Summary of Contents for WorldWEIGH BA 201 Series
- Page 1 BA 201 / BA 201-M SERIES PN 3.05.6.6.16339, Rev A1, October 2022 81320602 en...
- Page 2 81320602 en...
-
Page 4: Table Of Contents
CONTENTS 1.0 INTRODUCTION ................... 2 2.0 SPECIFICATIONS ................3 3.0 INSTALLATION ..................5 UNPACKING ......................5 LOCATING ......................5 SETTING UP THE SCALES .................. 6 4.0 KEYPAD ....................7 5.0 DISPLAY ....................9 SYMBOLS AND INDICATORS ................9 6.0 CALIBRATION COUNTER FOR APPROVED SCALES ....10 7.0 BATTERY ................... -
Page 5: Introduction
INTRODUCTION The BA 201 scales provides an accurate, fast and versatile general purpose weighing scales with parts counting, percent weighing and check-weighing functions. The BA 201 has colour changing LCD illumination to indicate when a weight is below the low limit, between the limits or above the high limit next to the display. -
Page 6: Specifications
SPECIFICATIONS BA 201-M Models Model # BA 201-M/30 BA 201-M/60 BA 201-M/150 BA 201-M/300 Maximum Capacity 30kg 300kg 60kg 150kg Readability 100g 100g Repeatability (Std 200g Dev) Linearity + 100g 200g Units of Measure Kilograms, grams Stabilization Time 2 Seconds typical Operating -10°C to +40°C / +14°F to +104°F Temperature... - Page 7 BA 201 Models BA 201/300 BA 201/600 Model BA 201/32 BA 201/75 BA 201/150 Maximum 32kg 150kg 300kg 50kg Capacity Readability Repeatability (Std Dev) Linearity + 100g Units of Measure Kilograms, pounds Stabilization Time 2 second typical Operating -10°C to +40°C / +14°F to +104°F Temperature 110V - 240 VAC 50/60 Hz Power Supply...
-
Page 8: Installation
INSTALLATION UNPACKING The BA 201 scales have already been adjusted to work with a platform and have been configured for this application. The platform and indicator have been calibrated as a pair and must be used together. LOCATING The scales should not be placed in a location that will reduce the accuracy. -
Page 9: Setting Up The Scales
Excess cable can be stored within the tube. The BA 201 series comes with a stainless steel platform packed separately. Place the platform in the base. Level the scale by adjusting the four feet. If the scale rocks re-adjust the feet. -
Page 10: Keypad
4.0 KEYPAD KEYS PRIMARY FUNCTION SECONDARY FUNCTION [Zero] Sets the zero point for all subsequent Escape from any setting menus weighing. The display shows zero. [Tare] It tares the scale and stores the current Accept the set values weight in memory as a tare value, subtracts the tare value from the weight and shows the results. - Page 11 [Low It sets the limits for check weighing and None Limit] allows setting of either the low limit or the high limit or both. & [High Limit] [Lim] It stores and recalls any of 10 preset None limits [Func] This is used to select percent weighing, None RS-232 parameters, Operation of the bar graph, RTC settings, User ID and...
-
Page 12: Display
DISPLAY SYMBOLS AND INDICATORS The LCD has unique symbols to indicate the following: 0 The display is at Zero The scale is Stable Net weight- The scale has been tared kg / g Symbols shown for the units Capacity Tracker- A bar graph indicating the proportion of the scale capacity being used by the weight on the platform Battery status... -
Page 13: Calibration Counter For Approved Scales
CALIBRATION COUNTER FOR APPROVED SCALES The approved (BA 201-M model) scales have the ability to control access to the calibration or metrology parameters using a passcode to limit access. The requirements for doing this stipulate the counters should be apparent and recorded in a suitable location on the scale. In this way if the record of the Calibration or Parameter counters do not agree with recorded settings the responsible person inspecting the scale can take appropriate action. -
Page 14: Backlight
BACKLIGHT The backlight for the LCD can be set by the user to always off, always on or automatic (on only when the indicator is in use or a key is pressed). See setting of “ ” S2 bL the parameter in section 13.3. -
Page 15: Taring
10.2 TARING 10.2.1 Manual tare Zero the scale by pressing [Zero]. The zero indicator will be on. Place a container on the platform and its weight will be displayed. Press [Tare] when the reading is stable. The weight that was displayed is stored as the tare value and it is subtracted from the display, leaving zero on the display. -
Page 16: Weighing
10.3 WEIGHING To determine the weight of a sample, first tare an empty container if used, then place the sample in the container. The display will show the weight and the unit of weight currently in use. To change the weighing unit press the [Unit] key. The only alternative weighing unit is grams. - Page 17 Press [Tare] to weigh the samples and determine the average piece weight. During the calculation on the display there will be dashes “- - - - - - - -“ the procedure will end with a beep and the display of the pieces. ...
-
Page 18: Check-Weighing
To count a different sample quantity, press the [Funct] key. The display will show the last amount of samples then it will reset. Use this sample quantity with a different piece or enter a new sample quantity as described above. ... -
Page 19: Setting Up While Weighing
10.5.1 SETTING UP WHILE WEIGHING Press the [Low Limit] key. It will show the current low limit. The “LO” symbol will appear on the display. Press the [CE] key to clear the old value and then enter the new low limit using the numeric keys. -
Page 20: Limits Storing And Recalling
10.6 LIMITS STORING AND RECALLING The scale can store up to 10 sets of high and low limits in memory along with the weighing units in use (including pcs for parts counting and % for percent weighing) as well as settings for the beeper. -
Page 21: Percent Weighing
NOTE: If the recalled limit is for parts counting, the display will show the last sample value used, ready for a new sample to be counted. If the recalled unit is a percent weighing limit, the display will show the last sample value used, ready for a new sample to be weighed. - Page 22 Remove the sample weight. Then any other weight placed on the scale will be displayed as a percentage of the original sample. For example, if 3500g is placed on the scale and percent weighing is selected, the display will show 100.00%. Remove the 3500g weight and place a 3000g weight.
- Page 23 10.8 ANIMAL (Dynamic) WEIGHING The scale can be set to animal (dynamic) weighing for weighing any items that are unstable or may move. See Section 13.4. The scale will use a special filter to minimise the effects of any movement on the platform ...
-
Page 24: Animal Weighing Procedure
10.8.1 ANIMAL WEIGHING PROCEDURE With the platform empty the display will show zero weight. Place containers or blankets onto the platform and press the [Tare] key to zero the display. The scale may go into the animal weighing procedure when the items are placed on the scale but will return to showing zero when the [Tare] key is pressed. -
Page 25: Manual Accumulation
10.9.1 MANUAL ACCUMULATION When the scale is set to manual accumulation, the weight displayed will be stored in the memory when the [Print] key is pressed and the weight is stable. Remove the weight and press [Print] when the scale is at zero. The display will show "ACC 1"... -
Page 26: Automatic Accumulation
10.9.2 AUTOMATIC ACCUMULATION When the scale has been set to Automatic Accumulation the value is stored in memory automatically. Place a weight on the platform. The beeper will sound when the scale is stable indicating the value is accepted. Remove the weight. ... -
Page 27: Rs-232 Specification
11.0 RS-232 SPECIFICATION The BA 201 indicator is supplied with bi-directional RS-232 interface as standard. The scale when connected to a printer or computer outputs the weight with the selected weighing unit through the RS-232 interface. Default Specifications: RS-232 output of weighing data ASCII code 9600 Baud (user selectable) 8 data bits... - Page 28 Data Format-Normal Output: Only weight value along with the weighing unit is printed. If Percent weighing is used then % is shown in place of weighing units. <cr><lf> <cr><lf> 12/09/2006 <cr><lf> Time 14:56:27 <cr><lf> <cr><lf> Scale ID 123456 <cr><lf> If ID is zero, it is left blank User ID 234567 <cr><lf>...
- Page 29 Data Format- Memory Recall Output: <cr><lf> Date 12/09/2006 <cr><lf> Time 14:56:27 <cr><lf> <cr><lf> Scale ID 123456 <cr><lf> User ID 234567 <cr><lf> <cr><lf> ------------------<cr><lf> TOTAL <cr><lf> 1.234 kg <cr><lf> 10 pcs <cr><lf> <cr><lf> ------------------<cr><lf> <cr><lf> Data Format- Continuous Output- Normal weighing: 1.234 kg <cr><lf>...
- Page 30 NOTE: 1. The accumulated total will not be sent to the RS-232 when the continuous print is turned on. 2. The continuous print will only be for the current weight and the display data. 3. In other languages the format is the same but the text will be in the language selected.
-
Page 31: Input Commands Format
11.1 INPUT COMMANDS FORMAT The scale can be controlled with the following commands. Press the [Enter] key of the PC after each command. T<cr><lf> Tares the scale to display the net weight. This is the same as pressing [Tare]. Z<cr><lf> Sets the zero point for all subsequent weighing. -
Page 32: Parameter Settings
13.0 PARAMETER SETTINGS Pressing the [Func] key allows the user to access the parameters for customising the scale. The parameters are split into 4 groups: 1. Check weighing parameters, 2. RS-232 parameters and 3. Scale parameters 4. Percent and Animal Weighing Functions ... - Page 33 This group of parameters- -enables or disables the percent weighing -sets the lock for re-setting the check weighing limits -enables or disables the check weighing alarm -sets the User Password for check weighing -enables or disables the negative check weighing Parameter Description Options...
-
Page 34: Rs-232 Parameters
13.2 RS-232 PARAMETERS Shortcut to enter this group is to press and hold the [Print] key for 4 seconds. The display will go directly to “C1 on”. Press [Func] to view the list of parameters. Press [Tare] to enter a parameter. Press [Func] to view the options for the parameter settings. - Page 35 C3 PrM MA StA, MA StA Printing Mode, Manual or Automatic, when Au StA, Stable or Automatic Au Con Continuous C4 Aon AC on AC on Enable or disable the Accumulation AC oFF C5 Ln EnGLi EnGLi Select Language (English) FrEnCH (French) SPAn...
-
Page 36: Scale Parameters
13.3 SCALE PARAMETERS Shortcut to enter this group is to press and hold the [Count] Key for 4 seconds. The display will go directly to “S1 Un ”. Press [Func] to view the list of parameters. Press [Tare] to enter a parameter. Press [Func] to view the options for the parameter settings. -
Page 37: Percent Weighing And Animal Weighing
S6 FL SLowESt (1-6) SLowEr 3 Filter setting, the slower the filter, the longer the readings SLowEr (1-6) will be averaged, the more FAStEr (1-6) accurate the result FAStESt (1-6) S7 SPS PI _ _ _ _ 0000 Scale Password- If it is anything other than 0000 then the user must enter the password to gain access to... -
Page 38: Error Messages
14.0 ERROR MESSAGES During the initial power-on testing or during operation, the scale may show an error message. The meaning of the error messages is described below. If an error message is shown, repeat the step that caused the message. If the error message is still shown then contact your dealer for support. -
Page 39: Replacement Parts And Accessories
Err 20 PLU storage/ reading is more than PLU number above max range of 50 Can’t find ADC chip Err ADC Damaged or missing ADC chip Load cell is damaged. Electronics is damaged. ---OL--- Weight over range Weight over scale range undEr Weight is lower than -25e Weight below scale range... -
Page 40: Service Information
16.0 SERVICE INFORMATION This manual covers the details of operation. If you have a problem with the scale that is not directly addressed by this manual then contact your supplier for assistance. In order to provide further assistance, the supplier will need the following information which should be kept ready: A. -
Page 41: Appendix
APPENDIX 17.0 PARAMETER LAYOUT for BA 201 hSERIES SCALES Key functions while in this section [Tare] enter a parameter or accept the changes Press the [Func] key to [Func] move to next parameter or option enter Functions mode. Low Lim] move to previous parameter or option [Zero] return to previous parameter or return to weighing FUNC 1 FUNC 2... - Page 42 WEEE 2012/19/EU This device may not be disposed of in domestic waste. This also applies to countries outside the EU, per their specific requirements. Disposal of batteries (if fitted) must conform to local laws and restrictions. Cet appareil ne peut être éliminé avec les déchets ménagers. L’élimination de la batterie doit être effectuée conformément aux lois et restrictions locales.
