- Page 1 OPERATOR AND PARTS MANUAL Round Bale Carrier Model 1450H 092017 F2324...
-
Page 3: Operation
1450H Bale Carrier OPERATION Optional Clevis Hitch (SZ000513) For tractors not equipped with a clevis drawbar, a IMPORTANT clevis hitch for the bale carrier is available. Use an approved hitch pin with a retainer. Attaching Bale Carrier Controls to Tractor... - Page 4 1450H Bale Carrier Loading Bales FIXED PICKUP ARM WARNING Make sure area is clear before lowering bale lift- arm. Failure to do so could result in injury or death. Align the tractor and bale carrier as indicated in the pictoral for pick up method used. Slowly approach the bale at 5 mph (8 km/h) while loading.
- Page 5 1450H Bale Carrier Optional Bale Stop (815692) Rotating Pickup Arm (RPU) The rotating pick up arm (RPU) loads bales “side When loading narrower bales (4’), an adjustable on” . The lift arm starts in the lowered position. bale stop is available. Using this stop permits...
-
Page 6: Part Identification
1450H Bale Carrier PART IDENTIFICATION The parts identification section list descriptions, part numbers and quantities for all North America Base Model 1450H bale carriers. Contact your Farm King dealer for additional parts information. HYDRAULIC COMPONENTS RED COVER BLACK COVER RED COVER... - Page 7 1450H Bale Carrier ITEM PART NUMBER DESCRIPTION QTY. 115169 3/8 HOSE X 132 ASSY 29256 COVER PLATE 810582 5/16" X 3" HEX BOLT (PL) 812069 TEE 3/4 MJIC 815608 BLOCK POLYPROPELENE 3/8 PAIR 815610 1/2" HOSE LINE MOUNT ASSEMBLY 818775 ASSEMBLY - HYD HOSE 0.375"X92"...
- Page 8 1450H Bale Carrier TAILLIGHT WIRING HARNESS & COMPONENTS 818777...
- Page 9 1450H Bale Carrier ITEM PART NUMBER DESCRIPTION QTY. 811795 3/8" X 2" HEX BOLT (PL) 812363 3/8" LOCK NUT (PL) 812537 NUT LOCK (NYLON) 0.136 NC GRB PL 813958 SCREW MACH #8-32 X 0.75 FLATHD 814063 CLAMP , WIRING HARNESS...
- Page 10 www.farm-king.com 2500 Airport Drive SW Willmar, MN 56201 Toll Free: 1-888-FK-80001 E-mail: info@buhler.com www.farm-king.com Equipment shown is subject to change without notice. ©2017 Buhler Trading Inc. Printed in USA TSX:BUI a division of Buhler Industries Inc.
