Bionet Cardio Q50 Quick Manual

Cardio Q50 / Cardio Q70 Quick Manual
How to start the device
Please check the following Before using the device.
l Operating procedure l
ᆞConnect the power cable to the device and press the 'POWER' switch.
ᆞConnect the leads to the patient in accordance with the preparation steps for measuring
electrocardiogram.
ᆞCheck the setting status for filter, signal size, output speed, channel configuration, rhythm lead, etc., and
set them to the desired value if you want to modify them.
ᆞEnter patient information according to the patient information input method.
ᆞIf the waveform displayed on the LCD screen is abnormal or there is a lot of noise, take measures
according to the 'Measures in case of poor lead connection'.
ᆞIf the waveform displayed on the LCD screen is normal, press the 'AUTO' key to record the patient's ECG.
ᆞPress the 'COPY' key to output the same 10-second data input previously, or to output the signal again
after processing the modified information.
ㆍPress the 'RHYTHM' key to monitor the ECG signal waveform with a printer instead of on the LCD screen.
ㆍPress the 'ESC' key to stop the operation while printing the printer or saving the ECG.
How to read the eIFU
1) https://www.ebionet.com/operation-manuals/
2) After entering the provided password, you can download the eIFU.
Product Configuration
▣ Basic composition and accessories
① Cardio Q50 / Cardio Q70 Main Body (1EA)
② Patient Cable (1EA)
③ Limb Electrodes (1SET)
④ Chest Electrodes (1SET)
⑤ ECG Chart Paper (1EA)
⑥ Power Cable (1EA)
⑦ ECG Gel (1EA)
⑧ ECG Diagnosis Guide (1EA)
⑨ Rechargeable Battery (1EA)
Rev. 1.00
PW: C9Mbh5
▣ Optional items
① Spiro Handle (1EA)
② Spiro Diagnosis Guide (1EA)
③ Nose Clip (1EA)
④ Mouthpiece Adaptor (1EA)
⑤ Handle Dock (1EA)
⑥ Disposable Mouthpiece (100EA)
⑦ PFT Filter (100EA)
⑧ Calibration Syringe [3L] (1EA)
Rev. 1.00 / Dec. 2021
1
