BA100 & BA100-M SERIES
(P.N. 3026610536, Revision A3, July 2013)
Cooperativa Bilanciai strives to be more environmentally focused and uses recycled materials and
environmentally friendly packaging where possible. As part of this initiative we have developed a short form
manual that uses less paper and ink to describe the main functions of your scale. Thank you for your support
of Cooperativa Bilanciai and we hope that you enjoy your new scale.
81320472 en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BA100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for WorldWEIGH BA100 Series

Summary of Contents for WorldWEIGH BA100 Series

  • Page 1 BA100 & BA100-M SERIES (P.N. 3026610536, Revision A3, July 2013) Cooperativa Bilanciai strives to be more environmentally focused and uses recycled materials and environmentally friendly packaging where possible. As part of this initiative we have developed a short form manual that uses less paper and ink to describe the main functions of your scale. Thank you for your support of Cooperativa Bilanciai and we hope that you enjoy your new scale.

  • Page 3: Table Of Contents

    1.0 CONTENTS 2.0 OPERATION........................ 4 SETTING UP AND TURN ON THE SCALE ............4 ZEROING THE DISPLAY ..................4 TARING ........................ 4 WEIGHING ......................5 PARTS COUNTING ....................5 CHECK COUNTING ....................6 PERCENT WEIGHING ..................7 ACCUMULATED TOTALS ..................8 RS-232 INTERFACE ....................

  • Page 4: Operation

    2.0 OPERATION 2.1 SETTING UP AND TURN ON THE SCALE The BA100, BA100-M series of scales provides a range of accurate, fast and versatile weighing scales with counting, percent weighing and check-weighing functions. For the first time, you should set up your scale as follows: Gently Place the platform in the locating holes on the top cover.

  • Page 5: Weighing

    Preset tare This method allows you to enter a value for the tare weight from the keypad. This is useful if all containers are the same or if the container is already full but the net weight is required and the weight of the container is known.

  • Page 6: Check Counting

    2.6 CHECK COUNTING Check-weighing is a procedure to display an indicator or sound an alarm when the weight on the platform meets or exceeds the values stored in the memory. The memory holds values for a high limit and a low limit. Either or both the limits can be set by the user.

  • Page 7: Percent Weighing

    “rEC” displayed. The display shows . Enter the number corresponding to the desired memory location (0 to 9) “rEC X” will be displayed for 2 seconds indicating the values stored in the location “X” is being to be recalled. recalled. The indicator will change to the recalled limits, weighing units and settings for the beeper and bar graph.

  • Page 8: Accumulated Totals

    2.8 ACCUMULATED TOTALS The scale can be set to accumulate when a weight is added to the platform automatically or manually by pressing [Print]. See menu structure section. The accumulation function is available only during weighing. If at any time the weighing units are changed, the accumulated data will be lost. Manual Accumulation When the scale is set to manual accumulation, the weight displayed will be stored in the memory when the [Print] key is pressed and the weight is stable.

  • Page 9: Rs-232 Interface

    RS-232 INTERFACE The BA100, BA100-M Series of scales can be ordered with a bi-directional RS-232 interface. For use in approved applications, BA100-M scales do not come with the RS-232 interface. However, the scale can be supplied with RS-232 interface if they are not used for the approved applications.The scale when connected to a printer or computer through the RS-232 interface, outputs the weight with the selected weighing unit.

  • Page 10: Parameters

    PARAMETERS Pressing the [Func] key allows the user to access the parameters for customising the scale. The parameters are split into 3 groups- Check weighing parameters, RS-232 parameters and Scale parameters. Please find the RS-232 parameters in complete manual. “FUnC 1” When [Func] is pressed, display will first show for Check weighing parameters.

  • Page 11: Scale Parameters

    SCALE PARAMETERS Shortcut to enter this group is to press and hold the [Count] Key for 4 seconds. The display will go “S1 Un ” directly to . Press [Func] to view the list of parameters. Press [Tare] to enter a parameter. Press [Func] to view the options for the parameter settings.

  • Page 12: Calibration

    CALIBRATION OIML TYPE APPROVAL: A jumper is placed on the PCB to prevent User Calibration and the scale is sealed. If the seal is broken or tampered with, the scale needs to be re-verified by an authorised certification body and re-sealed, before it is used legally. Contact your local metrology standards office for further assistance.

  • Page 13: Specifications

    SPECIFICATIONS BA100 4 BA100 8H BA100 8 BA100 BA100 BA100 48 Kilograms Maximum Capacity 4 kg 8 kg 8 kg 16 kg 32 kg 48 kg Tare Range -4 kg -8 kg -8 kg -9.9995 kg -32 kg -48 kg Readability 0.0001 kg 0.0001 kg...
  • Page 14 OTHER SPECIFICATIONS Units of measure BA100 Series- kg, g BA100a Series- kg, g, lb, oz, lb:oz Interface RS-232 bi-directional Interface Stabilisation Time 2 Seconds typical Operating Temperature -10°C to 40°C 14°F to 104°F Power supply 230 VAC 50/60 Hz 115 VAC available...
  • Page 15 BA100 3M BA100 6M BA100 15M BA100 30M Grams 3000 g 6000 g 15000 g 30000 g 10 g 3000 3000 3000 3000 Kilograms 3 kg 6 kg 15 kg 30 kg 0.001 kg 0.002 kg 0.005 kg 0.01 kg OTHER SPECIFICATIONS Units of measure kg, g...

  • Page 16: Error Codes

    ERROR CODES During the initial power-on testing or during operation, the scale may show an error message. The meaning of the error messages is described below. If an error message is shown, repeat the step that caused the message. If the error message is still shown then contact your dealer for support.

  • Page 17: Service Information

    SERVICE INFORMATION This manual covers the details of operation. If you have a problem with the scale that is not directly addressed by this manual then contact your supplier for assistance. In order to provide further assistance, the supplier will need the following information which should be kept ready: A.
  • Page 18 SOCIETÀ COOPERATIVA BILANCIAI CAMPOGALLIANO Via S. Ferrari, 16 41011 Campogalliano (MO) - Italia Declare under our responsibility that the product: Electronic weighing terminal E402 and its options described in this declaration complies with: Directive EMC 2004/108/CEE Directive Low voltage 2006/95/CE Conformity is censure by complying with EN 61000-6-3, EN 61000-6-4 EN 60950...
  • Page 19 This symbol on the w eighing instrument you have purchased means that: • this electric or electronic appliance cannot be disposed of as solid municipal w aste; • it must be collected separately; • it can be returned to the dealer w hen a new one is purchased; •...
