Outsider PLATEAU BENCH 192 Mounting Instructions

Advertisement

MOUNTING
#192+#193 PLATEAU BENCH+PLINTH - MOUNTING
PLATEAU BENCH+PLINTH
INSTRUCTIONS
#192 + #193
out-sider a/s
info@out-sider.dk
Kigkurren 8A, Islands Brygge
+45 2261 7420
DK-2300 Copenhagen S
www.out-sider.dk
31.01.2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLATEAU BENCH 192 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Outsider PLATEAU BENCH 192

  • Page 1 MOUNTING #192+#193 PLATEAU BENCH+PLINTH - MOUNTING 31.01.2020 PLATEAU BENCH+PLINTH INSTRUCTIONS #192 + #193 out-sider a/s info@out-sider.dk Kigkurren 8A, Islands Brygge +45 2261 7420 DK-2300 Copenhagen S www.out-sider.dk...
  • Page 2 #192+#193 PLATEAU BENCH+PLINTH - MOUNTING 31.01.2020 PARTS INCLUDED FOR MOUNTING: Plateau Bench • 4 pcs M8x14 allen key screws • 8 pcs M10x15 allen key screws • 4 pcs plastic washers Plateau Plinth • 6 pcs M8x14 allen key screws •...
  • Page 3 #192+#193 PLATEAU BENCH+PLINTH - MOUNTING 31.01.2020 UNPACKING THE SHIPMENT Cut the safety straps, remove protective material and unbox mounting parts (check list page 02) and legs. Plateau Bench Plateau Plinth Is packed with the laminate Is packed with laminate at at the bottom and the frame the bottom and the legs on at top...
  • Page 4 #192+#193 PLATEAU BENCH+PLINTH - MOUNTING 31.01.2020 MOUNTING THE SEAT ONTO THE FRAME Use the included M10x15mm allen key screws to mount the seat onto the frame/legs. Tighten the screws carefully with allen key no 6. Also, use the included M8x14mm allen key screws when mounting the legs on Plateau Plinth.
  • Page 5 #192+#193 PLATEAU BENCH+PLINTH - MOUNTING 31.01.2020 MOUNTING OF BACKREST ON PLATEAU BENCH Use the included M8x14mm screws and plastic washers to mount the backrest onto the bench frame. While one person is holding the backrest, tighten the M8x14mm screws. This is done through the holes in the frame.
  • Page 6 #192+#193 PLATEAU BENCH+PLINTH - MOUNTING 31.01.2020 PLATEAU SIDE-TABLE #196 Side-table MOUNTING OF SIDE-TABLE ON PLATEAU BENCH & PLINTH Use two M10x15mm screws (allen key no. 6), to fasten the side-table underneath seating surface the steel frame. (underneath) Bench + side-table Plinth + side-table Steel frame 2x M12x15...
  • Page 7 #192+#193 PLATEAU BENCH+PLINTH - MOUNTING 31.01.2020 CLEANING Clean the laminate surfaces using hot water and soft sponge or cloth. Do not use abrasive ‘green’ side of sponges. Common household cleaners without abrasives eg. dish detergent or window cleaner may be used. out-sider a/s info@out-sider.dk Kigkurren 8A, Islands Brygge...
