ASSEMBLY INSTRUCTIONS
Quadro Loop
L-Shaped Desk
G
COMPONENTS
A Table top x1
B Table top Return x1
C Legs Quadro x2
D Legs Quadro Loop x3
E Legs Quadro Return x1
*
F Beam x1
G Beam Return x1
H Plastic bracket x6
I Joiner plates x2
SCREWS
J M8x20MM CSK x3
K M8x20MM Socket head x4
L M6x20MM Socket head x6
M M6x30MM Socket head x8
N Join plates Screws
O Allen key x2
Colour of the beam is always black, regardless desk frame colour.
*
