HD-KL18-0623
Tool Rental Center
MANUAL
KL-18
PRO Walk Behind
Concrete Saw 18"
SKU # 39600HD & 39650HD
Revised Starting Serial # 220310382
Read and understand this Operator's Instruction Manual,
and the Engine Manufacturer's Owner's Manual
before operating this equipment.
Death of serious injury can result if this machine is used improperly.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 39600HD and is the answer not in the manual?

Questions and answers

Summary of Contents for Edco 39600HD

  • Page 1 Tool Rental Center MANUAL KL-18 PRO Walk Behind Concrete Saw 18” SKU # 39600HD & 39650HD Revised Starting Serial # 220310382 Read and understand this Operator’s Instruction Manual, and the Engine Manufacturer’s Owner’s Manual before operating this equipment. Death of serious injury can result if this machine is used improperly.
  • Page 2: Safety Information

    HD-KL18-0623 SAFETY INFORMATION SAFETY MESSAGES ELECTRICAL POWERED EQUIPMENT CONTINUED • Safety Instructions are proceeded by a graphic alert symbol of DANGER, • Do not disconnect power by pulling cord. To disconnect, grasp the WARNING, or CAUTION. plug, not the cord. •...
  • Page 3: Table Of Contents

    HOW TO ORDER REPLACEMENT PARTS FILL IN INFORMATION BELOW To insure product safety and reliability, always use  genuine EDCO replacement parts when making Date of Purchase ______________________________ repairs to the equipment. When calling for parts, specify the MODEL and ...
  • Page 4: Machine Safety Symbol Label Reference

    HD-KL18-0623 MACHINE SAFETY SYMBOL LABEL REFERENCE This symbol means that the guards must remain in place while the engine/motor on the machine is running because death or personal injury may result. (Yellow background with black pictogram and black outline) This symbol means that there are moving parts and if feet/fingers/digits are inserted under any edge of the cutter/grinder/saw cover while the engine/motor on the machine is running that personal injury and loss of foot/fingers/digits may result.
  • Page 5 HD-KL18-0623 MACHINE SAFETY SYMBOL LABEL REFERENCE This symbol means that the Operator’s, owners, instruction and/or manufacturer(s) manuals must be read and understood before operating or attempting to operate this electrical, gasoline, diesel or propane powered equipment, failure to do so can result in personal injury and possible death. (Blue background with white pictogram.) This symbol means that proper eye protection must be worn/used during the operation of this equipment.
  • Page 6: California Proposition 65 Warning

    California. While the exposure from EDCO products may be negligible or well within the “no significant risk” range, out of an abundance of caution, EDCO has elected to provide these Proposition 65 warnings.
  • Page 7: Dust And Crystalline Silica Warning

    HD-KL18-0623 DUST AND CRYSTALLINE SILICA WARNING Grinding/cutting/drilling of masonry, concrete, metal and other materials can generate dust, mists and fumes containing chemicals known to cause serious or fatal injury or illness, such as respiratory disease, cancer, birth defects or other reproductive harm. If you are unfamiliar with the risks associated with the particular process and/or material being cut or the composition of the tool being used, review the material safety data sheets and/or consult your employer, the manufacturers/suppliers, governmental agencies such as OSHA and NIOSH and other sources...
  • Page 8: Safety Guidelines

    HD-KL18-0623 Read and understand this Operator’s Instruction Manual, and the Engine Manufacturer’s Owner’s Manual before operating this equipment. Death of serious injury can result if this machine is used improperly. Safety Guidelines Maintain a safe operating distance from flammable materials. Sparks from the cutting-action of this saw can ignite flam- mable materials or vapors.
  • Page 9: Operating Controls

    HD-KL18-0623 Operating Controls Shown with Kohler Engine as an example. Consult the Engine Manufacturer’s Owner’s Manual for information on specific models. Engine Stop Switch Depth Control Handwheel Knob Lifting Bail Throttle Control Choke Control Recoil Starter Grip Guide Bar Figure 1 Please Note: Controls shown are for the model indicated.
  • Page 10: Operating Instructions

    HD-KL18-0623 Operating Instructions • FOR WET CUTTING: Attach the water supply. A flow rate of approximately 2 gallons per minute (minimum) is required. Attach the water hose to the coolant valve. Use the valve to control the flow of water. •...
  • Page 11 HD-KL18-0623 Operating Instructions • TO STOP THE MACHINE: Stop forward motion. On gasoline models push the throttle to idle. Turn the depth control handwheel knob counter clockwise to raise the blade clear of the cut. Turn ignition or power switch off and let the engine come to a complete stop. Turn off the water supply. •...
  • Page 12: Changing Blades

    Do not use blade without a drive pinhole (Figure 4). For safety reasons, EDCO does not recommend the use of any abrasive blades. Abrasive blades can break and cause serious personal injury to operator and/or bystanders. If abrasive blades are used by choice, use only reinforced abrasive blades.
  • Page 13: Maintenance Instructions

    Do not use a blade without a drive pinhole. • For safety reasons, EDCO does not recommend the use of any abrasive blades. Abrasive blades can break and cause serious personal injury to operator and/or bystanders. If abrasive blades are used by choice, use only reinforced abrasive blades.
  • Page 14: Maintenance Schedule

    HD-KL18-0623 Maintenance Schedule Repairs are to be done Read and follow instructions by authorized EDCO in the Engine Manufacturer’s Dealers only. Owner’s Manual. This is for a quick reference to the information supplied in the Maintenance portion of this manual.
  • Page 15 HD-KL18-0623 THIS PAGE LEFT BLANK INTENTIONALLY Page 15...
  • Page 16: Illustration 1: Main Grouping

    HD-KL18-0623 ILLUSTRATION 1: MAIN GROUPING ILLUSTRATION 1: MAIN GROUPING Page 16...
  • Page 17 HD-KL18-0623 PARTS LISTING - ILLUSTRATION 1: MAIN GROUPING ITEM # PART # DESCRIPTION QTY. 100008HD MAIN FRAME WELDMENT, KL18 10009 WASHER, FLAT 3/4 SAE ZINC 79013 WHEEL, 8 X 2-1/2 X 3/4”BRG.POLY HUB 10306 PIN, COTTER 3/16 X 1-1/2 100005HD FORK WELDMENT, KL18 10009 WASHER, FLAT 3/4 SAE ZINC...
  • Page 18: Illustration 2: Arbor & Blade Guard Grouping

    HD-KL18-0623 ILLUSTRATION 2: ARBOR & BLADE GUARD GROUPING ILLUSTRATION 2: ARBOR & BLADE GUARD GROUPING Page 18...
  • Page 19 HD-KL18-0623 PARTS LISTING - ILLUSTRATION 2: ARBOR & BLADE GUARD GROUPING ITEM # PART # DESCRIPTION QTY. 100213 ARBOR ASSY. COMPLETE, KL-18 (INCLUDES ITEMS 2 THRU 13) 69050 ARBOR SHAFT 19-1/4”L 50222 BEARING, BALL 1” TPB 10960 FITTING, GREASE 1/4-28 X 45° 10808 FITTING, GREASE 1/4-28 STRAIGHT 56308...
  • Page 20: Illustration 3: Engine Grouping

    HD-KL18-0623 ILLUSTRATION 3: ENGINE GROUPING ILLUSTRATION 3: ENGINE GROUPING Page 20...
  • Page 21 HD-KL18-0623 PARTS LISTING - ILLUSTRATION 3: ENGINE GROUPING ITEM # PART # DESCRIPTION QTY. 15029 ENGINE, HONDA GX390UT2QC9 (SHOWN) 15504 ENGINE, KOHLER CH440 (NOT SHOWN) 10625 MUFFLER CAP, HONDA #18331-ZE3-811 10128 RIVET, BLIND 1/8 X .275L X .250HD 56234 OIL DRAIN KIT 100221 LEVER CONTROL ASSY., THROTTLE (HONDA) 101221...
  • Page 22: Illustration 4A & 4B: Optional Water Tank Assembly

    HD-KL18-0623 ILLUSTRATION 4A: ILLUSTRATION 4A: OPTIONAL WATER TANK ASSEMBLY OPTIONAL WATER TANK ASSEMBLY PART #56310 PART #56310 Page 22...
  • Page 23 HD-KL18-0623 ILLUSTRATION 4B: ILLUSTRATION 4B: QUICK-DISCONNECT FITTING QUICK-DISCONNECT FITTING FOR HOSE FROM WATER VALVE FOR HOSE FROM WATER VALVE PARTS LISTING - ILLUSTRATION 4A & 4B: OPTIONAL WATER TANK ASSEMBLY PART #56310 ITEM # PART # DESCRIPTION QTY. 52031 DRUM, PLASTIC 5 GALLON, 3/4NPT CAP 56311HD TRAY, WATER TANK 10412...
  • Page 24: Wiring Diagram For Honda Engine

    HD-KL18-0623 WIRING DIAGRAM FOR HONDA ENGINE WIRING DIAGRAM FOR HONDA ENGINE Page 24...
  • Page 25: Decals

    HD-KL18-0623 DECALS DECALS P/N 91379 P/N 91346 HOME DEPOT Page 25...
  • Page 26 HD-KL18-0623 THIS PAGE LEFT BLANK INTENTIONALLY Page 26...
  • Page 27: Limited Equipment Warranty Of Sale

    *Seller reserves the right to alter payment terms. EDCO will, at its option, repair or replace, at the EDCO factory or at a point designated by EDCO, any part which shall appear to the satisfaction of EDCO inspection to have been 3.
  • Page 28: Stop - Before Using This Product

    EDCO product group. The information in these tracks help businesses be successful with those products. EDCO is always updating online training / information so you always have the most recent content. Also see Operator’s Safety & Limited Warranty Manual...
