Atoll Electronique AV50 Owner's Manual

C :
ONNECTING
Rear of Amplifier :
1
2
3
1) Ampli in (Right, Center and Left)
2) Ampli out (Right, Center and Left)
3) Right channel Output
4) Center channel Output
5) Left channel Output
6) Power Plug
7) Power Switch
:
FUNCTIONS
Front of Amplifier :
8) Power indicator led
4 5
6 7
8
2
A :
DVISES
- To optimise the performances your amplifier, you should switch it on at least half
an hour before any listening, the time for power stage to reach their ideal working
temperature. Between two utilisation, it's better to use the stand-by position, so
that the power stages remains at their optimal temperatures.
- We advise you to use good wires to link with the other elements (CD player,
Loudspeakers...). Don't hesitate to take advise from your dealer.
- Your Amplifier is equipped with a temporised switch on. A relay protect
loudspeakers on output power stage from over-voltage.
C :
LEANING
Before any cleaning, switch off your amplifier (6). Use a soft and dry rag to clean
up the appliance. Never use acetone, white-spirit, ammoniac, or any kind of product
containing abrasive agent. Never try to clean up inside the appliance.
T S :
ROUBLES AND OLUTIONS
TROUBLES
- The power led (7) do not
switch on;
- There is no sound from one
speaker;
E.C. MARKING :
E.C. marking certified the conformity with low tension directive 73/23/CEE,
directive CEM 89/336/CEE and national transpositions.
PROBABLE CAUSES
- The power switch (6) is on wrong
position ;
- The sector wire is badly plugged;
- Check all connections between the
amplifier and the speaker;
- Check all connections between the
amplifier and the input;
