- Page 1 OWNER’S MANUAL SDA300 SIGNATURE STREAMER / DAC AMPLIFIER...
-
Page 2: Safety Instructions
• It is recommended to choose good quality cords to connect this appliance to the other devices. Feel free to take advice from your specialist dealer. YOU WILL FIND ENCLOSED – An SDA300 Signature Streamer – A remote control. Dac Amplifier . -
Page 3: General Information
Distortion at 1 kHz: 0,05% / (10 W) Bandwidth: 5 Hz - 150 kHz Rising time: 1,3 µs Sensibility: 350 mV Signal/Noise ratio: 129 dB Digital/analog converter: BURR-BROWN PCM1792 24 bits/192 kHz Dimensions: 440×365×103mm Weight: 19 Kg Page 3 ATOLL ELECTRONIQUE... - Page 4 You will find the antennas in the bag of the remote control. Make sure that the WIFI and Bluetooth® antennas are correctly installed before any connection and use. Please use the 2 supplied antennas (identical) or an antenna with a male connector. Page 4 ATOLL ELECTRONIQUE...
-
Page 5: Remote Control Functions
38) Input selection keys: Coaxial 1, Coaxial 2, Optical 1, Optical 2. 39) FAVORITE: add (ADD) or remove (REM) from a radio station. 40) CD keys: keys to control CD and Drive Atoll players. 41) IN/PR keys: keys allowing you to control the Atoll integrateds and preamps. Page 5 ATOLL ELECTRONIQUE... -
Page 6: Trigger Link
Left & Right polarity between outputs and terminal inputs of the speakers. Bi-amplification: Your appliance can also be used as a single power amplifier (preamp section BY-PASS, see page 11) and also be used for bi-amplification. See below for details about connecting. SDA300 SIGNATURE Right Speaker Left Speaker... -
Page 7: Getting Started
– Deezer. – Settings. – Amazon Music Connecting an RJ45 cable automatically launched the network link. If this is done correctly ( blinking), your network is correctly configured. The following paragraph is optional in your case. Page 7 ATOLL ELECTRONIQUE... -
Page 8: Network Configuration
This menu allows you to rename the auxiliary inputs, to allow the user to identify their different inputs. It also allows you to check/uncheck the entry of your choice so that it is displayed/hidden in the main menu of the navigation bar. Page 8 ATOLL ELECTRONIQUE... -
Page 9: Power Management
These applications undergo regular updates, their operation and their possibilities are therefore likely to evolve over time. N.B: Note that the old ATOLL Signature application is still available for download. Page 9 ATOLL ELECTRONIQUE... -
Page 10: Internet Radio
Popular podcasts / Trends / Filters. FRONT & REAR USB Select one of those inputs to read all music files from a USB key or Hard Disk. Readable files system can be FAT32, NTFS, EXT 2/3/4. Page 10 ATOLL ELECTRONIQUE... -
Page 11: Media Server
The signal reception quality may depend on the power of the Bluetooth® transmitter on your device and the distance between the two devices. To ensure correct reception without interruption, avoid being more than 5 meters away from your device. Page 11 ATOLL ELECTRONIQUE... -
Page 12: Troubleshooting Table
This device was made to give you complete satisfaction. ATOLL Electronique warranty is two years from the date of purchase of the equipment, date, and stamp of the seller being authentic. We recommend you keep your proof of purchase (invoice) with this coupon properly filled.
