Kärcher HDS 6/10-4 C/CX Basic Instruction Manual page 24

Note: A system care bottle is included in
the delivery.
 Replace the system care bottle.
Refill fuel
DANGER
Risk of explosion! Only refill diesel oil or
light fuel oil. Unsuitable fuels, e.g. petrol,
are not to be used.
ATTENTION
Never operate device with empty fuel tank
The fuel pump will otherwise be destroyed.
 Refill fuel.
 Close tank lock.
 Wipe off spilled fuel.
Refill detergent
DANGER
Risk of injury!
– Use Kärcher products only.
– Under no circumstances fill solvents
(petrol, aceton, diluting agent etc.)
– Avoid eye and skin contact.
– Observe safety and handling instruc-
tions by the detergent manufacturer.
Kärcher offers an individual cleaning
and care appliances program.
Your dealer will consult you gladly.
 Refill detergent.
Water connection
For connection values refer to technical
specifications
 Attach supply hose (minimum length
7.5 m, minimum diameter 3/4") to the
water supply set by means of a hose
clamp.
 Connect the supply hose to the water
connection point of the machine and at
the water supply point (for e.g. a tap).
Note: The supply hose and the hose clamp
are not included in the scope of delivery.
Suck in water from vessel
If you want to suck in water from an exter-
nal vessel, the following modification is
necessary:
 Remove the system care bottle.
24
All manuals and user guides at all-guides.com
Figure 9
 Remove the two screws on the burner
Figure 10
 Unscrew the back wall and remove it.
Figure 11
 Remove water connection from the fine
 Unscrew the fine filter from the pump
 Remove the system care reservoir.
Figure 12
 Unscrew the top supply hose to the
 Connect the top supply hose at pump
 Replug the rinse line of the detergent
 Connect suction hose (minimum diame-
– Max. suck height: 0.5 m
Until the pump sucked in water, you should:
 Set the pressure/quantity regulation at
 Close the dosing valve for the deter-
Never suck in water from a drinking water
container. Never suck in liquids which con-
tain solvents like lacquer thinner, petrol, oil
or unfiltered water. The sealings within the
device are not solvent resistant. The spray
mist of solvents is highly inflammable, ex-
plosive and poisonous.
 Assembly in reverse order.
Note: Ensure that the solenoid valve cable
on the reservoir of the system care is not
pinched.
Figure 13
Note: After placing the back wall, reach into
the chute of the system care and press the
nozzle onto the system care reservoir.
– 5
EN
casing.
The nozzle of the system care reservoir
will remain in the back wall.
filter.
head.
swimmer container.
head.
dosing valve to blind plugs.
ter 3/4") with filter (accessory) to the
water connection point.
the pump unit to maximum quantity.
gent.
DANGER
