- Page 1 RA SERIES (with EC type Approval) (P.N. 6315, Rev. C7, July 2011) Software rev.: 2.29A & above 81320484 en...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION ...................... 3 FEATURES......................3 SPECIFICATIONS ....................4 INSTALLATION ......................4 LOCATING THE SCALES..................4 SETTING UP THE SCALES.................. 5 DISPLAY WINDOWS .................... 5 BATTERY CHARGING ..................6 KEY DESCRIPTIONS ................... 7 OPERATION ......................8 ZEROING THE DISPLAY ..................8 TARING ........................ -
Page 5: Introduction
1.0 INTRODUCTION The RA series of digital price-computing scales are EC Type approved. These scales provide an accurate, fast and versatile method of computing price by weight. FEATURES Stainless steel weighing platform Level indicator with adjustable levelling feet ... -
Page 6: Specifications
SPECIFICATIONS RA 100 RA 100 RA 100 RA 200 RA 200 RA 200 RA 200 10030 15P* 30P* Maximum Capacity 3 kg 6 kg 15 kg 30 kg 3 kg 6 kg 15 kg 30 kg Readability 10 g 10 g Tare -3 kg -6 kg... -
Page 7: Setting Up The Scales
SETTING UP THE SCALES The scales come with a stainless steel platform, packed separately. Place the platform in the receptacles on the top cover. Do not press with excessive force as that could damage the load cell inside. -
Page 8: Battery Charging
The window for the Weight has arrows to indicate when the scale is at zero or if the scale is displaying a net weight (if a tare value has been entered). It also indicates when the scale is stable. The window for the Unit Price has arrows to show when the Auto Clear function is active and if the unit price is per 100g or per kilogram. -
Page 9: Key Descriptions
KEY DESCRIPTIONS Not applicable for South Africa and Far East [0-9] keys Numeric entry keys to set the unit price. [00] key Numeric entry keys to enter double zero values. For example, to enter 2 pounds or Euros, press [2] and [00]. The display will show “2.00”. -
Page 10: Operation
3.0 OPERATION ZEROING THE DISPLAY You can press the [Zero] key when no tare is entered to set the zero point from which all other weighing is measured. This will usually be necessary when the platform is empty. When the zero point is obtained the Weight window will show an arrow next to the Zero legend marked under the Weight window. -
Page 11: Determining Value Of A Product By Weight
DETERMINING VALUE OF A PRODUCT BY WEIGHT To determine the cost of a product sold by weight, it is necessary to enter the cost per kilogram or per 100g using the numeric keys or one of the preset PLU values. ... - Page 12 The user can store and recall up to 103 PLU values as PLU1, PLU2, PLU3 and PLU00 to PLU99. The keys labelled [PLU1] and [PLU2] are used to immediately recall the most frequently used PLU values saved as PLU1 and PLU2. The [PLU+] key is used to access the other values saved as PLU3 and PLU00 to PLU99.
-
Page 13: Entering Values For The Plu S
ENTERING VALUES FOR THE PLU s To store values for the PLUs into the memory follow the procedure. Entering values for PLU1 and PLU2 keys Enter the unit price value using the keypad, selecting either price/kg or price/100g if needed. ... -
Page 14: Auto Clear Key
AUTO CLEAR KEY The [Auto Clear] key will enable the Auto Clear function. When this function is active the scale will automatically clear (set to zero) the unit price when the last item to be weighed has been removed from the scale. -
Page 15: Auto Sleep Function
AUTO SLEEP FUNCTION This function may be enabled or disabled by the user. If enabled, when the scale is not used for some time (as pre-set by the user under this function) it automatically switches off. To set this parameter- ... -
Page 16: Rs-232 Interface
3.10 RS-232 INTERFACE The RA scales include a bi-directional RS-232 interface. When connected to a printer or computer, the scale outputs the weighing results using the RS-232 interface. The scale can be controlled sending commands from a PC. See section 3.10.1. - Page 17 Displays Options Functions Weight Unit Price Total Price Port on or oFF Enable or disable the RS-232 interface. 4800 600, 1200, 2400, Set baud rate. 4800, 9600 or 19200 1, 2 or 3 LAbEL Select label format to print. CoUntr nGLiSH EnGLiSH, FrEnCH, Select Language...
-
Page 18: Real Time Clock Setup
3.11 REAL TIME CLOCK SETUP The Real Time Clock (RTC) is used only for the RS-232 output. The Date and Time can be set as required. The scale will keep the clock running even when the power is off. Setting up the clock ... -
Page 19: Error Codes
4.0 ERROR CODES During the initial power-on testing or during operation, the scale may show an error message. If an error message is shown, repeat the step that caused the message. If the error is still shown contact your dealer for further support. ERROR DESCRIPTION POSSIBLE CAUSES... -
Page 20: Calibration
5.0 CALIBRATION 5.1 CALIBRATION PROCEDURE The scales are sealed to prevent unauthorised calibration. Contact your supplier for more details. The calibration of the RA scale is accomplished by removing the label at the base of the scale which covers a hole through which the PCB can be accessed. -
Page 21: Replacement Parts And Accessories
6.0 REPLACEMENT PARTS AND ACCESSORIES If you need to order any spare parts and accessories, contact your supplier. A partial list of such items is as follows- Main Power cord In use cover Replacement Battery Stainless Steel Pan 7.0 SERVICE INFORMATION This manual covers the details of operation. - Page 22 WEEE COMPLIANCE This symbol on the weighing instrument you have purchased means that: • this electric or electronic appliance cannot be disposed of as solid municipal waste; • it must be collected separately; • it can be returned to the dealer when a new one is purchased; •...
- Page 23 COOPERATIVA BILANCIAI CAMPOGALLIANO Via S.Ferrari 16 41011 Campogalliano Italy Declaration of Conformity Verklaring van overeenstemming Konformitätserklärung Dichiarazione di Conformità Déclaration de Conformité Declaración de Conformidad Het niet –automatische weegwerktuig The non-automatic weighing instrument Die nicht- automatischen Wägeapparate Strumento per pesatura non automatico L’instrument de pesage à...
