- Page 1 LE7 product line (x2, x4, IR) Image Engineering GmbH & Co. KG . Augustinusstraße 9d . 50226 Frechen . Germany T +49 2234 995595 0 . F +49 2234 995595 10 . www.image-engineering.de...
-
Page 2: Table Of Contents
CONTENT I REQUIREMENTS & INSTALLATION………………………………………………………………………...3 1.1 Hardware requirements ….……………………………………………………………………………….3 1.2 Installation……………………………….……………………………………………………………………3 II CONNECT THE HARDWARE………………………………………………………………………………..3 III USING YOUR LE7…………………………………………………………………………………………….4 IV LOW INTENSITY USE…………………………………………………………………………….…..……..4 V CALIBRATION / LED DEGRADATION………………………………………………………..……………4 5.1 iQ-LED spectral calibration…………………………………………………………………………………4 5.2 Spectrometer calibration…………………………………………………………………..………………..5 VI LE7 SPECTROMETER SETTINGS………………………………………………………………..……….5 VII SYSTEM TEMPERATURE, AMBIENT TEMPERATUTRE AND ENVIRONMENT CONDITIONS….5 VIII MINIMUM CAMERA DISTANCE AND POSITIONING…………………………………………….……6... -
Page 3: Irequirements & Installation
Connect the power cord to the power supply on the right side of your LE7. Connect the USB cable from the LE7 to your PC and turn on the LE7, the power switch is placed beside the power supply. The system will install the spectrometer and iQ-LED driver on your PC, this will take a few seconds. -
Page 4: Using Your Le7
5.1 iQ-LED spectral calibration The LEDs of the iQ-LED inside the LE7 are of many different types and wavelengths. Some LEDs will change their intensity level and peak wavelength a bit in the first 500 working hours because of a burn in effect. -
Page 5: Spectrometer Calibration
The internal spectrometer comes fully calibrated. It is recommended to recalibrate the spectrometer once a year, regardless of the operating hours. Therefor a NIST traceable calibrated light source is needed. If a spectrometer calibration is required please contact Image Engineering. LE7 SPECTROMETER SETTINGS... -
Page 6: Minimum Camera Distance And Positioning
The minimum camera distance is depending on the viewing angle of the device under test. So if the camera position is very close to the LE7 and you want to make sure that the distance and position of your camera is correct, follow these steps: 1.
