- Page 1 MOUNTING #195 PLATEAU SEAT - MOUNTING 01.02.2020 PLATEAU SEAT INSTRUCTIONS #195 out-sider a/s info@out-sider.dk Kigkurren 8A, Islands Brygge +45 2261 7420 DK-2300 Copenhagen S www.out-sider.dk...
- Page 2 #195 PLATEAU SEAT - MOUNTING 01.02.2020 PARTS INCLUDED FOR MOUNTING Seat 900 • 2 pcs M8x100 allen key bolt • 2 pcs M8 nuts • 2 pcs M8 washer Seat 1250 PLATEAU Seat PLATEAU Seat w. table • 4 pcs M8x100 allen key bolts •...
- Page 3 #195 PLATEAU SEAT - MOUNTING 01.02.2020 UNPACKING THE SHIPMENT Cut the safety straps, remove protective material and unbox mounting parts (check list page 02) and surface bracket. Seat 900 Surface brackets are not mounted to Seat when delivered. Seat 1250 and Seat 1800 Please notice, two surface brackets for these models.
- Page 4 #195 PLATEAU SEAT - MOUNTING 01.02.2020 MOUNTING OF SURFACE BRACKET The surface bracket needs to be mounted on a surface before its assembled with Seat. The bracket has four holes made ready for surface mounting. Use your preferred bolts or screws to mount the bracket.
- Page 5 #195 PLATEAU SEAT - MOUNTING 01.02.2020 MOUNTING OF SEAT ON SURFACE BRACKET Use the included M8 x 100mm allen key bolts to fix the sitting surface to the fixated surface bracket. Tighten the bolts and nuts with allen key no 6. and a 17mm spanner tool.
- Page 6 #195 PLATEAU SEAT - MOUNTING 01.02.2020 PLATEAU SIDE-TABLE DISASSEMBLY OF DISC AND DISC-TUBE. Use allen key no 6 to unfasten the M8x100mm and the M8x14mm bolts. Then pull #200 out the disc and disc-tube from the circular slot in the seating surface. Save the bolts, nut and washer for the mounting of Side-table.
- Page 7 #195 PLATEAU SEAT - MOUNTING 01.02.2020 MOUNTING OF SIDE-TABLE ON SEAT Lower Side-table into the circular slot. Rotate Side-table in such a way, that the two holes align with the steel frame. Reuse the bolts, nut and the washer from your previous disassembly of the disc-tube.
- Page 8 #195 PLATEAU SEAT - MOUNTING 01.02.2020 CLEANING Clean the laminate surfaces using hot water and a soft sponge or cloth. Do not use the abrasive ‘green’ side of sponges. Common household cleaners without abrasives eg. dish detergent or window cleaner may be used. out-sider a/s info@out-sider.dk Kigkurren 8A, Islands Brygge...
