Place the mounting bracket in the center of the ceiling tile.
2
Mark positions for the screw holes and a position for the
Ethernet cable hole. Drill holes for the screws and a hole for
the Ethernet cable at the marked positions.
3
Secure the mounting bracket to the ceiling tile using pan-head
screws, washers and wing nuts.
4
Feed the Ethernet cable through the hole and set the ceiling
tile back into place.
Connect the Ethernet cable to the Ethernet port. Attach the
5
AP to the mounting bracket by aligning the arrow mark on the
AP with the arrow mark on the mounting bracket, then rotate
the AP until it is locked into place.
■ Option 2: Wall Mounting
Follow the steps below to install the AP with the provided accessories:
Note: The mounting bracket and the accessories (quantity and size) may vary by product.
Plastic Wall Anchors Self-tapping Screws
2
Hole for Ethernet cable
