- Page 1 PLATEAU SEAT #195 #200 MOUNTING GUIDE Kigkurren 8A Islands Brygge DK-2300 Copenhagen · out-sider.dk...
- Page 2 Seat 1800 PLATEAU SEAT • 5 pcs M8x100 allen key screw Developed by out-sider in collaboration with Holscher Design 2019. • 5 pcs M8 nuts • 5 pcs M8 washer Seat 1800 • 1 pcs M8x20 allen key screw INDEX: PAGE Tools (not included) •...
- Page 3 MOUNTING OF SURFACE BRACKET The surface bracket needs to be mounted on a surface before its assembled with Seat. The bracket has four holes made ready for surface mounting. Use your preferred bolts or screws to mount the bracket. Ø11 mm holes 24 cm Seat 1250 and Seat 1800 Make sure the two brackets have the...
- Page 4 MOUNTING OF SEAT ON SURFACE BRACKET Use the included M8 x 100mm allen key bolts to fix the sitting surface to the fixated surface bracket. Tighten the bolts and nuts with allen key no 6. and a 17mm spanner tool. M8x100 bolt Seat 900 Washer...
- Page 5 FIXATION OF DISC Use one of the included M8 x 100mm unbraco bolts to fix the disc into place. Allen key nr 6. Disc for Seats Washer M8x100 bolt...
- Page 6 PLATEAU SIDE-TABLE #200 MOUNTING OF SIDE-TABLE ON SEAT Lower Side-table into the circular slot. Rotate Side-table in such a way, that the two holes align with the steel frame. Reuse the bolts, nut and the washer from your previous disassembly of the disc-tube. Seat 900, 1250, 1800 M8x100 bolt Side-table mounted on Seat...
- Page 7 MOUNTING OF LEGS Use M8x100 and M8 nut to fasten the two legs (204 1010). Out-sider does not provide tools and materials for surface mounting through the top flange, but recommends countersunk M8-M10 bolts. M8 nut M8x100 bolt 204 1010 Seat 900, 1250, 1800 Legs (204 1010) mounted on Seat...
- Page 8 CLEANING Clean the laminate surface with warm water and a soft sponge. NEVER use the abrasive “green” side of the sponge. Use an ordinary universal cleaner. Difficult dirt must be removed with a nano sponge and water. Please take a closer look at our website, or contact us for information.
