  • Page 1 01.03 2016 loop cone plAnter / tAble / bAckrest instruction #169 out-sider a/s info@out-sider.dk Kigkurren 8A, Islands Brygge +45 2261 7420 DK-2300 Copenhagen S www.out-sider.dk...
  • Page 2 #169 loop Cone plAnter / tABle / BACKreSt - mountIng 01.03 2016 index • loop Cone plAnter: pAge 03 • loop Cone tABle: pAge 04-07 • loop Cone BACKreSt: pAge 08-10 out-sider a/s info@out-sider.dk Kigkurren 8A, Islands Brygge +45 2261 7420 DK-2300 Copenhagen S www.out-sider.dk...
  • Page 3 #169 loop Cone plAnter / tABle / BACKreSt - mountIng 01.03 2016 FIlleD WItH WAter or SAnD / plAnter B11 BrACKet For SurFACe mountIng / plAnter Ø55mm Ø1130mm 3 x m10 loop Cone (22 kg) + water up to the filling cap...
  • Page 4 #169 loop Cone plAnter / tABle / BACKreSt - mountIng 01.03 2016 FIlleD WItH WAter or SAnD / tAble B11 BrACKet For SurFACe mountIng / tAble Ø55mm Ø1130mm 3 x m10 loop Cone (22 kg) + water up to the filling cap...
  • Page 5 #169 loop Cone plAnter / tABle / BACKreSt - mountIng 01.03 2016 mountIng tHe tABletop uSIng tHe BrACKetS SupplIeD / tAble mountIng tHe tABletop uSIng tHe BrACKetS SupplIeD / tAble the assembled brackets are mounted into the 3 inserts using the m10 bolts and washers supplied.
  • Page 6 #169 loop Cone plAnter / tABle / BACKreSt - mountIng 01.03 2016 01.02 2016 mountIng tHe tABletop uSIng tHe BrACKetS SupplIeD / tAble ADJuStIng tHe tABletop W. FleXIBle Angle BrACKetS / tAble the 3 angle brackets may be attached in a number of positions to permit horizontal adjustment of the tabletop.
  • Page 7 #169 loop Cone plAnter / tABle / BACKreSt - mountIng 01.03 2016 DISmAntlIng tHe tABletop For mAIntenAnCe / tAble the tabletop can be removed to adjust the height or to clean inside loop Cone. position the tool level with one of the 3 plugs between the tabletop and loop Cone and tilt it to loosen the tabletop.
  • Page 8 #169 loop Cone plAnter / tABle / BACKreSt - mountIng 01.03 2016 ASSemBlY WItH loop uSIng B13 ASSemBlY BrACKet / bAckrest ASSemBlY WItH loop uSIng B13 ASSemBlY BrACKet / bAckrest 3 x m10 3 x m10 loop Cone is placed as shown (large diameter upwards) on a non-damaging layer (e.g.
  • Page 9 #169 loop Cone plAnter / tABle / BACKreSt - mountIng 01.03 2016 ASSemBlY WItH loop uSIng B13 ASSemBlY BrACKet / bAckrest FIlleD WItH WAter or SAnD / bAckrest the assembly (loop Cone + loop) is elevated, turned and placed on ground with the brackets facing downwards.
  • Page 10: Cleaning Instructions

    #169 loop Cone plAnter / tABle / BACKreSt - mountIng 01.03 2016 CleAnIng InStruCtIonS the material polyethylene withstands almost all detergents. polyethylene requires no maintenance. the dyed polyethylene preserves the colour - minimal fading by the sun is to be expected.
