- Page 1 ASSEMBLY INSTRUCTIONS Quadro A Mobile Need help! Counter table Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation Page 1 of 8...
- Page 2 Counter table Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 COMPONENTS Table top x1 Leg Quadro A x2 Upper Beam x1 Lower Beam x1 Plastic bracket x4 Wheels x4 SCREWS M8x20MM CSK x4 M8x20MM Socket head x4...
- Page 3 ASSEMBLY INSTRUCTIONS Quadro A Mobile Need help! Counter table Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 STEP 01 STEP 02 TOP VIEW Using Allen Key provided, attach 2 plastic brackets per leg (D) Using Allen Key provided, attach M8x20MM Socket head (H)- (as per picture above) using M6x20MM (I) Socket head screw.
- Page 4 ASSEMBLY INSTRUCTIONS Quadro A Mobile Need help! Counter table Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 STEP 03 Adjust extendable beam (C) to desired length using markers and secure beam at that length using screws provided...
- Page 5 ASSEMBLY INSTRUCTIONS Quadro A Mobile Need help! Counter table Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 STEP 04 Adjust extendable beams (D) to desired length. Remove plastic inserts Loosen 2 bolts on beam using allen key...
- Page 6 ASSEMBLY INSTRUCTIONS Quadro A Mobile Need help! Counter table Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 STEP 05 TOP VIEW STEP 06 Attach Upper Beam (C) to legs (B) using nut insert in legs. Frame looks like this. Using Allen Key, attach Upper Beam (C) See point attached with Sockets (G).
- Page 7 ASSEMBLY INSTRUCTIONS Quadro A Mobile Need help! Counter table Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 STEP 07 Frame looks like this. Using Allen Key. Tighen Sockets (G) on the Lower Beam Using the allen key, tighten two bolts (D) using Allen Key (J).
- Page 8 ASSEMBLY INSTRUCTIONS Quadro A Mobile Need help! Counter table Call us on 1300 527 665 Sizes: 1200x700, 1400x700, 1600x700, 1800x700 STEP 08 TABLE TOP BOTTOM VIEW nut insert nut insert Place desktop ontop of frame - with cutout at the back of the desk.
