Safety Instructions; Troubleshooting; Assembly Instruction - Carrera RC RC Power Advent calendar Assembly And Operating Instructions Manual

Warning!
WARNING! This toy contains small parts which can be swallowed and is therefore not
suitable for children under 3 years of age.
WARNING! danger of pinching during operation! Remove all packaging materials and
wire fastenings before handing the toy over to the child. Please retain the packaging
and address for information and in the event of any questions.
Note for adult supervisors: Check if the toy is assembled as instructed. The assembly shall be per-
formed under the supervision of an adult.
WARNING! Not suitable for children under 12 years old!
This symbol, showing refuse bins with a cross through them, denotes that empty
batteries, rechargeable batteries, button cells, rechargeable battery packs, equipment
batteries, disused electrical equipment, etc. should not be disposed of in domestic
refuse, as they are harmful to the environment and health. Do not mix dissimilar bat-
tery types or employ new and used batteries together. Rechargeable batteries are
only to be charged by adults. Empty batteries should be removed from the product. Do not recharge non-
recharge able batteries due to risk of explosion. Rechargeable batteries are to be removed from the toy before
being charged. Batteries are to be inserted with the correct polarity. Supply terminals are not to be short circuited.
Never use damaged batteries. Remove batteries if consumed or if product is to be left unused for a long time.
Always replace the whole set of batteries at one time, taking care not to mix old and new ones, or batteries of
different types.
The appliance is only to be used with the power supply unit provided with the appliance. The use of a different
power supply unit may lead to the permanent dawwmage of the battery and neighbouring parts, as well as
physical injury! WARNING: For the purposes of recharging the battery, only use the detachable supply
unit provided with this toy. Battery chargers used with the toy are to be regularly examined for damage to
the cord, plug, enclosure and other parts, and in the event of such damage, they must not be used until the
damage has been repaired. The toy is only to be connected to Class II equipment bearing the following
symbol.
or
FCC statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Caution: Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
NOTE: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interfer-
ence in a residential installation. This product generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If the product does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures :
• Reorient or relocate the receiving antenna.a
• Increase the separation between the product and receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IC statement
The device contain license-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and Eco-
nomic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions:
1. The device must not cause interference;
2. The device must accept any interference, including interference that may cause undesired operation of the device.

Safety instructions

The Carrera RC vehicle is designed for hobby use only and may only be operated on tracks and in spaces
A
especially intended for this purpose. WARNING! Do not use the Carrera RC vehicle in road traffic.
Do not operate the car beneath overhead high-voltage cables or broadcasting masts or during a storm!
B
Atmospheric disturbances can affect the operation of the vehicle. When there a large temperature
differences between your car's garage and the running track, please wait until the vehicle has had time
to acclimatise. This will help prevent conden sation forming and the possibility of malfunctions resulting.
Never operate the product on grass surfaces. There is the risk of grass hindering the movement of the
C
axles, which can lead to the motor overheating. Do not use the Carrera RC vehicle for transporting
goods, persons or animals.
Never use the Carrera RC vehicle outdoors during rain or snowfall. The car must not be run through
D
water, puddles and snow, and must always be kept stored in a dry place.
Never operate the vehicle near rivers, ponds or lakes, to avoid the risk of the Carrera RC car falling into
E
the water. Avoid running on courses which are laid exclusively with sand.
Do not expose the Carrera RC vehicle to direct sunlight. To avoid the electronics in the car overheating,
F
when temperatures are above 35 ° C, regular short pauses in operation are essential.
Never subject the Carrera car to repeated changes of load – that means continuously reversing it.
G
Always place the car on the floor by hand. Never throw the car on the floor from a standing position.
H
Avoid jumping from jumps or ramps higher than 5 cm (0.16 ft.).
I
Never use strong solvents for cleaning the car.
K
To avoid malfunctions to the control system resulting in uncontrolled operation of the Carrera RC vehicle,
L
check that the controller batteries and the rechargeable batteries in the vehicle have sufficient charge.
The Carrera RC vehicle must be inspected before and after operation, each time it is used, to ensure
M
that it has not become disassembled. Any screws or nuts that may have become loosened during
operation must be tightened.
Contents of package
1 x Complete kit with controller
1
4 x 1.5 V Mignon AA batteries (non-rechargeable)
2 x 1.5 V Micro AAA batteries (non-rechargeable)

Assembly instruction

1. Contents: Screwdriver, Screws: type
the relevant step, otherwise use type
2. Contents: Gearbox with motor
3. Contents: Decorative part
long, type short – Use type screws as instructed in
screws.
4. Contents: Main chassis part with electronics
5. Temporarily attach steering cover.
6. Insert gearbox from 2 and connect to the electronics. Ensure that you do not pinch or trap the cable.
Temporarily attach electronics cover.
7. Remove cover 5. Insert the stub axle and latch in the steering linkage. Re-attach the cover 5.
8. Remove cover 6. Insert the shock absorber bridge. Re-attach the cover 6.
9. Contents: Use enclosed screws to fix the shock absorbers.
10. Contents: Decorative part
11. Contents: Decorative part
12. Attach the rear wheels
13. Contents: Cage for decorative parts
14. Attach driver's seat to the main part of the chassis. Attach the cage above it on the main part. Use type
screws to attach decorative parts 3/10/11 to the cage.
15. Attach protection for gearbox at the rear
16. Attach the front wheels
17. Use type screws to attach decorative part
18. Attach bumper at the front
19. Attach rear spoiler
20. Insert batteries into the vehicle.Ensure the polarity is correct
2
Adjusting the steering (left/right)
21. Attach battery compartment cover to the vehicle
22. Contents: Transmitter battery compartment
23. 3 Insert batteries into the transmitter battery compartment. Ensure the polarity is correct
24. Insert the transmitter battery compartment.
Now you can drive the car
1. Switch the car ON at the ON/OFF switch. The LED on top of the car will flash rhythmically.
4
2. Switch on the controller. The LED on top of the controller will flash rhythmically. After a few seconds,
5
the LEDs on the car and on the controller will light continuously, meaning the bind has been made.
• When changing over to new batteries, an operating pause of at least ten minutes is essential.
• Avoid constant motor operation.
• If the vehicle switches itself off several times in quick succession, the batteries are discharged.
Please insert new batteries.
• Please always store the batteries away from the vehicle.
• Clean the Carrera RC car after use.
Controller functions – Full Function
When the controller is switched on, the red LED lamps at the front of the controller are lit.
6
Gas pedal to the rear: forwards
Gas pedal to the front: braking, or backwards
Turn the steering wheel clockwise: right
Turn the steering wheel anti-clockwise: left

Troubleshooting

The vehicle does not work
• Position the switches on the transmitter and vehicle to "ON".
• Have the batteries been inserted correctly?
• Are the battery contacts bent or dirty?
• Are the batteries discharged or defective?
• Are the vehicle and the transmitter/controller connected properly (see
The vehicle does not work properly; the range is too small!
• Is battery power fading?
• Are any other remote control devices close by which might be transmitting on the same frequency?
• Is interference being caused by metal railings or fences?
• Transmitter or power masts often cause the model vehicle to behave in an uncontrolled manner.
• Are there walkie-talkies/CB radios/wireless networks in the vicinity that might cause interference?
