13 Technical data

Issue EN 2024-03 Geocal / Geocal IR / Geocal XL User Manual
Overview
Product name
Principle
Features
Hardware
Diffractive Optical
Element (DOE)
DOE output
window
Compatible FoV
Dimensions
(L x W x H)
Mounting points
Illumination
(WARNING: Visible or invisible laser radiation!
Light source
Wavelength
Optical power
Laser class
(diode only)
Laser class
(GEOCAL)
Service life
Warm-up time
Software
System
requirements
Functions
GEOCAL / GEOCAL XL / GEOCAL IR
DOE-based, geometric calibration of digital cameras
Creates an evenly distributed grid of light points projected
from infinity
GEOCAL / GEOCAL IR: Ø 77 mm
GEOCAL XL: Ø 155 mm
(Diameter of the camera lens ≤ exit opening )
approx. 30 - 120° (larger angles possible, depending on
the camera. Please contact us for details).
GEOCAL / GEOCAL IR: approx. 575 mm x 144 mm x 170
mm
GEOCAL XL: approx. 850 mm x 244 mm x 270 mm
GEOCAL / GEOCAL IR: 3 x M5 x 0.8 internal thread in
the base plate
GEOCAL XL: 10 x M5 x 0.8 internal thread in the base
plate
Frequency-stabilized laser diode
GEOCAL / GEOCAL XL: 633 nm
GEOCAL IR: 935 nm
5 mW
3B
1M
>20.000h
Not required
PC with Windows 7 operating system (or newer) ,
USB connection
•
Load multiple recordings
•
Show recordings
