T100
R 2
Transpallet Weighing Systems for Internal Use
T100 and T100S
Use and Maintenance Manual
Code
81320224

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T100 and is the answer not in the manual?

Questions and answers

Summary of Contents for WorldWEIGH T100

  • Page 1 T100 Transpallet Weighing Systems for Internal Use T100 and T100S Use and Maintenance Manual Code 81320224...
  • Page 2 T100 DECLARATION OF CONFORMITY SOCIETA’ COOPERATIVA BILANCIAI Via S.Ferrari,16 41011 Campogalliano (MO) ITALIA We declare that the product described in this manual complies with the following CE requirements - 90/384 CEE and subsequent modifications: Standard EN 45501 - 2004/108/CE : Standard EN 61000-6...
  • Page 3: Table Of Contents

    T100 TABLE OF CONTENTS G E N E R A L … … … … … … … … … … … … … … … … … . … . … . . … … . 1 M E C H A N I C...
  • Page 4 T100...
  • Page 5: General

    T100 1 GENERAL The transpallet T100 series are composed by accurate and fast solutions for weighing operations. The range comprises 4 lines of scales with 2 different fork dimensions and integrated printer. Keyboards are all water proof with membrane keys and the backlighted liquid crystal displays (LCD) are large to make reading easier.
  • Page 6: Safety Regulations

    T100 2.2 SAFETY REGULATIONS For a safe use of the transpallet, please read the danger signals on the instrument and these instructions before operating it. 1. Do not use the transpallet without authorization or the proper training. 2. Do not use the transpallet before checking its conditions, paying particular attention to the wheels, the helm unit, the forks and the lower command.
  • Page 7: Keys

    T100 5. Operators are suggested to wear protective gloves and safety shoes. 6. Do not transport unstable weights or weights which have been piled but not properly fastened. 7. Do not overload the transpallet. 8. Do not place weights off balance either horizontally or lengthwise on the frame.
  • Page 8: Operating Modes

    T100 Adds the displayed value to the stored total. When the scale is at zero, pressing this key the current total is displayed, if a printer is connected, also the printing of weight and total is activated. Shifts to the left the active digit while setting values.
  • Page 9: Tare

    T100 4.1.2 Tare If needed, set the scale to zero pressing the ZERO key. The stable weight indication is displayed. Place a container on the platform, the value of its weight is displayed. Press TARE to capture a tare. The displayed weight is stored as tare value then subtracted leaving zero displayed.
  • Page 10: Net/Gross Switching

    T100 4.1.4 Net/Gross Switching Available only after capturing a tare or entering a preset tare (NET indication visible), press the N/G key to get net weight and gross weight alternately displayed (the gross weight display shows the “GROSS” indicator, the net weight display shows the “NET”...
  • Page 11: Recalling A Total

    T100 4.2.3 Recalling a Total To display the total in the memory press M+ with scale at zero (the ZERO indicator displayed), "ACC n" is displayed (n is the current number of operations of totalization) before the total in the memory for 2 seconds.
  • Page 12: B A T T E R Y O P E R A T I O

    T100 6. BATTERY OPERATION The weight indicator can be battery operated. The battery has an approximately 70 hour life span. When the battery needs to be recharged, the arrow above the low battery symbol above the weight display is on. The scale operates for one hour, then it automatically switches off in order to protect the battery.
  • Page 13 T100 Transpallet T100: installation instructions handle 1. Remove the plastic strips from the packaging. 2. Remove the carton box, inside it the indicator and the transpallet are separated 3. Take the helm out 4. Take the indicator (display unit) out of the packaging material, place it on the instrument. The cable running downward.
  • Page 14 T100 5. Remove the screws of the display unit by means of a screwdriver, open the display unit case where the junction box and three threaded holes are located. 6. Use 3 socket head screws to fix the display unit on the transpallet using a socket spanner. All the parts are...
  • Page 15 T100 Installation General Avoid extreme temperatures. Do not place in the direct sunlight or air conditioned. Avoid moist condensation. Avoid to wet the scale. Do not sprinkle or dip the scale into water. Keep the scale clean. Do not pile material when the scale is not in use.
  • Page 16 T100 in the groove of the part (139H) “elbow”. Adjusting the Lowering System The helm lever (H106) has three positions. Adjust the set screw (140H), located on the part (139H) “crank link”, so that when the is lever in the LOWER position, the forks go down.
  • Page 17 T100 Maintenance Check the oil level each six months, the quantity is about 0,3 liters. Use an hydraulic oil according to the following table. Temperature L-HM68 hydraulic oil (equivalent to ISO VG68) -5℃~+45℃ L-HM46 hydraulic oil (equivalent to ISO VG46) -15℃~-5℃...
  • Page 18 T100 SOC. COOP. BILANCIAI CAMPOGALLIANO 41011 Campogalliano (MO) Via Ferrari, 16 tel. +39 (0)59 893 611 – fax +39 (0)59 527 079 servizio post-vendita after sales service service après-vente kundendienstservice servicio post-venta serviço pòs-venda tel. +39 (0)59 893 612 - fax +39 (0)59 527 294...
