Connectors on the rear

On the rear of the D-AMPS module (slot 5/6), you can find various connectors.
This section explains what they can be used for.
"
Not all of these signals are available all the time. If you require some of them and
you do not find them operational, please contact Wavetek for a special application
software.
Socket Signal
Bu 103 IF
Bu 104 AF
Bu 105 RS-232
Bu 106 AUX
Pin 1 AnalogInI
Pin 2 AnalogInQ
Pin 3 GND
Pin 4 GND
Pin 5 GND
Pin 6 GND
Pin 7 ITXout
Pin 8 QTXout
Pin 9 GND
Pin 10 GND
Pin 11 GND
Pin 12 GND
QoutM
Pin 13
Pin 14 IoutM
Pin 15 ext Q
Pin 16 ext I
Pin 17 GND
Pin 18 QRX
Pin 19 IRX
Pin 20 GND
Pin 21 Vcc
Pin 22 GND
Pin 23 –15 V
Pin 24 GND
Pin 25 +15 V
Bu 107 SYNC
Bu 108 SYNC
10-54
Dir. Ri Vmax
270 Ω ±14 V
in
±5 V
in 3 kΩ
(approx.)
in/out
±5 V
in 3 kΩ
±5 V
in 3 kΩ
out
out
out
out
2.5 V ±2.5 V
in 5 kΩ
2.5 V ±2.5 V
in 5 kΩ
2.5 V ±2.5 V
out
2.5 V ±2.5 V
out
in TTL TTL
out
Application
External IF signal feed from
Bu 103 on slot 3
Reserved
For external control, see
section "RS-232 interface" in
this option manual
\ Input for external I/Q signal
/ (TX, IF)
\ Analog I/Q TX signals
/ output
\ RX signal, I/Q
/
\ Input from fading simulator
p
/
p
\ Output to fading simulator
p
/ (RX I/Q signals)
p
External synchronization,
negative pulse > 125 ns
External synchronization
Appendix
