Arterial 2 Dual 560mm Water-box
Arterial 2 Dual 560mm Water-box is a dedicated high-end water-cooling enclosure with a
distribution plate which integrates a reservoir, pump tops and pump covers. It fits dual 85mm
thick 560mm radiators, push pull fans and a dual D5 configuration in series. All components are
CNC machined, the enclosure is built from 3mm 6061 aluminum, the distribution plate from cast
acrylic and the fasteners are stainless steel.
Arterial 2 has been completely redesigned. The enclosure is now built from folded aluminum
which greatly improves strength and gives a more streamlined aesthetic. All ventilation is now
dust filtered. The distribution plate has been re designed for increased fluid volume.
Specifications & Included Items
Water-box enclosure
Distribution Plate
DDC Pump Top
SC Stop Fittings
Side Panel Window
LED Strip
Dimensions
Packaged Dimensions
Weight
Packaged Weight
Installation
Step 1
Attach the Top and Bottom Panels to the two Radiator
Mounting Panels using the included M4 6mm Fasteners x12
which are marked in the diagram.
Revision 1.0
6061 Aluminum, CNC Machined, Anodized.
Clear Cast Acrylic, CNC Machined.
Clear Cast Acrylic, CNC Machined.
x2 Brass, Powder coated, Laser Etched.
x1 Clear Cast Acrylic, CNC Machined.
x1 Spectrum 2.0 50cm 5V D-RGB LED Strip.
W: 220mm x L: 155mm x H: 320mm
W: 300mm x L: 200mm x H: 400mm
4 kg
5 kg
| Arterial 2 Manual
Page | 4
