If your Ethernet cable feeds through the wall, position the
1
mounting bracket and feed the Ethernet cable. Mark positions
for the screw holes and then drill holes at the marked
positions�
2
Insert the plastic wall anchors into the holes.
Secure the mounting bracket to the wall by driving the self-
3
tapping screws into the anchors. Make sure that the shoulders
of the mounting bracket are on the outside.
4
Connect the Ethernet cable to the Ethernet port on the AP.
Attach the AP to the mounting bracket by aligning the arrow
5
mark on the AP with the arrow mark on the mounting bracket,
then rotate the AP until it is locked into place.
