Cardio P1 Quick Manual
How to start the device
Please check the following Before using the device.
l Operating procedure l
• Connect the power cable to the device.
• Run the 'CardioSync' program
• Connect the leads to the patient according to the ECG preparation steps.
• Check the settings of filter, signal size, output speed, channel configuration, rhythm lead, etc. and set
them to the desired values if you want to modify them.
• Enter patient information according to the patient information input method.
• If the waveform displayed on the PC screen is abnormal or there is a lot of noise, take action according to
the 'Correspondence for bad lead wiring'.
• If the waveform displayed on the PC screen is normal, press the AUTO key to record the patient's ECG.
• Press the 'STOP' key while saving ECG to stop the operation.
How to read the eIFU
1)
https://www.ebionet.com/operation-manuals/
2) After entering the provided password, you can download the eIFU.
Product Configuration
▣ Basic composition and accessories
①
Cardio P1 Main Body (1EA)
②
Patient Cable (1EA)
③
Limb Electrodes (1SET)
④
Chest Electrodes (1SET)
⑤
Power (USB Data) Cable (1EA)
⑥
USB Lock Key (1EA)
⑦
ECG Diagnosis Guide (1EA)
Rev. 1.00
Rev. 1.00 / Feb. 2022
PW: C9Mbh5
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bionet Cardio P1
Summary of Contents for Bionet Cardio P1
- Page 1 How to read the eIFU https://www.ebionet.com/operation-manuals/ 2) After entering the provided password, you can download the eIFU. PW: C9Mbh5 Product Configuration ▣ Basic composition and accessories ① Cardio P1 Main Body (1EA) ② Patient Cable (1EA) ③ Limb Electrodes (1SET) ④ Chest Electrodes (1SET) ⑤...
-
Page 2: Body Configuration
Body Configuration ▣Top View ① ② ③ ① Indication Part (LED) : Part showing the power connection status of a product ② Indication Part (LED) : Part that informs the lead connection status ③ Function Switch: Start record (push more than 3 seconds), event marker key ▣Bottom View ⒜... -
Page 3: Control Key
▣Side View ① ① Power (USB Data) Cable Connection Port ▣Rear View ① ① ECG Cable Connection Port Control Key Status Display Auto / Event. 1. Short Press Performed to mark as a marker when abnormalities such as arrhythmias were felt in the ECG diagnostic test 2. -
Page 4: Troubleshooting
Trouble Shooting When the signal is output with a lot of noise In this case, first check whether the AC power filter is set. If it is set and still noisy, connect a ground wire to the system's ground electrode. The grounding should not be used with the AC power grounding. - Page 5 Electrical Internal Noise : 20uV(p-p)max Input Impedance : ≥ 50MΩ Input Voltage Range : ±5mV CMRR : > 105dB DC Offset Voltage : ≥ ±400mV Patient Leakage Current : < 10uA Frequency Response : 0.05~200 with in –3dB Isolated, Defibrillation and ESU Protected Signal Quality Pacemaker Pulse Detection Control...
- Page 6 Toll Free: 1-877-924-6638 / Fax: 1-714-734-1761 / E-mail: support@bionetus.com Website: www.bionetus.com European Sales & Service Representative Bionet Europe GmbH 2Li Bessemerstr. 51, D-12103 Berlin, Germany Tel: +49-30-240-374-52 / E-mail: bionetEU@ebionet.com Website: www.ebionet.com Bionet Co., Ltd Model Name: Cardio P1 Rev. 1.00...
