Outsider 194 Manual

Plateau bench wall
Hide thumbs

Advertisement

Table of Contents

MOUNTING
#194 PLATEAU BENCH WALL - MOUNTING GUIDE
PLATEAU BENCH WALL
INSTRUCTIONS
#194
out-sider a/s
info@out-sider.dk
Kigkurren 8A, Islands Brygge
+45 2261 7420
DK-2300 Copenhagen S
www.out-sider.dk
12.08.2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 194 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Outsider 194

Summary of Contents for Outsider 194

  • Page 1 MOUNTING #194 PLATEAU BENCH WALL - MOUNTING GUIDE 12.08.2020 PLATEAU BENCH WALL INSTRUCTIONS #194 out-sider a/s info@out-sider.dk Kigkurren 8A, Islands Brygge +45 2261 7420 DK-2300 Copenhagen S www.out-sider.dk...

  • Page 2: Table Of Contents

    #194 PLATEAU BENCH WALL - MOUNTING GUIDE 12.08.2020 PARTS INCLUDED FOR MOUNTING Plateau Bench Wall • 8 pcs M10 button head allen key screws • 4 pcs M10 cylinder allenkey screws • 4 pcs plastic washers Plateau Sidebord • 2 pcs M10 button head allen key screws TOOLS NEEDED FOR MOUNTING (NOT INCLUDED: •...

  • Page 3: Mounting The Seat Onto The Frame

    #194 PLATEAU BENCH WALL - MOUNTING GUIDE 12.08.2020 MOUNTING THE SEAT ONTO THE FRAME Use the included M10x20 mm allen key screws to mount the seat onto the frame. Fasten the screws with allen key no. 6. Tighten the screws after all of them are fitted.

  • Page 4: Drilling For, And Mounting Of Threaded Rods

    #194 PLATEAU BENCH WALL - MOUNTING GUIDE 12.08.2020 DRILLING FOR, AND MOUNTING OF THREADED RODS PLEASE NOTICE: Threaded rods should Use the frame for Bench Wall as a guide and mark spots for drilling on the wall. We be able to carry a load of 500 kg.

  • Page 5: Mounting Of Backrest On Plateau Bench Wall

    #194 PLATEAU BENCH WALL - MOUNTING GUIDE 12.08.2020 MOUNTING OF BACKREST ON PLATEAU BENCH WALL Use the included M10 cylinder head screws and plastic washers to mount the backrest onto the frame. While one person holds the backrest, tighten the M10 screws through the frame and the plastic washer.

  • Page 6: Fitting Plateau Bench Wall Onto The Wall

    #194 PLATEAU BENCH WALL - MOUNTING GUIDE 12.08.2020 FITTING PLATEAU BENCH ONTO THE WALL Through the frame Use appropriate nuts to tighten the assembled Bench Wall to the threaded rods. The bench can rest on the threaded rods while the nuts are fastened.

  • Page 7: Mounting Of Side-Table On Bench Wall

    #194 PLATEAU BENCH WALL - MOUNTING GUIDE 12.08.2020 PLATEAU SIDE-TABLE #196 MOUNTING OF SIDE-TABLE ON PLATEU BENCH WALL Use two M10x20mm button head screws (allen key no.6), to fasten the side-table underneath the steel fame. Side-table Seat Bench Wall + Side-table...

  • Page 8: Cleaning

    #194 PLATEAU BENCH WALL - MOUNTING GUIDE 12.08.2020 CLEANING Clean the laminate surfaces using hot water and soft sponge or cloth. Do not use abrasive ‘green’ side of sponges. Common household cleaners without abrasives eg. dish detergent or window cleaner may be used.
