- Page 1 RETRACTABLE AIR HOSE REEL MODEL NO: HVR15 PART NO: 3122011 INSTALLATION & USER GUIDE ORIGINAL INSTRUCTIONS GC10/23...
-
Page 2: General Safety Rules
INTRODUCTION Thank you for purchasing this CLARKE product. This retractable air hose reel incorporates a spring driven, automatic rewind with locking ratchet mechanism. It can be installed in any location using the integral mounting bracket and can be swivelled to cover a wide range of movement. -
Page 3: Installation
INSTALLATION The hose reel may be mounted to a wall, floor, or ceiling as required. Ensure the mounting hardware and the mounting position is of sufficient strength to support the hose and reel, plus the force required to extend the hose. Choose a suitable mounting position close enough to the air compressor that the two items... -
Page 4: Operation And Use
ADJUSTING THE GUIDE ARM Pull out a metre of hose and allow the reel to lock in position. Remove the four bolts connecting the guide arm to the support post. Rotate the guide arm in 90 increments to the desired position. Replace the four bolts and tighten. -
Page 5: Maintenance
MAINTENANCE WARNING: BEFORE CARRYING OUT ANY MAINTENANCE OR REPAIRS, BE SURE TO TURN OFF THE AIR SUPPLY TO THE HOSE REEL AND VENT ANY PRESSURE IN THE AIR LINE. Periodically, check the hose for wear and damage and for leakage using soapy water. -
Page 6: Component Parts
4. Unscrew the hose clamps that secure the hose to the drum. Disconnect the inlet end of the hose from the air inlet valve. 5. Pull the inlet end hose through the slot in the drum and guide rollers, removing the old hose completely 6. - Page 7 COMPONENT PARTS GUARANTEE This product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt which will be required as proof of purchase. This guarantee is invalid if the product is found to have been abused or tampered with in any way, or not used for the purpose for which it was intended.
