6.As shown in the picture, place the seat bracket
onto the frame.
8.As shown in the picture, slide the left and right
parts of the frame down along the groove of the
slot, and then thread them through the front bar of
the seat cushion cover, close the left and right
frames.
7.As shown in the picture, first unscrew the seat
fixing knob from the bolt, then let the bolt below
the saddle pass through the hole on the main
frame, then tighten the seat fixing knob until the
saddle is secure and doesn't move.
Installation note:
After installing the
sunshade, press the
backside lock buckle
downwards to secure
the sunshade.
9.As shown in the picture, first insert the push
rod into the connecting tube at the rear of the
seat until it locks with a "click" sound, complet-
ing the lock. Hang the bottle holder; then align
and insert the canopy tube into the backrest
tube and lock it; finally, position the basket
properly and secure it with the basket fixing
knob.
