert in legs. See point attached Frame looks like this. Using Allen Key, attach beam (C) with Socket (F) www.jasonl.com.au Need help! 5 of 7...
- Page 6 ASSEMBLY INSTRUCTIONS Quadro Square Counter table Radius Corners STEP 06 STEP 07 Place desktop on top of the frame. Please place the top equally centred at Please tighten (H) M6x30mm screws the same distance from left and right of the leg frame and then please tighten screws using M6x30MM (H) into the underneath of the tops.
- Page 7 ASSEMBLY INSTRUCTIONS Quadro Square Counter table Radius Corners If purchase with wheels: WEELS ASSEMBLY DONE! Replace Feet (E ) on the bottom of each leg (B) with wheels (E ) www.jasonl.com.au Need help! 7 of 7 1300 527 665 Call us on...
