- Page 1 PLATEAU CITY CHAIR #202 MOUNTING GUIDE Kigkurren 8A Islands Brygge DK-2300 Copenhagen · out-sider.dk...
- Page 2 PLATEAU CITY CHAIR Developed by out-sider in collaboration with Holscher Design 2021. 1x Chair INDEX: PAGE Item list ..................02 Fixation of armrest and side table..........03 Surface mounting...............04 Cleaning and maintenance .............05 ITEM LIST ADD-ONS Add-ons are not included with standard chair Plateau City Chair •...
- Page 3 Arched cutout For angle adjustment Plastic spacer 202 + 2x armrest 2x M8x12 2x M8x12 2x 202 + side table Step 1: Step 2: ATTENTION: Unscrew the M8 bolts and After placement fasten the M8 bolts. - Only use provided bolts! remove the plastic spacers.
- Page 4 SURFACE MOUNTING OR GLIDER FEET Use 4x bolts for surface mounting (not included). The chair is placed in the desired position on the surface. Prepare the surface for fixation. Entry hole in the chair frame is Ø16 mm and exit hole Ø14. Be aware of surface impurities and bumps before mounting.
- Page 5 CLEANING AND MAINTENANCE Clean the laminate surface with warm water and soft sponge. NEVER use the abrasive “green” side of sponges. Use ordinary universal cleaner. Difficult dirt must be removed with nanosponge and water. Take a closer look at our website, or contact us for information. Kigkurren 8A Islands Brygge DK-2300 Copenhagen...
