OPERATOR AND PARTS MANUAL
Backsaver Auger
Model 1370, 1385, 1395, 13114
072018
FK325
6990633 (1-13)
Printed in U.S.A.
© Bobcat Company 2013
062013 | Rev 1 | 88664296

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1370 and is the answer not in the manual?

Questions and answers

Related Manuals for Farm King 1370

Summary of Contents for Farm King 1370

  • Page 1 OPERATOR AND PARTS MANUAL Backsaver Auger Model 1370, 1385, 1395, 13114 072018 FK325 6990633 (1-13) Printed in U.S.A. © Bobcat Company 2013 062013 | Rev 1 | 88664296...

  • Page 3: Table Of Contents

    Table of Contents - 13" Backsaver Auger TABLE OF CONTENTS Manufacturer’s Statement: For technical reasons, Buhler Industries Inc. reserves the right to modify machinery design and specifications provided herein without any preliminary notice. Information provided herein is of descriptive nature. Performance quality may depend on soil fertility, applied agricultural techniques, weather INTRODUCTION .
  • Page 4 Table of Contents - 13" Backsaver Auger...

  • Page 5: Safety

    Customer / Owner’s Signature: Remove this Warranty Registration Form from the Operator And Parts Manual. Make two copies of the form. Send original Warranty Registration Form to Farm King. Give one copy to the customer and the dealer will keep one copy.
  • Page 6 Warranty Registration - 13" Backsaver Auger...

  • Page 7: Introduction

    Farm King equipment. READ AND UNDERSTAND THIS OPERATOR AND PARTS MANUAL BEFORE OPERATING YOUR FARM KING EQUIPMENT. If you have any questions, see your Farm King dealer. This manual may illustrate options and accessories not installed on your Farm King equipment.
  • Page 8 Introduction - 13" Backsaver Auger...

  • Page 9: Owner's Information

    Introduction - 13" Backsaver Auger OWNER’S INFORMATION Serial Number Location Thank you for your decision to purchase a Farm King Please enter the model and serial number in the space Backsaver Auger. To ensure maximum performance of provided for easy reference.

  • Page 10: Equipment Identification

    Introduction - 13" Backsaver Auger EQUIPMENT IDENTIFICATION Component Location BOOM BRIDGING INPUT BOX ELBOW DISCHARGE SPOUT HYDRAULIC CYLINDER DRIVELINE UNDERCARRIAGE INTAKE AUGER WHEELS INPUT BOX HOPPER JACK SAFETY CHAIN FK325 - 13...
  • Page 11 Safety - 13" Backsaver Auger SAFETY SAFETY INSTRUCTIONS ..........13 Safe Operation Is The Operator’s Responsibility .
  • Page 12 Safety - 13" Backsaver Auger...

  • Page 13: Safety Instructions

    It may also be used to alert against Understand the Written Instructions, Rules and unsafe practices. Regulations • The written instructions from Farm King include the Warranty Registration, Dealer Inspection Report, Operator and Parts Manual and machine signs (decals). •...

  • Page 14: Use Safety Rules

    Safety - 13" Backsaver Auger SAFETY INSTRUCTIONS (CONT’D) Transport Safety Use Safety Rules • Review Transport Safety instructions in tractor • Read and follow instructions in this manual and the manual before moving. tractor’s Operators Manual before operating. • The equipment should never be towed without the •...

  • Page 15: Operation Safety

    Safety - 13" Backsaver Auger SAFETY INSTRUCTIONS (CONT’D) Safety Rules For Power Take-Off (PTO) Driven Equipment Operation Safety • Keep PTO shields and all guards in place. Replace • Ensure bystanders are clear of the area before damaged or missing shields and guards before operating.

  • Page 16: Machine Requirements And Capabilities

    Safety - 13" Backsaver Auger SAFETY INSTRUCTIONS (CONT’D) Machine Requirements And Capabilities • Fasten seat belt securely. If equipped with a foldable Roll-Over Protective Structure (ROPS), only fasten seat belt when ROPS is up and locked. DO NOT wear seat belt if ROPS is down. •...

  • Page 17: Operation

    Fueling Operation The Farm King machine must be in good operating condition before use. Check all of the items listed on the service schedule under the 8 hour column. (See “SERVICE SCHEDULE” on page 144.) Stop the engine and let it cool before adding fuel.

  • Page 18: Welding And Grinding

    Safety - 13" Backsaver Auger FIRE PREVENTION (CONT’D) Welding And Grinding Always clean the machine and equipment, disconnect the battery, and disconnect the wiring from the machine controls before welding. Cover rubber hoses, battery and all other flammable parts. Keep a fire extinguisher near the machine when welding.

  • Page 19: Operating Safety Zone

    Safety - 13" Backsaver Auger OPERATING SAFETY ZONE Safety Zone Identification ELECTROCUTION HAZARD • Owners operators Keep away from power lines, AVOID INJURY OR DEATH should allow only electrocution occur authorized personnel and • allow small without direct contact. grain transport vehicles children,...

  • Page 20: Safety Signs (Decals)

    SAFETY SIGNS (DECALS) Follow the instructions on all the Signs (Decals) that are on the equipment. Replace any damaged signs (decals) and be sure they are in the correct locations. Equipment signs are available from your Farm King equipment dealer.
  • Page 21 Safety - 13" Backsaver Auger SAFETY SIGNS (DECALS) (CONT’D) Intake Auger Input Box Elbow B-0934 B-0909 p/n 961016 p/n 963206...
  • Page 22 Safety - 13" Backsaver Auger SAFETY SIGNS (DECALS) (CONT’D) Intake Auger B-0738 p/n 917765 p/n 961017...

  • Page 23: Equipment Decals And Signs

    Safety Signs Section. (See “SAFETY SIGNS (DECALS)” on page 20.) Check and replace any worn, torn, hard to read or missing decals on your equipment. Part Number 910575 Part Number 960372 1370 Part Number 910577 1385 Part Number 961015 Part Number 910578 1395...

  • Page 24: Safety Sign-Off Form

    Untrained operators and failure to follow instructions can cause injury or death. Farm King follows the general Safety Standards specified by the American Society of Agricultural and Biological Engineers (ASABE) and the Occupational Safety and Health Administration (OSHA). Anyone who will be operating and / or maintaining the Backsaver Auger must read and clearly understand ALL Safety, Operating and Maintenance information presented in this manual.
  • Page 25 1370, 1385 & 1395 Bridging Assembly ........49...
  • Page 26 Assembly - 13" Backsaver Auger...

  • Page 27: General Assembly Information

    • DO NOT permit bystanders to be in the work area 4. Hydraulic (See “1370, 1385, 1395 HYDRAULIC when unloading and assembling the auger ASSEMBLY” page 86.) (See “13114 components.

  • Page 28: Base Group

    Align the hub (Item 1) [Figure 5] with the axle. Stub Axle Mounting Bolt Sizes 1/2” x 1-3/4” - Models 1370, 1385 and 1395. 3/4” x 2-1/2” - Models 13114. Install and tighten the four bolts (Item 2) [Figure 5] and lock nuts.
  • Page 29 Raise and move the RH lower lift arm to the assembly Undercarriage Arm Mounting Bolt Sizes area. 5/8” x 2” - Models 1370, 1385 and 1395. 3/4” x 2-1/2” - Models 13114. Install four bolts (Item 3) [Figure 7] and lock nuts. Do...
  • Page 30 (Item 2) [Figure 11] on the axle. Lift Arm Axle Pin Sizes Install one axle pin (Item 3) [Figure 11] through the 1” x 5.63” - 1370 Models axle mounts and LH lower lift arm. 1” x 6.38” - 1385 & 1395 Models Install one 1-1/4”...

  • Page 31: 1370, 1385 & 1395 Link And Yoke Assembly

    Assembly - 13" Backsaver Auger 1370, 1385 & 1395 Link and Yoke Assembly Figure 14 Figure 12 B-0786A Continue installing the connecting link pin through the B-0784 connecting link and RH lower lift arm. Place the connecting link (Item 1) and pivot yoke (Item Install one 2”...
  • Page 32 Narrow Rim Washer Sizes Figure 17 1-1/2” x 10 Ga. - 1370 Models 2” x 10 Ga. - 1385 & 1395 Models Cotter Pin Sizes 1/4” x 2” - 1370 Models 5/16”...
  • Page 33 Assembly - 13" Backsaver Auger Figure 19 Figure 21 B-0846 B-0790A Install one 1/2” flat washer on the remaining 1/2” x 2” bolts (Item 1) [Figure 21], install bolts through the Lift the LH & RH lower lift arms. Remove blocks (Item lift arm torque tube and LH &...
  • Page 34 1-1/2” x 7-1/8” - 1370 Models Figure 24 2” x 9-1/16” - 1385 & 1395 Models Narrow Rim Washer Sizes 1-1/2” x 10 Ga. - 1370 Models 2” x 10 Ga. - 1385 & 1395 Models Cotter Pin Sizes 1/4” x 2” - 1370 Models 5/16”...
  • Page 35 (Item 2) [Figure 27] on the upper lift arm (Item 3). (Item 2) [Figure 29] onto the top yoke pin. Narrow Rim Washer Sizes 1-1/2” x 10 Ga. - 1370 Models 1-1/2” x 10 Ga. - 1385 & 1395 Models Cotter Pin Sizes 1/4”...

  • Page 36: 13114 Link And Yoke Assembly

    Install the cylinder pin (Item 1) [Figure 30] through the upper lift arm and cylinder. Narrow Rim Washer Sizes 1-1/2” x 10 Ga. - 1370 Models 2” x 10 Ga. - 1385 & 1395 Models Cotter Pin Sizes 1/4” x 2” - 1370 Models 5/16”...
  • Page 37 Assembly - 13" Backsaver Auger Figure 33 Figure 35 B-0262 B-0264 NOTE: It is recommended to leave the plastic on the Install one 2” narrow rim washer (Item 1) and one 5/ hydraulic cylinders during assembly. This will 16” x 3” cotter pin (Item 2) onto the 2” x 18-7/8” lift help to prevent damage to the paint and pin rod (Item 3) [Figure 35].
  • Page 38 Assembly - 13" Backsaver Auger Figure 37 Figure 39 B-0266 B-0268 Place the right yoke arm (Item 1) on the outside of the Align the RH lower lift arm (Item 1), link (Item 2) and link (Item 2) [Figure 37]. Position cylinder inside the LH lower lift arm (Item 3) [Figure 39].
  • Page 39 Assembly - 13" Backsaver Auger Figure 41 Install the remaining 1/2” x 2” bolts (Item 1) [Figure 42], 1/2” flat washers and 1/2” lock nuts (both sides). Do not tighten bolts and lock nuts at this time. Remove the strap. Figure 43 B-0271 NOTE: Install a chain or strap through the base ends...
  • Page 40 Assembly - 13" Backsaver Auger Figure 45 Figure 47 B-16017 B-0282 Install a strap (Item 1) around the upper lift arm (Item Install one 2” narrow rim washer (Item 1) and 5/16” x 2) [Figure 45]. Connect the strap to an approved 3”...
  • Page 41 Assembly - 13" Backsaver Auger Figure 49 Figure 51 B-0580 B-0264 Install a chain through the mounting hole of the left Install one 2” narrow rim washer (Item 1) and 5/16 x yoke arm (Item 1). Lift the left yoke arm until the right 3”...

  • Page 42: All Models - Tire And Lift Arm Rest Tube Assembly

    B-0495 sides). Install one 2” narrow rim washer (Item 1) and 5/16” x Models 1370, 1385 and 1395 - Install six wheel bolts 3” cotter pin (Item 2) [Figure 54] onto the cylinder pin (both sides) [Figure 56]. rod, securing the cylinders to the upper lift arm.
  • Page 43 Align the left undercarriage arm (Item 1) with the mounting flange (Item 2) on the axle [Figure 58]. Models 1370, 1385 and 1395 - Install four 5/8” x 2” bolts (Item 3) [Figure 58] and 5/8” lock nuts. Do not tighten bolts and nuts at this time.
  • Page 44 Install four 5/8” lock nuts on the bolts. Do 1385 & 1395 Models not tighten at this time. Figure 62 1370, 1385 & 1395 Models B-0814 NOTE: 1385 & 1395 lift arm rest tube mounts on top of the tabs on the LH & RH undercarriage arms.

  • Page 45: Tube Assembly

    Assembly - 13" Backsaver Auger BASE GROUP (CONT’D) Figure 64 Tube Assembly Assemble the tube on flat level surface. B-0817 • DO NOT permit bystanders to be in the work area Install a strap (Item 1) around the top tube (Item 2) when unloading and assembling the auger [Figure 64].
  • Page 46 Assembly - 13" Backsaver Auger Figure 68 When assembling the Model 1395 tube, install the 10 ft. extension tube between the top and center Figure 66 B-0310 When installing the connecting shaft, the shaft will need to be aligned with and inserted into the inner collar (Item 1) [Figure 68] of flighting tube.
  • Page 47 Assembly - 13" Backsaver Auger Figure 70 Figure 72 B-0981 B-0998A Slide the flighting from the center tube forward onto Install a strap (Item 1) [Figure 72] around the end of the connecting shaft. Apply thread locker to the bolt the bottom tube.
  • Page 48 Assembly - 13" Backsaver Auger Figure 74 Figure 76 B-0996A B-0352A Install the chains (Item 1) [Figure 74] onto the input Align the input box flighting (Item 1) with the hole in box gearbox mounting bracket. Raise and move the the bottom tube flighting.

  • Page 49: 1370, 1385 & 1395 Bridging Assembly

    Assembly - 13" Backsaver Auger 1370, 1385 & 1395 Bridging Assembly Figure 79 Locate and uncoil the four 1/2” cables. Place one long and one short 1/2” cable on each side of the tube assembly (longest 1/2” cable towards the outside).
  • Page 50 Raise the tube assembly to allow adequate space for the bridging mount under the main bridging mount. Figure 81 MAIN BRIDGING MOUNTING POSITION Model 1370 B-0997 Position the main bridging yoke mount (Item 1) [Figure 81] below bridging mount.
  • Page 51 Install one main bridging yoke clamp (Item 1) over the tube main bridging yoke mounting. The main bridging yoke, install two 5/8” x 1-3/4” bolts procedure is the same for the 1370 model (Item 2) [Figure 84] with 5/8” flat washers through augers.
  • Page 52 (on the bottom tube) (both sides). Install one 1” x 7/ tube main bridging brace mounting. The 16” x 10 ga. flat washer and nut onto the clamp u- procedure is the same for the 1370 model bolt. Do not tighten the 1/2” cable clamps at this augers.
  • Page 53 Assembly - 13" Backsaver Auger washer and nut onto the clamp u-bolt. Do not tighten Figure 90 the 1/2” cable clamps at this time. Figure 88 B-0863 Locate two cable yoke brackets (Item 1) [Figure 90]. B-0867 Install one 1/2” x 2” bolt (Item 2) through the mounting bracket and cable yoke bracket.
  • Page 54 Assembly - 13" Backsaver Auger Figure 91 Figure 92 B-0864 B-0869 Install one 1/2” x 2” bolt (Item 1) through the Thread the cable through the eyebolt and around the mounting bracket and cable yoke bracket. Install one thimble (both sides). Pull cable as tight as possible. 1/2”...
  • Page 55 Assembly - 13" Backsaver Auger Figure 93 Figure 95 B-0996A B-0872 NOTE: Cable lengths may vary. The following is a starting point and cables may need to be tightened more or loosened depending on the 4 ft. (1.22 m) cable length. Tighten the long cable until there is approximately 3 - GROUND 4 inches (76 - 102 mm) of exposed threads (Item 1)
  • Page 56 Assembly - 13" Backsaver Auger NOTE: The following images may not show your exact Figure 98 bearing assembly as it appears but the procedure is correct. Figure 96 B-0878 Align the spout clamp (Item 1) and discharge spout (Item 2) [Figure 98] with discharge opening in the top B-0373 B-0374 tube.

  • Page 57: 13114 Truss Beam Assembly

    Assembly - 13" Backsaver Auger 13114 Truss Beam Assembly Figure 101 Figure 99 B-16003 B-16064 Install the truss fastener / beam assembly (Item 1) onto the lower tube #1 truss beam mount (Item 2) Install the T-bar (Item 1) as shown, install a bolt and [Figure 101].
  • Page 58 Assembly - 13" Backsaver Auger Figure 103 Figure 105 ANGLE WIDE SIDE NOTCH ANGLE B-16044 B-16045 Raise the truss beam assembly (Item 1) and the truss The truss support brackets (Item 1) [Figure 105] have beam (Item 2) [Figure 103]. one, two, three or four notches and are different lengths.
  • Page 59 Assembly - 13" Backsaver Auger Figure 107 Figure 109 Wide Side B-16028 B-16041 Install the truss beam (Items 1 & 2) [Figure 107] onto Raise and align the truss beam (Item 1), install the 1- the tube #2 truss beam mount. 1/4”...
  • Page 60 Assembly - 13" Backsaver Auger Figure 110 Figure 112 B-16048 B-16047 Install the truss beam (Items 1 & 2) [Figure 110] onto the tube #3 truss beam mount. Raise and align truss beam (Item 1), install the 1-1/4” pin (Item 2), 1-1/4” narrow rim washer and 1/4” x 2” NOTE: The lower truss beam (Item 1) [Figure 110] cotter pin [Figure 112].
  • Page 61 Assembly - 13" Backsaver Auger Figure 114 Figure 116 B-16024 B-16054 Install the 1-1/4” nut (Item 1) onto the truss fastener (Item 2). Install the truss fastener into the truss beam Raise the truss beam assembly (Item 1) and the truss (Item 3) [Figure 114].
  • Page 62 Assembly - 13" Backsaver Auger Figure 118 Figure 120 Wide Side B-16053 B-16056 Align the cross brace plates (Item 1) [Figure 120] Place the truss support bracket (four notches) (Item 1) diagonally with the tabs on the left side and right side [Figure 118] between the left side and right side truss truss beams.
  • Page 63 Assembly - 13" Backsaver Auger With the tube assembly complete, tighten the castle nut (Item 1) until the castle nut contacts the washer / flighting shaft (Item 2) [Figure 121]. Check for cotter pin hole in the shaft. Tighten or back the castle nut off (applying some tension on the flighting) until the closest cotter pin hole(s) is exposed.

  • Page 64: 13114 Truss Beam Identification

    Assembly - 13" Backsaver Auger 13114 Truss Beam Identification Top of Auger Tabs to inside Tabs to inside Tabs to inside Tabs to inside Tabs to inside Bottom of Auger...
  • Page 65 Assembly - 13" Backsaver Auger 83.69” 260” 145.42” 145.42” 262.38” 260” 121.08” 214.19” 53.50”...

  • Page 66: 13114 Cross Brace Plate / Truss Support Bracket Identification

    Assembly - 13" Backsaver Auger 13114 Cross Brace Plate / Truss Support Bracket Identification Top of Auger 4 Notches 3 Notches Qty 2 2 Notches Qty 2 1 Notch Qty 6 Bottom of Auger...
  • Page 67 Assembly - 13" Backsaver Auger 1 Notch 52.24” 2 Notches 64.34” 3 Notches 50.46” 4 Notches 36.64” 103.70” 114.50” 84.85”...

  • Page 68: 1370, 1385 & 1395 Installing Tube On Undercarriage

    Assembly - 13" Backsaver Auger 1370, 1385 & 1395 Installing Tube On Undercarriage Figure 124 Install the tube on the undercarriage on a flat level surface. B-0376 • DO NOT permit bystanders to be in the work area when unloading and assembling the auger With the strap (Item 1) [Figure 124] installed around components.
  • Page 69 Assembly - 13" Backsaver Auger Figure 126 Figure 128 1370, 1385 & 1395 MODELS 1385 & 1395 MODELS B-0886 B-0888 Remove the 5/8” x 1-3/4” bolt (Item 1) [Figure 128], Remove the two 7/16” x 1-1/2” bolts (Item 1) [Figure 5/8”...
  • Page 70 Assembly - 13" Backsaver Auger Figure 130 Figure 132 1370 MODELS B-0892 B-0994 Align upper lift arm (Item 1) with the main bridging Install a strap around the LH or RH lower lift arm. yoke (Item 2) [Figure 130] on the center tube section.
  • Page 71 Assembly - 13" Backsaver Auger Lower the lower lift arm assembly onto the lift arm Figure 135 cradle. Figure 134 B-0961 B-0962 Install grease zerks (Item 1) [Figure 135] in the axle B-0891A end of the LH & RH lower lift arms. With the upper lift arm (Item 1) resting on the lift arm Figure 136 rest (Item 2) [Figure 134] and cradle rest, verify that...
  • Page 72 Assembly - 13" Backsaver Auger Figure 137 B-0964 Install two grease zerks (Item 1) [Figure 137] into the connecting link. Figure 138 B-0965 Install two grease zerks (Item 1) [Figure 138] into the connecting link. Install two grease zerks (Item 2) [Figure 138] into the upper lift arm.

  • Page 73: 13114 Installing Tube On Undercarriage

    Assembly - 13" Backsaver Auger 13114 Installing Tube On Undercarriage Figure 139 Install the tube on the undercarriage on a flat level surface. B-16030 • DO NOT permit bystanders to be in the work area when unloading and assembling the auger With the strap (Item 1) [Figure 139] installed around components.
  • Page 74 Assembly - 13" Backsaver Auger Figure 141 Figure 143 B-16012 B-16038 Raise the front of the undercarriage (Item 1) [Figure Lower the tube assembly and align the holes of the 141] and align the holes of the undercarriage with the tube undercarriage mounting plate (Item 1) and upper mount holes on the tube.
  • Page 75 Assembly - 13" Backsaver Auger Figure 145 Figure 146 B-16011 B-16001 Install the upper lift arm pin (Item 1) [Figure 145] Align the cross brace tube (Item 1) [Figure 146] with through the bridging plate and upper lift arm. the lower cross brace mounts on the left and right undercarriage arms.
  • Page 76 Assembly - 13" Backsaver Auger Place chock blocks in front and behind the tires of the Figure 148 undercarriage to prevent the auger assembly from moving. Figure 147 B-0273 Tighten the sixteen 1/2” bolts (Item 1) and nuts on the torque tube (Item 2) [Figure 148]. B-16039 Tighten the four 1/2”...
  • Page 77 Assembly - 13" Backsaver Auger Figure 149 B-16011 Install one grease zerk (Item 1) [Figure 149] into the upper lift arm. Figure 150 B-16039 Install two grease zerks (Item 1) [Figure 150] into the upper lift arm. Install two grease zerks (Item 2) [Figure 150] into the lower link pivot.

  • Page 78: Installing The Intake Auger

    Assembly - 13" Backsaver Auger Installing The Intake Auger Figure 153 Figure 151 B-0903 Lower the intake auger, align the u-joint (Item 1) with the top gearbox shaft (Item 2) [Figure 153] of the B-0967 input box. Install the intake spacers (Item 1) [Figure 151] on the NOTE: Lubricate top gearbox shaft before lowering top of the input box.

  • Page 79: Hopper Assembly And Installation

    Assembly - 13" Backsaver Auger Figure 155 Hopper Assembly And Installation Figure 157 B-0905 Rotate the intake auger (Item 1) [Figure 155] 90° B-0910 towards the right side of the auger. Install chains (Item 1) onto the hopper (Item 2) [Figure Figure 156 157].
  • Page 80 Assembly - 13" Backsaver Auger Figure 159 Figure 161 B-0498 B-0504 Install a ratchet strap (Item 1) onto the bracket (Item Align the mounting holes on the hopper and intake 2) [Figure 159] on the top of the hopper (connect the auger.
  • Page 81 Assembly - 13" Backsaver Auger Figure 162 Figure 164 B-0448 B-0734 Align the hinged intake auger cover (Item 1) with the Place the rubber edge (Item 1) [Figure 164] inside the outer flange of the hopper. four mounting holes in the hopper. Install four 1/4” x 3/4”...

  • Page 82: Safety Chain Installation

    Assembly - 13" Backsaver Auger Figure 165 Safety Chain Installation Figure 166 B-0449 B-0746 Align the end of the rubber edge with the two holes at the back of the hopper. Install two 1/4” x 1” bolts Install the safety chain loop (Item 1) into the opening (Item 1) [Figure 165] through the hopper and rubber on the bottom side of the hitch, install one 3/4”...

  • Page 83: Hydraulic Hose Holder Installation

    Assembly - 13" Backsaver Auger Hydraulic Hose Holder Installation PTO Driveline Installation Figure 168 Figure 170 B-0722 B-0767 Install the hydraulic hose holder (Item 1) [Figure 168] onto the mounting bracket located on the top of the Push back on the collar (Item 1) [Figure 170] and gearbox (above the hitch).

  • Page 84: Hand Winch And Cable Installation

    Assembly - 13" Backsaver Auger Hand Winch And Cable Installation Figure 173 Figure 172 B-0741 B-0717 Locate the winch cable. Install the open end of the cable (Item 1) [Figure 173] through the slot and over Install the hand winch mounting bracket (Item 1) the pulley on the top of the lift boom.

  • Page 85: Hopper Safety Hook Installation

    Assembly - 13" Backsaver Auger Hopper Safety Hook Installation Figure 176 Do not remove the drum to install the cable. Figure 175 B-0748A Install the quick link (Item 1) through the eye of the hook (Item 2) [Figure 176]. Install the quick link onto the safety chain at the desired location.

  • Page 86: 1370, 1385, 1395 Hydraulic Assembly

    Assembly - 13" Backsaver Auger 1370, 1385, 1395 HYDRAULIC ASSEMBLY Install the 08 MNPT x 08 MNPT 90° elbow into the flow control valve [Figure 177]. Hydraulic Cylinder Hose Installation Install the 08 x 00 MJIC x 08 MNPT hydraulic hose into the 08 FNPT One Way Flow Control Valve [Figure 177].
  • Page 87 Assembly - 13" Backsaver Auger Figure 180 Figure 182 B-0898 B-0405 Locate one 90° elbow (Item 1) [Figure 182] and place Install and tighten the 08 x 010 MJIC x 08 MNPT in a vise. hydraulic hose (Item 1) into the tube (Item 2) [Figure 180] on the center tube section.
  • Page 88 Assembly - 13" Backsaver Auger Figure 184 B-0706 Install hose assembly (Item 1) into the hydraulic tube (Item 2) [Figure 184] on the bottom tube section. Route the hose towards the hitch and install into the hydraulic hose holder.

  • Page 89: 13114 Hydraulic Assembly

    Assembly - 13" Backsaver Auger 13114 HYDRAULIC ASSEMBLY Figure 186 Hydraulic Cylinder Hose Installation When installing and servicing hydraulic systems, clean the work area before assembly or disassembly and keep all parts clean. Always use caps and plugs on hoses, hydraulic tubes and ports to keep dirt out. Dirt can quickly damage the system.
  • Page 90 Assembly - 13" Backsaver Auger Figure 188 Figure 190 B-0395 B-0397 Install and tighten the two hoses from the base ends Locate and install the two hydraulic hoses (Item 1) of the cylinders onto the tee fitting (Item 1) [Figure [Figure 190] on the rod end of the cylinders.
  • Page 91 Assembly - 13" Backsaver Auger Figure 192 Figure 194 B-0398 B-16020 Install and tighten the two hoses from the rod ends of Route the rod end and base end hydraulic hoses up to the cylinders onto the tee fitting (Item 1) [Figure 192]. the hydraulic tubes on the #2 tube (on the right side, just in front of the upper lift arm pin).
  • Page 92 Assembly - 13" Backsaver Auger Figure 196 Figure 198 B-0406 B-0405 Apply teflon tape to the threads (Item 1) of the Locate one 90° elbow (Item 1) [Figure 198] and place hydraulic hose fitting, then install and tighten the male in a vise.

  • Page 93: Hydraulic Mover And Winch (Optional)

    Assembly - 13" Backsaver Auger Figure 199 HYDRAULIC MOVER AND WINCH (OPTIONAL) Hydraulic Control Valve Installation Figure 201 B-16021 Install hose assembly (Item 1) [Figure 199] onto the right side hydraulic tube. B-0758 Install hose / valve assembly (Item 2) [Figure 199] onto the left side hydraulic tube.
  • Page 94 Assembly - 13" Backsaver Auger Figure 203 Figure 205 B-0983 B-0406 Apply teflon tape to the threads (Item 1) of the Install the mounting bracket (Item 1) onto the valve hydraulic hose fitting, then install and tighten the male block using three 1/4” x 2-3/4” bolts, three 1/4” flat quick coupler fitting (Item 2) [Figure 205].

  • Page 95: Hydraulic Winch Installation (Optional)

    Assembly - 13" Backsaver Auger Hydraulic Winch Installation (Optional) Figure 208 Remove the cable from the hand winch (if equipped). Remove the hand winch from the input box (if equipped). Figure 207 B-0463 Align the winch with four holes (Item 1) [Figure 208] in the winch mounting plate on the top of the bottom tube.
  • Page 96 Assembly - 13" Backsaver Auger Figure 210 Figure 211 B-0465 B-0467 Route the winch cable (Item 1) [Figure 211] through Install one lock washer and flat washer onto the four the end pulley of the lift boom, down through the bolts bottom pulley of the lift boom, across the top of the While holding down on the square nut (Item 1) [Figure...
  • Page 97 Assembly - 13" Backsaver Auger Figure 213 Figure 215 B-0469 B-0946 Locate one hose holder clamp weldment (Item 1), one Loop the tail end (Item 1) of the cable and feed back clamp (Item 2), two hose clamps (Item 3), four 3/8” x into the slot, install the wedge (Item 2) [Figure 213] 2”...
  • Page 98 Assembly - 13" Backsaver Auger Figure 216 Figure 218 B-0471 B-0480 Using four bolts (Item 1) (two each side) and lock Install and tighten two 90° elbow fittings (Item 1) nuts, install the winch shield (Item 2) onto the winch [Figure 216] into the winch.

  • Page 99: Hydraulic Wheel Motor And Wheel Installation (Optional)

    Assembly - 13" Backsaver Auger Hydraulic Wheel Motor And Wheel Installation Figure 222 (Optional) Figure 220 LEFT SIDE RIGHT SIDE (LH) (RH) B-0936 Right hand (RH) and left hand (LH) sides of the hopper B-0933 are as viewed from the end of the hopper, looking towards the intake auger (Item 1) [Figure 222].
  • Page 100 Assembly - 13" Backsaver Auger Figure 224 Figure 225 B-0972 B-0974 Locate one hose holder clamp weldment (Item 1), one Locate one hose holder clamp weldment (Item 1), one clamp (Item 2), two hose clamps (Item 3), four 3/8” x clamp (Item 2), two hose clamps (Item 3), four 3/8”...
  • Page 101 Assembly - 13" Backsaver Auger Figure 226 hoses). Tighten the 3/8” lock nut to secure the hoses in the clamps. Figure 228 B-0942 B-0941 Locate one 60” hydraulic hose (Item 1) and two 84” B-0786 hydraulic hoses (Item 2) [Figure 226]. Install the 60”...

  • Page 102: Electric Mover And Winch (Optional)

    Assembly - 13" Backsaver Auger ELECTRIC MOVER AND WINCH (OPTIONAL) Figure 230 Electric Winch Installation NOTE: The following images may not show your winch exactly as it appears but the procedure is correct. Remove the cable from the hand winch (if equipped). Remove the hand winch from the input box (if equipped).
  • Page 103 Assembly - 13" Backsaver Auger Figure 232 Figure 233 B-0465 B-0467 Route the winch cable (Item 1) [Figure 233] through Install one lock washer and flat washer onto the four the end pulley of the lift boom, down through the bolts bottom pulley of the lift boom, across the top of the While holding down on the square nut (Item 1) [Figure...
  • Page 104 Assembly - 13" Backsaver Auger Figure 235 Figure 237 B-0469 B-16059 Locate the upper control box mount (Item 1), lower Loop the tail end (Item 1) of the cable and feed back control box mount (Item 2), six 3/8” x 2-3/4” bolts into the slot, install the wedge (Item 2) [Figure 235] and six 3/8”...

  • Page 105: Electric Wheel Motor And Wheel Installation

    Assembly - 13" Backsaver Auger Figure 239 Electric Wheel Motor And Wheel Installation Figure 241 B-16016 Route the harness (Item 1) [Figure 239] from the B-0933 control box and connect the wires to the winch motor. Secure the harness to the auger tube as shown. Remove the retaining clip (Item 1), washer and tire (Item 2) (intake auger end of the hopper).
  • Page 106 Assembly - 13" Backsaver Auger Figure 243 Figure 245 LEFT SIDE RIGHT SIDE (LH) (RH) B-0936 B-16058 Right hand (RH) and left hand (LH) sides of the hopper Install wiring harness connector (Item1) to right hand (R) electric motor wheel harness connector (Item 2) are as viewed from the end of the hopper, looking [Figure 245] as shown.

  • Page 107: 1000 Rpm Retro Fit Kit

    Assembly - 13" Backsaver Auger Figure 247 1000 RPM RETRO FIT KIT Removing Intake Auger And Hopper • DO NOT permit bystanders to be in the work area B-16058 when unloading and assembling the auger components. Install the two proximity indicators (Items 1) with the •...
  • Page 108 Assembly - 13" Backsaver Auger Figure 249 AVOID INJURY OR DEATH Hydraulic fluid escaping under pressure can have sufficient force to enter a person’s body by penetrating the skin. This can cause serious injury B-0756 and possible death if proper medical treatment by a physician familiar with this injury is not received Disconnect the left and right wheel motor hydraulic immediately.
  • Page 109 Assembly - 13" Backsaver Auger Figure 251 Figure 253 B-0907 B-0851 Remove the two bolts (Item 1) and ring clamp (Item 2) Install chains (Item 1) [Figure 253] inside the input [Figure 251]. Repeat to remove the three remaining box. ring clamps.
  • Page 110 Assembly - 13" Backsaver Auger Figure 255 Figure 257 B-0721A Remove the eight 7/16” x 1-1/4 bolts (Item 1) [Figure 255] and 7/16” lock nuts around the mounting flanges of the bottom tube and input box. Figure 256 B-0829 Lower the input box to the ground with the tube mounting flange flat on the ground [Figure 257].
  • Page 111 Assembly - 13" Backsaver Auger Figure 258 Figure 260 B-0831 B-0991 Remove the four bolts (Item 1), then remove guard Release the two latches (Item 1) and open clean out (Item 2) [Figure 258]. cover (Item 2) [Figure 260]. Loosen the two bolts (Item 3) and remove gearbox Figure 259 access cover (Item 4) [Figure 260].
  • Page 112 Assembly - 13" Backsaver Auger Figure 262 Figure 264 B-0988 B-0990 Remove the bolt (Item 1) [Figure 262] from input box Install straps (Item 1) [Figure 264] through the drive flighting. assembly. Connect the straps to an approved lifting device. Figure 263 Raise and remove the drive assembly from the input box.
  • Page 113 Assembly - 13" Backsaver Auger Figure 266 Install key (Item 3) [Figure 267]. Figure 268 B-0992 B-0988 B-0847 Install the square end of the bar shaft (Item 1) [Figure 266] into the input box flighting. Install a strap (Item 1) around the 1000 RPM gearbox NOTE: Hold on to the bar shaft when installing into the (Item 2) [Figure 268].
  • Page 114 Assembly - 13" Backsaver Auger Figure 269 Figure 271 B-0848 Install the eight bolts (Item 1) [Figure 269] through the B-0847A 1000 PRM gearbox, spacer plate and input box. Install one lock nut on each bolt and tighten. Raise the hitch (Item 1) and align with the mounting tube (Item 2) [Figure 271].
  • Page 115 Assembly - 13" Backsaver Auger Figure 273 B-0352A Align the input box flighting (Item 1) with the hole in the bottom tube flighting. Install bolt (Item 2) [Figure 273] and lock nut. Tighten bolt and lock nut. Figure 274 B-0855 Move the input box towards the bottom tube until the two mounting flanges make contact.
  • Page 116 Assembly - 13" Backsaver Auger...
  • Page 117 Operation - 13" Backsaver Auger OPERATION GENERAL INFORMATION ..........119 Pre - Operation Checklist .
  • Page 118 Operation - 13" Backsaver Auger...

  • Page 119: General Information

    Operation - 13" Backsaver Auger GENERAL INFORMATION 4. Check wheel bolts for tightness. Torque as required. (See “AXLE” on page 149.) Pre - Operation Checklist 5. Check the augers. Remove any material build-up or debris that has become entangled. Before operating the Backsaver Auger for the first time and each time thereafter, check the following 6.

  • Page 120: Break - In Checklist

    Operation - 13" Backsaver Auger Break - In Checklist 1. Check the auger hitch for damaged, loose or missing parts. Repair as needed before operation. NOTE: The Backsaver Auger must have a break-in period with different operating conditions than 2. Check for loose fasteners and hardware. Tighten for normal use.

  • Page 121: Tractor Requirements

    HITCH WEIGHT TOTAL WEIGHT NOTE: A tractor hitch of less than 16” minimum will MODEL result in PTO bottoming out, when operating 1370 1140 lb (518 kg) 5175 lb (2350 kg) auger at maximum height. 1385 1270 lb (577 kg)

  • Page 122: Entering And Leaving The Operator's Position

    Operation - 13" Backsaver Auger Entering And Leaving The Operator’s Position INITIAL SET-UP Connecting The Backsaver Auger To The Tractor Always inspect the tractor’s drawbar and Backsaver Auger hitch before connecting. See the tractor’s owner’s manual. Verify that the tractor’s drawbar is adjusted correctly for use with the Backsaver Auger.

  • Page 123: Connecting The Pto Driveline

    Operation - 13" Backsaver Auger Figure 278 Figure 279 B-0530 B-0728 Install the hitch pin (Item 1) [Figure 279] and retaining pin to securely fasten the Backsaver Auger hitch to Turn the handle (Item 1) [Figure 278] clockwise to the tractor drawbar. raise the hitch or counterclockwise to lower the hitch.
  • Page 124 Operation - 13" Backsaver Auger Figure 280 B-0112 B-0113 Retract the collar and slide the PTO driveline (Item 1) onto the tractor PTO shaft until it locks onto the shaft. Push and pull on the PTO driveline to verify it is securely attached to the PTO shaft.

  • Page 125: Pto Driveline

    Operation - 13" Backsaver Auger PTO Driveline PTO Driveline Bottoming Out Check PTO Driveline Length Check Stop the engine and leave the operator’s position. (See “Leaving The Operator’s Position” on page 122.) NOTE: Due to variations in distances between tractor Make sure the PTO driveline and all rotating PTO shafts and implement input shafts, components have come to a complete stop before...
  • Page 126 Operation - 13" Backsaver Auger Reducing The PTO Driveline Length Figure 282 Stop the engine and leave the operator’s position. Auger PTO (See “Leaving The Operator’s Position” on page 122.) Shaft Make sure the PTO driveline and all rotating components have come to a complete stop before leaving the operator’s position.
  • Page 127 Operation - 13" Backsaver Auger PTO Driveline Engagement Check 3. Multiply the retracted driveline length by 1.667 to determine the PTO driveline Maximum Operating Stop the engine and leave the operator’s position. Length. (i.e.: 25.5 in. (647,7 mm) x 1.667= 42.5 (See “Leaving The Operator’s Position”...

  • Page 128: Connecting Hydraulic Hoses

    Operation - 13" Backsaver Auger Connecting Hydraulic Hoses To Connect: Figure 286 HIGH PRESSURE FLUID HAZARD To prevent serious injury or death from high pressure fluid: • Relieve pressure on system before repairing or B-0531A adjusting. • Wear proper hand and eye protection when Pull back on the collar of the female coupler, push searching for leaks.

  • Page 129: Auger Operation

    Operation - 13" Backsaver Auger AUGER OPERATION Manual Hopper And Winch Winch Operation • Frayed, kinked or damaged wire rope must be replaced immediately. • Always stand clear of wire rope and hopper during operation. • Always stand clear and keep others away during operation.
  • Page 130 Operation - 13" Backsaver Auger Hopper Operation Figure 287 B-0761 Turn the winch handle to raise the hopper and release the safety chain tension. Remove the safety chain hook (Item 1) [Figure 287] from the hopper. Using the winch handle, slowly lower the hopper to the ground.

  • Page 131: Hydraulic Hopper Mover And Winch (If Equipped)

    Operation - 13" Backsaver Auger Hydraulic Hopper Mover And Winch (If Equipped) • Frayed, kinked or damaged wire rope must be replaced immediately. • Always stand clear of wire rope and hopper during operation. • Always stand clear and keep others away during operation.

  • Page 132: Adjusting Flow Control Valve

    Operation - 13" Backsaver Auger Winch Operation Adjusting Flow Control Valve Figure 289 Figure 290 B-0900 B-0786 Turn the knob (Item 1) [Figure 290] on the flow control valve “IN” to decrease the speed the auger Move the lever (Item 1) [Figure 289] down to raise the lowers.

  • Page 133: Auger Placement

    Operation - 13" Backsaver Auger Auger Placement ELECTROCUTION HAZARD • Do not raise the main auger higher than 35° To prevent serious injury or death from electrocution: before lowering the intake auger or interference between the intake auger and the intake box will •...

  • Page 134: Unloading Belly Dump Units

    Operation - 13" Backsaver Auger With the main auger in the fully down position, move Unloading Belly Dump Units the auger towards the bin or barn. Position the auger as close as possible to the bin or barn. Figure 292 Never place blocks under the wheels to increase the elevation of auger.
  • Page 135 Operation - 13" Backsaver Auger Figure 294 Figure 295 B-0538 B-0539 Move the belly dump unit forward until the rear Move the belly dump unit back until the front compartment is directly over the hopper (Item 1) compartment is directly over the hopper (Item 1) [Figure 294].

  • Page 136: Unloading Rear And Side Dump Units

    Operation - 13" Backsaver Auger Unloading Rear And Side Dump Units Rear Dump Units Figure 296 • Do NOT exceed 540 RPM PTO if equipped with chain drive. • Do NOT exceed 1000 RPM PTO if equipped with optional M1000 gearbox. •...
  • Page 137 Operation - 13" Backsaver Auger Side Dump Units Figure 297 • Do NOT exceed 540 RPM PTO if equipped with chain drive. • Do NOT exceed 1000 RPM PTO if equipped with optional M1000 gearbox. • Keep PTO shields and all guards in place. •...

  • Page 138: Transporting

    Operation - 13" Backsaver Auger TRANSPORTING Requirements Never exceed 20 mph (32 kph). ELECTROCUTION HAZARD To prevent serious injury or death from electrocution: • Be aware of overhead power lines. • Keep away from power lines when transporting or raising auger. •...

  • Page 139: Transporting Procedure

    Operation - 13" Backsaver Auger Transporting Procedure Hydraulic Winch Remove all supports on the discharge end and Move the lever (Item 2) [Figure 298] to the left anchoring from the intake end (if required). (towards the hitch) to raise the boom cable (wind cable).
  • Page 140 Operation - 13" Backsaver Auger adequate space for the auger to be lowered into the Figure 302 transport position. Stop the tractor and engage the parking brake. Always lower the auger before transporting and allow the weight of the auger to rest on the undercarriage and not the hydraulic cylinders.

  • Page 141: Maintenance

    Tire / Wheel Replacement ......... . .149 1370, 1385, AND 1395 BRIDGING CABLES ....... .150 Cable Inspection .
  • Page 142 Maintenance - 13" Backsaver Auger...

  • Page 143: Troubleshooting

    Maintenance - 13" Backsaver Auger TROUBLESHOOTING Chart Instructions are necessary before operating or servicing equipment. Read and understand the Operator And Parts Manual and safety signs (decals) on equipment. Follow warnings and instructions in the manuals when making repairs, adjustments or servicing. Check for correct function after adjustments, repairs or service.

  • Page 144: Service Schedule

    Maintenance - 13" Backsaver Auger SERVICE SCHEDULE Maintenance Intervals Maintenance work must be done at regular intervals. Failure to do so will result in excessive wear and early failures. The service schedule is a guide for correct maintenance of the Backsaver Auger. Instructions are necessary before operating or servicing equipment.

  • Page 145: Lubrication

    Maintenance - 13" Backsaver Auger LUBRICATION Locations Recommendations Always use a good quality multi-purpose / lithium base grease when lubricating the equipment. Fluid such as engine oil, hydraulic fluid, coolants, grease, etc. must disposed environmentally safe manner. Some regulations require that certain spills and leaks on the ground must be cleaned in a specific manner.
  • Page 146 Maintenance - 13" Backsaver Auger Lubricate the following grease locations EVERY 50 Figure 307 HOURS: NOTE: The PTO shaft is equipped with extended life bearings. Do not over-grease. Figure 305 B-0732 Apply 1-2 pumps of grease to the universal joint (Item 1) (Item 1) [Figure 307] on the hopper auger drive B-0002 shaft.
  • Page 147 Maintenance - 13" Backsaver Auger Figure 309 Figure 312 B-0797 B-0342 Apply two - three pumps of grease to the connecting link (Item 1) [Figure 312]. Apply 1-2 pumps of grease to the intake hopper drive shaft (Item 1) [Figure 309]. Figure 313 Figure 310 B-0900...

  • Page 148: Hopper Dual Auger Drive Chains

    Maintenance - 13" Backsaver Auger Figure 314 4168 Upper Gearbox Figure 316 B-0259 Apply 1-2 pumps of grease to the RH lower lift arm pivot (Item 1) [Figure 314]. Repeat procedure on the 960950 LH lower lift arm pivot. Hopper Dual Auger Drive Chains Check the gearbox oil level every 50 hours or weekly.

  • Page 149: Axle

    Maintenance - 13" Backsaver Auger AXLE Figure 317 Wheel Lug Nut Torque Check the torque on wheel lug nuts daily. Tighten lug nuts to 120 lb. / ft. (162 N•m) torque. Tire / Wheel Replacement Empty the Backsaver Auger (if required). AVOID INJURY OR DEATH B-0810 Before you leave the operator’s position:...

  • Page 150: 1370, 1385, And 1395 Bridging Cables

    Maintenance - 13" Backsaver Auger 1370, 1385, AND 1395 BRIDGING CABLES Lower And Upper Bridging Cables Cable Inspection Always wear the proper hand and eye protection when serving the equipment. Regularly check the tightness of all cable clamps to AVOID INJURY OR DEATH avoid slipping.
  • Page 151 Maintenance - 13" Backsaver Auger Figure 319 Figure 320 B-0653 B-0762 Remove bolt (Item 1) [Figure 320] and lock nut (from Loosen all cable clamps along the cable being mounting bracket on the bottom tube section), move tightened. the yoke (Item 2) back, one hole. Re-install the bolt and lock nut.

  • Page 152: Safety Sign (Decal) Installation

    Maintenance - 13" Backsaver Auger SAFETY SIGN (DECAL) INSTALLATION Procedure When replacing safety signs (decals), temperature must be above 10° C (50° F). • Remove all portions of the damaged safety sign (decal). • Thoroughly clean the area with glass cleaner. Removing all adhesive residue.

  • Page 153: Storage And Return To Service

    • Place the equipment flat on the ground. Return To Service After the Farm King Backsaver Auger has been in storage, it is necessary to follow a list of items to return the equipment to service. • Be sure all shields and guards are in place.
  • Page 154 Maintenance - 13" Backsaver Auger...

  • Page 155: Parts Identification

    Parts Identification - 13" Backsaver Auger PARTS IDENTIFICATION GENERAL INFORMATION ..........159 13”...
  • Page 156 INPUT BOX (1370, 1385, 1395) ........
  • Page 157 PTO 1370 ........
  • Page 158 Parts Identification - 13" Backsaver Auger...

  • Page 159: General Information

    Maintenance - 13" Backsaver Auger GENERAL INFORMATION The parts identification section lists descriptions, part numbers and quantities for all Backsaver Auger. Contact your Farm King dealer for additional Backsaver Auger parts information. 13” BACKSAVER AUGER Components ITEM DESCRIPTION AXLE UNDERCARRIAGE...

  • Page 160: Bs1370 Undercarriage

    Maintenance - 13" Backsaver Auger BS1370 UNDERCARRIAGE NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 2, 7 1, 9 6, 2, 3 4, 8, 5 919024-B...
  • Page 161 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 812364 LOCK NUT, 1/2” (PL) 812482 LOCK NUT, 5/8” (PL) 812639 WASHER, 5/8” SAE FLAT BS PL 81599 BOLT, 7/16” x 1-1/2” HEX (PL) 84041 FLAT WASHER, 7/16” SAE (PL) 84270 BOLT, 5/8”...

  • Page 162: Lifting Arms - Bs1370

    Maintenance - 13" Backsaver Auger LIFTING ARMS - BS1370 2, 17, 18 2, 11, 18 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. 2, 15, 18 2, 13, 18 4, 6 2, 12, 18 14, 19, 24 1, 3, 5 20, 21, 25...
  • Page 163 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811791 BOLT, 1/2” x 2” HEX (PL) 81210 COTTER PIN, 1/4” x 2” (PL) 812364 LOCK NUT, 1/2” (PL) 812482 LOCK NUT, 5/8” (PL) 81638 FLAT WASHER, 1/2” BS (PL) 84270 BOLT, 5/8”...

  • Page 164: Stub Axle Assembly - Bs1370

    Maintenance - 13" Backsaver Auger STUB AXLE ASSEMBLY - BS1370 906572...
  • Page 165 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 904902 GREASE GRADE 2 906466 STUB AXLE WELDMENT 967713 7/8” SAE FLAT WASHER (BR) 967731 HUB CTD H611 COMPLETE ASSY 9812486 1/8” x 1 1/2” COTTER PIN (BR) 810010 NUT-SLOTTED 7/8” UNF (BR)

  • Page 166: Bs1385 Undercarriage

    Maintenance - 13" Backsaver Auger BS1385 UNDERCARRIAGE NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 7, 1 2, 5 3, 6 2, 4 919020...
  • Page 167 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 812364 LOCK NUT, 1/2” (PL) 812482 LOCK NUT, 5/8” (PL) 81599 BOLT, 7/16” x 1-1/2” HEX (PL) 84270 BOLT, 5/8” x 1-3/4” HEX (PL) 84299 BOLT, 5/8” x 2” HEX GR 5 (PL) 86273 LOCK NUT, 7/16”...

  • Page 168: Lifting Arms - Bs1385

    Maintenance - 13" Backsaver Auger LIFTING ARMS - BS1385 13, 19, 20 2, 10, 17 12, 19, 20 19, 20, 24 4, 6 1, 3, 5 2, 14, 17 13, 19, 20 15, 18, 23 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections.
  • Page 169 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811791 BOLT, 1/2” x 2” HEX (PL) 81210 COTTER PIN, 1/4” x 2” (PL) 812364 LOCK NUT, 1/2” (PL) 812482 LOCK NUT, 5/8” (PL) 81638 FLAT WASHER, 1/2” BS (PL) 84270 BOLT, 5/8”...

  • Page 170: Stub Axle Assembly - Bs1385 / Bs1395

    Maintenance - 13" Backsaver Auger STUB AXLE ASSEMBLY - BS1385 / BS1395 906573...
  • Page 171 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 81207 3/16” x 2” COTTER PIN (BR) 904902 GREASE GRADE 2 906467 STUB AXLE WELDMENT 960586 HUB CTD H618 COMPLETE ASSY 967217 SLOTTED HEX NUT 1.0 NF 967218 1” SAE FLAT WASHER (BR)

  • Page 172: Bs13114 Undercarriage

    Maintenance - 13" Backsaver Auger BS13114 UNDERCARRIAGE NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 2, 5 6, 5 1, 3 927749...
  • Page 173 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811691 BOLT, 1/2” x 6” HEX (PL) 812087 BOLT, 5/8” x 6” HEX (PL) 812364 LOCK NUT, 1/2” (PL) 812365 LOCK NUT, 3/4” (PL) 812482 LOCK NUT, 5/8” (PL) 81672 BOLT, 5/8” x 4-1/2” HEX (PL) 84268 BOLT, 5/8”...

  • Page 174: Lifting Arms - Bs13114

    Maintenance - 13" Backsaver Auger LIFTING ARMS - BS13114 4, 7 1, 6, 3 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. 928575...
  • Page 175 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811791 BOLT, 1/2” x 2” HEX (PL) 81210 COTTER PIN 1/4” x 2” (PL) 812364 LOCK NUT, 1/2” (PL) 812482 LOCK NUT, 5/8” (PL) 81629 BOLT, 1/2” x 3 1/2” HEX (PL) 81638 FLAT WASHER, 1/2”...

  • Page 176: Stub Axle Assembly - Bs13114

    Maintenance - 13" Backsaver Auger STUB AXLE ASSEMBLY - BS13114 909191...
  • Page 177 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 904902 GREASE GRADE 2 28 g 909190 STUB AXLE WELDMENT 92812442 ARROW RIM WASHER, 1-1/4” x 10 GA (BR) 909190 HUB, CTD H817 COMPLETE ASSEMBLY 967252 3/16” x 2-1/2” COTTER PIN (BR) 960037 NUT-SLOTTED, 1-1/4”...

  • Page 178: Tube Layout And Bridging - Bs1370

    Maintenance - 13" Backsaver Auger TUBE LAYOUT AND BRIDGING - BS1370 2, 3 6, 7 8, 9 10, 11 6, 7 14, 15 10, 11 10, 11 8, 9, 16 8, 9, 16 NOTE: Apply general purpose thread locker (ASTM D5363 8, 17 0321) thread...
  • Page 179 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 960612 SPOUT CLAMP, PL 812363 LOCK NUT, 3/8” (PL) 967291 BOLT, 3/8” x 2” FULL THREAD HEX (PL) F9716 DISCHARGE SPOUT, 13” B/S 960677 BRIDGING TIE BAR, 1/4” x 1-1/4” x 31-1/2” PL 964001 FLAT WASHER, 1”...

  • Page 180: Tube Layout And Hydraulics - Bs1370

    Maintenance - 13" Backsaver Auger TUBE LAYOUT AND HYDRAULICS - BS1370 2, 3 15 16, 17 5, 6, 3 7, 8 11, 3 NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 918968...
  • Page 181 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 918739 FLIGHTING SHAFT, SQUARE 910025 BOLT, 1/2” x 4” GR 8 HEX (PL) 812364 LOCK NUT, 1/2” (PL) F1913 BS13 LIFT BOOM ASSEMBLY 81620 BOLT, 1/2” x 1-1/4” HEX (PL) 81638 FLAT WASHER, 1/2”...

  • Page 182: Bs1370 Top Tube Assembly

    Maintenance - 13" Backsaver Auger BS1370 TOP TUBE ASSEMBLY NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 1, 3 4, 7 1, 3 F1919...
  • Page 183 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 812026 BOLT, 5/16” x 1” HEX (PL) 81210 COTTER PIN, 1/4” x 2” (PL) 812362 LOCK NUT, 5/16” (PL) 904902 GREASE, GRADE 2 918816L TOP FLIGHTING ADJUSTMENT PLATE 918817 TOP PLATE WELDMENT 918828 TOP FLANGE CAP WELDMENT 918969...

  • Page 184: Bs1370 Bottom Tube Assembly

    Maintenance - 13" Backsaver Auger BS1370 BOTTOM TUBE ASSEMBLY NOTE: Apply general purpose thread locker (ASTM D5363 3, 1 0321) thread connections. F1917_0 ITEM PART NUMBER DESCRIPTION 812363 LOCK NUT, 3/8” (PL) 812711 JIC UNION -10-10 86170 BOLT, 3/8” x 1” HEX GR.5 (PL) 918752 BS1370 BOTTOM FLIGHTING WELDMENT 918974...

  • Page 185: Bs1370 Center Tube Assembly

    Maintenance - 13" Backsaver Auger BS1370 CENTER TUBE ASSEMBLY NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. F1918 ITEM PART NUMBER DESCRIPTION 918973 BS1370 CENTER TUBE WELDMENT 918975 BS1370 CENTER FLIGHTING WELDMENT...

  • Page 186: Tube Layout And Bridging - Bs1385

    Maintenance - 13" Backsaver Auger TUBE LAYOUT AND BRIDGING - BS1385 5, 6 5, 6 8, 9 10, 11 10, 11 12, 13 30, 27 8, 9 5, 6 29 23 26, 27, 28 24, 25 8, 9 9, 8 10, 11, 15 11, 15, 34, 35 10, 18...
  • Page 187 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION F1908 BS1385 TOP TUBE ASSEMBLY F1907 BS1385 CENTER TUBE ASSEMBLY F1906 BS1385 BOTTOM TUBE ASSEMBLY 960678 BRIDGING TIE BAR, PL 1/4” x 1-1/4” x 34” 964001 FLAT WASHER, 1” x 7/16” x 10 GA (PL) 964565 CABLE CLAMP, 1/2”...

  • Page 188: Tube Layout And Hydraulics - Bs1385 / Bs1395

    Maintenance - 13" Backsaver Auger TUBE LAYOUT AND HYDRAULICS - BS1385 / BS1395 6, 7 2, 3 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. 918802...
  • Page 189 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 918739 FLIGHTING SQUARE SHAFT 910025 BOLT, 1/2” x 4” GR8 HEX (PL) 812364 LOCK NUT, 1/2” (PL) F9716 13” B/S DISCHARGE SPOUT 960612 SPOUT CLAMP PLATE 812363 LOCK NUT, 3/8” (PL) 967291 BOLT, 3/8”...

  • Page 190: Bs1385 Top Tube Assembly

    Maintenance - 13" Backsaver Auger BS1385 TOP TUBE ASSEMBLY 4, 14 15, 16 1, 3 1, 3 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. F1908 ITEM PART NUMBER DESCRIPTION 812026 BOLT, 5/16” x 1” HEX (PL) 81210 COTTER PIN, 1/4”...

  • Page 191: Bs1385 Bottom Tube Assembly

    Maintenance - 13" Backsaver Auger BS1385 BOTTOM TUBE ASSEMBLY 3, 1, 8 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. F1906 ITEM PART NUMBER DESCRIPTION 812363 LOCK NUT, 3/8” (PL) 812711 JIC UNION, #10 x #10 86170 BOLT, 3/8”...

  • Page 192: Tube Extension 10' And Bridging - Bs1395

    Maintenance - 13" Backsaver Auger TUBE EXTENSION 10’ AND BRIDGING - BS1395 4, 6 5, 2 4, 6 1, 12 6, 3 NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 918840...

  • Page 193: Bs13 10' Extension Assembly

    Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 812364 LOCK NUT, 1/2” (PL) 812482 LOCK NUT, 5/8” (PL) 81598 7/16” x 1-1/4” HEX BOLT (PL) 81599 7/16” x 1-1/2” HEX BOLT (PL) 84270 5/8” x 1-3/4” HEX BOLT (PL) 86273 LOCK NUT, 7/16”...

  • Page 194: Tube Layout - Bs13114

    Maintenance - 13" Backsaver Auger TUBE LAYOUT - BS13114 26, 2 14, 10, 10, 6 16, 3 3, 9, 7 3, 8 13, 5, 4 F - F E - E 12, 11, 3 NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread 17, 22...
  • Page 195 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 812208 NIPPLE 1/2" BODY 1/2"-14 NPTF QUICK CONNECT 812363 3/8" LOCK NUT (PL) 812364 1/2" LOCK NUT (PL) 812482 5/8" LOCK NUT (PL) 812639 WASHER 0.625 SAE FLAT BS PL 81599 7/16"...

  • Page 196: Bs13114 Tube #4 (Top) Assembly

    Maintenance - 13" Backsaver Auger BS13114 TUBE #4 (TOP) ASSEMBLY 1, 3 3, 18 4, 14 1, 3 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. F2165 ITEM PART NUMBER DESCRIPTION 812026 5/16" X 1" HEX BOLT (PL) 81210 1/4"...

  • Page 197: Bs13114 Tube #1 (Bottom) Assembly

    Maintenance - 13" Backsaver Auger BS13114 TUBE #1 (BOTTOM) ASSEMBLY NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. F2162 ITEM PART NUMBER DESCRIPTION 812711 JIC UNION -10-10 81523 1/4" X 1/2" HEX BOLT (PL) 81549 5/16"...

  • Page 198: Tube Bridging - Bs13114

    Maintenance - 13" Backsaver Auger TUBE BRIDGING - BS13114 5, 3 2, 6, 10 28, 27, 9 NOTE: Apply general purpose 2, 6, 26 thread locker (ASTM D5363 0321) thread connections. 928085A...
  • Page 199 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION EZBN125 NUT HEX 1-1/4” NC GR2 ZNCR 81210 1/4” x 2” COTTER PIN (PL) 812364 1/2” LOCKNUT (PL) 84277 1/2” x 1-1/2” HEX BOLT (PL) 87553 1/2” x 1-3/4” HEX BOLT UNC GR 5 (PL) 9812487 1-1/4”...

  • Page 200: Tube Bridging - Bs13114

    Maintenance - 13" Backsaver Auger TUBE BRIDGING - BS13114 TOP OF AUGER INSIDE HOLE (Two Places) 3, 1, 2 4, 3 OUTSIDE HOLE (Two Places) OUTSIDE HOLE (Two Places) INSIDE HOLE (Two Places) BOTTOM OF AUGER OUTSIDE HOLE (Two Places) NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections.
  • Page 201 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811691 BOLT, 1/2” x 4-1/2” HEX (PL) 905736 UNDERCARRIAGE PIN SLEEVE, 3-1/6”ID x 3-1/2” OD x 1-1/2” 812364 LOCK NUT, 1/2” (PL) 84277 BOLT, 1/2” x 1-1/2” HEX (PL)

  • Page 202: Intake Auger

    Maintenance - 13" Backsaver Auger INTAKE AUGER 1, 3, 6 2, 7 4, 5 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. 918803...
  • Page 203 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 12780 HAIR PIN CLIP, #7 812365 LOCK NUT, 3/4” (PL) 812639 WASHER, 0.625” SAE FLAT BS PL 81636 NUT, 1/2” HEX (PL) 914449 HOPPER ADJUSTMENT, WELDMENT 918914 PIVOT PIN, WELDMENT 967437 BOLT, 3/4”...

  • Page 204: Intake Auger Assembly

    Maintenance - 13" Backsaver Auger INTAKE AUGER ASSEMBLY 11, 3 4, 1 7, 2 3, 6 2, 3, 8 5, 12, 9, 10 ALIGN CENTER OF DOUBLE JOINT WITH CENTERLINE OF PIVOT NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections.
  • Page 205 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811752 1/2” x 4” HEX BOLT (PL) 811792 3/8” X 1 1/2” HEX BOLT GR.5 (PL) 812363 3/8” LOCK NUT (PL) 812364 1/2” LOCK NUT (PL) 812365 3/4” LOCK NUT (PL) 813517 3/8”...

  • Page 206: Input Box Elbow Assembly - Bs13

    Maintenance - 13" Backsaver Auger INPUT BOX ELBOW ASSEMBLY - BS13 3, 6 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. 917552 ITEM PART NUMBER DESCRIPTION 81525 BOLT, 1/4” x 3/4” HEX (PL) 81620 BOLT, 1/2”...

  • Page 207: Intake Auger Tube Assembly

    Maintenance - 13" Backsaver Auger INTAKE AUGER TUBE ASSEMBLY 1, 6 1, 3 1, 4, 5 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. 918818 ITEM PART NUMBER DESCRIPTION 812363 LOCK NUT, 3/8” (PL) 918978 HANGER BRACKET, WELDMENT 813517...

  • Page 208: Input Box (1370, 1385, 1395)

    Maintenance - 13" Backsaver Auger INPUT BOX (1370, 1385, 1395) 3, 9 1, 3, 7 19 14 22, 20, 5, 10 18, 12 3, 7, 9 4, 8 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections.
  • Page 209 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811792 3/8" X 1 1/2" HEX BOLT GR.5 (PL) 81210 1/4" X 2" COTTER PIN (PL) 812363 3/8" LOCK NUT (PL) 812365 3/4" LOCK NUT (PL) 814433 WARRANTY REGISTRATION MANUAL 81549 5/16"...

  • Page 210: Bs13 Input Box Assembly

    Maintenance - 13" Backsaver Auger BS13 INPUT BOX ASSEMBLY NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 41, 38 3, 10 4, 11 29 4, 14 37, 41 9, 4, 8 2, 22 34, 7 4, 14 22, 2 5, 1 F1931...
  • Page 211 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811790 3/4" X 4 1/2" HEX BOLT GR5 (PL) 812362 5/16" LOCK NUT (PL) 812363 3/8" LOCK NUT (PL) 812364 1/2" LOCK NUT (PL) 812365 3/4" LOCK NUT (PL) 81620 1/2" X 1 1/4" HEX BOLT PL 81676 5/8"...

  • Page 212: Input Box Assembly (13114)

    Maintenance - 13" Backsaver Auger INPUT BOX ASSEMBLY (13114) NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 42, 37 2, 9 3, 10 3, 13 32, 6 36, 42 8, 3, 7 20, 1 12 15 17 13, 3 40, 39 1, 20...
  • Page 213 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 812362 LOCK NUT, 5/16” (PL) 812363 LOCK NUT, 3/8” (PL) 812364 LOCK NUT, 1/2” (PL) 81525 BOLT, 1/4” x 3/4” HEX (PL) 81620 BOLT, 1/2” x 1-1/4” HEX (PL) 81676 NUT, 5/8” HEX (PL) 84048 FLAT WASHER, 1/2”...

  • Page 214: Idler Assembly

    Maintenance - 13" Backsaver Auger IDLER ASSEMBLY NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 8, 1 5, 9, 6 919378...
  • Page 215 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 812363 3/8” LOCK NUT (PL) 919363 SHAFT, REVERSE PTO 919368 BEARING FLANGE, 2-BOLT (PL) 919379 WELDMENT, IDLER 919438 H80B9 SPROCKET (1.375 BORE) 960180 U-JOINT & SPROCKET KEY 0.313” SQ. x 1.375” 965917 1-3/8”...

  • Page 216: Single Flighting Hopper

    Maintenance - 13" Backsaver Auger SINGLE FLIGHTING HOPPER NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 6, 3 4, 2, 1, 7 3, 6 3, 5, 6 918843...
  • Page 217 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 812026 BOLT, 5/16” x 1” HEX (PL) 812362 LOCK NUT, 5/16” (PL) 812363 LOCK NUT, 3/8” (PL) 81546 FLAT WASHER, 5/16” (PL) 84039 FLAT WASHER, 3/8” (PL) 86170 BOLT, 3/8” x 1” HEX GR 5 (PL) 910898 CAGE MOUNTING PLATE 911040...

  • Page 218: Single Flighting Hopper

    Maintenance - 13" Backsaver Auger SINGLE FLIGHTING HOPPER 3, 4 3, 4 1, 3, 4 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. 918804 ITEM PART NUMBER DESCRIPTION 812624 FLAT WASHER, 1/4” (PL) 81525 BOLT, 1/4”...

  • Page 219: Single Flighting Hopper

    Maintenance - 13" Backsaver Auger SINGLE FLIGHTING HOPPER 5, 2 1, 3 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. F1916 ITEM PART NUMBER DESCRIPTION 811746 BOLT, 3/4” x 7.5” HEX 812363 LOCK NUT, 3/8” (PL) 812365 LOCK NUT, 3/4”...

  • Page 220: Multi Flighting Hopper

    Maintenance - 13" Backsaver Auger MULTI FLIGHTING HOPPER 3, 4 3, 4 1, 3, 4 NOTE: Apply general purpose thread locker (ASTM D5363 AN 0321) to all thread connections. 918805...
  • Page 221 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 812624 FLAT WASHER, 1/4” (PL) 81525 BOLT, 1/4” x 3/4” HEX (PL) 81527 BOLT, 1/4” x 1” HEX (PL) 84498 LOCK NUT, 1/4” (PL) 911359 RUBBER HOPPER EDGING 918850 INTAKE ACCESS, WELDTMENT 960180 U-JOINT &...

  • Page 222: Multi-Flighting Hopper Assembly

    Maintenance - 13" Backsaver Auger MULTI-FLIGHTING HOPPER ASSEMBLY NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 4, 6, 1 5, 3, 2, 14 4, 6, 1 4, 7 918841...
  • Page 223 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811792 BOLT, 3/8” x 1-1/2” HEX BOLT GR 5 (PL) 812026 BOLT, 5/16” x 1” HEX (PL) 812362 LOCK NUT, 5/16” (PL) 812363 LOCK NUT, 3/8” (PL) 81546 FLAT WASHER, 5/16” (PL) 81570 FLAT WASHER, 3/8”...

  • Page 224: Multi-Flighting Hopper Assembly

    Maintenance - 13" Backsaver Auger MULTI-FLIGHTING HOPPER ASSEMBLY 2, 6 NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. F1915...
  • Page 225 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811746 BOLT, 3/4” x 7” HEX (PL) 812363 LOCK NUT, 3/8” (PL) 812365 LOCK NUT, 3/4” (PL) 81525 BOLT, 1/4” x 3/4” HEX (PL) 84072 BOLT, 3/8” x 3/4” HEX (PL) 86170 BOLT, 3/8”...

  • Page 226: Bs13 Lift Boom Assembly

    Maintenance - 13" Backsaver Auger BS13 LIFT BOOM ASSEMBLY NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 9, 1 12, 11 6, 14 13, 8 F1913_0...
  • Page 227 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 905821 PIN WELDMENT, 0.750” DIA 914619 PULLEY HOLDER WELDMENT 918822 BOOM ARM WELDMENT 918823 HOPPER LIFT ARM MOUNT WELDMENT 960041 HOOK WITH LATCH 960111 CYLINDER PIN WELDMENT, 1.000” DIA 960167 QUICK LINK (PL) 960913 CLEVIS PIN,1/2”...

  • Page 228: Pto 1370

    CV CEN. HOUSING (13" TF) 936364 KIT (BRG&SNAP RING-WSLR)-13" 936319 KIT, BRG & SN. RING (WSLR) 936362 YOKE & TUBE (13" AUGER) 936274 YOKE & BAR 73-96SB&1370 936363 INNER GUARD (13" AUGER) 936273 SHLD OUTR 73-96SB &1370 F9552 PTO SHAFT,CV-13"(2-6 SPL ENDS) 936566...

  • Page 229: Pto 1385, 1395, 13114

    ITEM PART NUMBER DESCRIPTION 936432 SHEAR ASSY 13X85MD 936199 LOCK REPAIR KIT SB & BS 936249 SHEAR KIT 73-108SB&1370 903297 10 SHEAR BOLTS 0.31NCGR8 W/NUT 10 812362 NUT LOCK (STEEL) 0.313NC GRBPL 906505 REPAIR KIT 55E EXTLIFE 936431 YOKE 1 3/8 X 6 SPL (FOR F9554)
  • Page 230 Maintenance - 13" Backsaver Auger M1000 GEARBOX (OPTION) 2, 1 6, 4 NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 918939 (11-16)
  • Page 231 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811829 BOLT, 1/2” x 7” HEX (PL) 812364 LOCK NUT, 1/2” (PL) 84270 5/8” X 1-3/4” HEX BOLT (PL) 904578 GEAR OIL, SAE 75W-90 SYNTHETIC 2.5L 906073 WASHER, INPUT BOX SHAFT 21/32” ID x 3” OD x 1/2” 910927 GEARBOX, M1000 HELICAL 910947...

  • Page 232: Bs13 Hydraulic Mover And Winch (Option)

    Maintenance - 13" Backsaver Auger BS13 HYDRAULIC MOVER AND WINCH (OPTION) NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 4, 7 4, 2 29, 4 (To Quick Connect Fitting) (To RH Side Mover) 20, 5, 6 21 (To Hydraulic Valve) (To Winch Motor) 918950...
  • Page 233 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811748 ADAPTOR, #12 MORB x #8 MJIC 811792 BOLT, 3/8” x 1 1/2” HEX GR.5 (PL) 812208 NIPPLE, 1/2” BODY 1/2”-14 NPTF QUICK CONNECT 812363 LOCK NUT, 3/8” (PL) 812624 FLAT WASHER, 1/4” PL 84498 LOCK NUT, 1/4”...

  • Page 234: Bs13 Hydraulic Winch (Option)

    Maintenance - 13" Backsaver Auger BS13 HYDRAULIC WINCH (OPTION) 5, 8 2, 5 5, 25 (To Quick Connect Fitting) 18, 6, 7 (To Quick Connect Fitting) 19 20 (To Winch Motor) NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections.
  • Page 235 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811748 ADAPTOR, #12 MORB x #8 MJIC 811792 BOLT, 3/8” x 1 1/2” HEX GR.5 (PL) 811970 PLUG, #10 (7/8”) MORB STEEL 812208 NIPPLE, 1/2” BODY 1/2”-14 NPTF QUICK CONNECT 812363 LOCK NUT, 3/8”...

  • Page 236: Bs13 Hydraulic Mover (Option)

    Maintenance - 13" Backsaver Auger BS13 HYDRAULIC MOVER (OPTION) 14 (To Quick Connect Fitting) (To Quick Connect Fitting) 2, 4 2, 4 10 (To RH Mover Motor) 1 (To Valve Assembly) NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections.
  • Page 237 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811484 HOSE, #8 x #8 MNPT x #8 SWFJIC 811792 BOLT, 3/8” x 1 1/2” HEX GR.5 (PL) 812208 NIPPLE, 1/2” BODY 1/2”-14 NPTF QUICK CONNECT 812363 LOCK NUT, 3/8” (PL) 902200 3-BOLT CLAMP, 12 GA 902207...

  • Page 238: Hydraulic Mover Valve Assembly

    Maintenance - 13" Backsaver Auger HYDRAULIC MOVER VALVE ASSEMBLY NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 2, 4 919463...
  • Page 239 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 811469 STRAIGHT ADAPTOR, #8 MNPT x #8 MNPT 81530 BOLT, 1/4” x 1-3/4” HEX GR 5 (PL) 81913 CAP PLUG, 1/2” NPT 84498 LOCK NUT, 1/4” (PL) 902204 VALVE MOUNT CLAMP WELDMENT 908995 4 WAY DIRECTIONAL CONTROL VALVE (AO) 914930...

  • Page 240: Bs Safety Light Kit (Option)

    Maintenance - 13" Backsaver Auger BS SAFETY LIGHT KIT (OPTION) 4, 2 11, 3, 1 NOTE: Apply general purpose thread locker (ASTM D5363 0321) thread connections. 918966...
  • Page 241 Maintenance - 13" Backsaver Auger ITEM PART NUMBER DESCRIPTION 812363 LOCK NUT, 3/8” (PL) 81527 BOLT, 1/4” x 1” HEX (PL) 84000 FLAT WASHER, 7/16” (PL) 84498 LOCK NUT, 1/4” (PL) 912830 LOCTITE, 242 BLUE 0.02 OZ (0.5 ml) 919052 WIRE HARNESS, AG ECONOMY EXT, 10’...
  • Page 242 Maintenance - 13" Backsaver Auger...

  • Page 243: Shipping Kit And Bundle Numbers

    Shipping Kit and Bundle Numbers - 13" Backsaver Auger SHIPPING KIT AND BUNDLE NUMBERS SHIPPING KIT AND BUNDLE NUMBERS ........245 Y1370TMR 13”...
  • Page 244 Shipping Kit and Bundle Numbers - 13" Backsaver Auger...

  • Page 245: Shipping Kit And Bundle Numbers

    F1926 WELDT-LH UNDERCARRIAGE ARM F1931 ASSY-BS13 INPUT BOX F1933 WELDT-BS1370 AXLE F1936 1370 BS CRATE OF PARTS F1938 BS13” SINGLE FLT HOPPER CARTON F9707 UPPER LIFT 13” x 70’ Y1370TMMR 13” x 70’ Backsaver Auger W/Multi-Flighting Hopper BUNDLE NUMBER DESCRIPTION F0210 WHEEL 15”...

  • Page 246: Y1385Tmr 13" X 85' Backsaver Auger W/Single Flighting Hopper

    Shipping Kit and Bundle Numbers - 13" Backsaver Auger Y1385TMR 13” x 85’ Backsaver Auger W/Single Flighting Hopper BUNDLE NUMBER DESCRIPTION F0211 WHEEL 15” x 8” x 6 BOLT F1460 AXLE TUBE WELDMENT F1480 RIGHT UNDERCARRIAGE ARM F1481 LEFT UNDERCARRIAGE ARM F1769 LOWER LIFT ARM - LH F1770...

  • Page 247: Pbmy13114E 13" X 114' Backsaver Auger W/Electric

    Shipping Kit and Bundle Numbers - 13" Backsaver Auger PBMY13114E 13” x 114’ Backsaver Auger W/Electric BUNDLE NUMBER DESCRIPTION F0679 WHEEL 16.5”, TIRE ASSEMBLY 16” F1767 LOWER LIFT ARM WELDMENT - LH F1768 LOWER LIFT ARM WELDMENT - RH F1911 13”...

  • Page 248: Pbmy13114H 13" X 114' Backsaver Auger W/Hydraulics

    Shipping Kit and Bundle Numbers - 13" Backsaver Auger PBMY13114H 13” x 114’ Backsaver Auger W/Hydraulics BUNDLE NUMBER DESCRIPTION F0679 WHEEL 16.5”, TIRE ASSEMBLY 16” F1767 LOWER LIFT ARM WELDMENT - LH F1768 LOWER LIFT ARM WELDMENT - RH F1911 13”...

  • Page 249: Optional Bundle Numbers

    Shipping Kit and Bundle Numbers - 13" Backsaver Auger OPTIONAL BUNDLE NUMBERS The following is a list of options available for the Standard Kits. Options Available BUNDLE NUMBER DESCRIPTION F0014 REFLECTIVE SAFETY DECAL KIT F0018 OPTION-SAFETY LIGHT KIT F0923 CLEVIS HITCH F0946 CLOSED CENTER HOPPER MOVER VALVE KIT F1940...
  • Page 250 Shipping Kit and Bundle Numbers - 13" Backsaver Auger...

  • Page 251: Specifications

    Dimensions (1370) ........
  • Page 252 Specifications - 13" Backsaver Auger...
  • Page 253 Specifications - 13" Backsaver Auger SPECIFICATIONS Dimensions (1370) 8° (18) DESCRIPTION 1370 Overall Width (A) 156 in. Discharge Spout Height @ 42° Angle (B) 593 in. Discharge Spout Height @ 26° Angle (C) 388 in. Discharge Spout Height @ 8° Angle (D) 153 in.
  • Page 254 Specifications - 13" Backsaver Auger Dimensions (1385 & 1395 Models) 6° (18) DESCRIPTION 1385 1395 Overall Width (A) 156 in. 156 in. Discharge Spout Height @ 42° Angle (B) 701 in. 763 in. Discharge Spout Height @ 24° Angle (C) 424 in.
  • Page 255 Specifications - 13" Backsaver Auger Dimensions (13114 Models) 5° DESCRIPTION 13114 Overall Width (A) 173 in. Discharge Spout Height @ 36° Angle (B) 839 in. Discharge Spout Height @ 21° Angle (C) 514 in. Transport Height (D) 131 in. Discharge Spout To Wheels @ 5° Angle (E) 763 in.
  • Page 256 Specifications - 13" Backsaver Auger Performance DESCRIPTION 1370 1385 1395 13114 Size 13” x 70’ 13” x 85’ 13” x 95’ 13” x 114’ Tubing All Sections 12 Gauge Flighting 1/4” Flighting in Swing-Away And Main Auger Flighting Shaft 11 Gauge - 2-3/8” Diameter Undercarriage 3-1/2”...
  • Page 257 Specifications - 13" Backsaver Auger HARDWARE TORQUE VALUES Metric Chart NOTE: Do not use the values listed in the charts if a different torque value or tightening procedure is specified in this manual for a specific application. Torque values listed are for general use only. Use the following charts to determine the correct torque when checking, adjusting or replacing hardware.
  • Page 258 Specifications - 13" Backsaver Auger HARDWARE TORQUE VALUES (CONT’D) Imperial Chart NOTE: Do not use the values listed in the charts if a different torque value or tightening procedure is specified in this manual for a specific application. Torque values listed are for general use only. Use the following charts to determine the correct torque when checking, adjusting or replacing hardware.
  • Page 259 Specifications - 13" Backsaver Auger HYDRAULIC CONNECTION SPECIFICATIONS Port Seal (O-ring Boss) Fitting O-Ring Fitting (Straight Thread) Figure 323 Lubricate the O-ring before installing the fitting. Port Seal And O-ring Boss Tightening Torque Loosen the jam nut and install the fitting. Tighten the jam nut until the washer is tight against the surface.
  • Page 260 Specifications - 13" Backsaver Auger...

  • Page 261: Warranty

    Warranty - 13" Backsaver Auger WARRANTY WARRANTY ............263...
  • Page 262 Warranty - 13" Backsaver Auger...
  • Page 263 If Farm King determines that it will pay labor costs for warranty work, it will do so by issuing a credit to the dealer’s or distributor’s account.
  • Page 264 Limited Warranty WARRANTY REQUIREMENTS To be covered by warranty, each new product must be registered with Farm King within thirty (30) days of delivery to original retail purchaser. If the customer decides to purchase replacement components before the warranty disposition of such components is determined, Farm King will bill the customer for such components and then credit the replacement invoice for those components later determined to be covered by this limited warranty.

  • Page 265: Alphabetical Index

    BS1370 CENTER TUBE ASSEMBLY . . .185 PTO - 1370 ....228 BS1370 TOP TUBE ASSEMBLY ..182 PTO - 1370 .
  • Page 266 Alphabetical Index - 13" Backsaver Auger STORAGE AND RETURN TO SERVICE . 153 STUB AXLE ASSEMBLY - BS13114 . . . 176 STUB AXLE ASSEMBLY - BS1370 ..164 STUB AXLE ASSEMBLY - BS1385 / BS1395 TRANSPORTING ....138 TROUBLESHOOTING .
  • Page 268 www.farm-king.com 301 Mountain Street South Morden, Manitoba Canada R6M 1X7 Toll Free: 1-888-FK-80001 E-mail: info@buhler.com www.farm-king.com Equipment shown is subject to change without notice. ©2018 Buhler Trading Inc. Printed in Canada TSX:BUI...

This manual is also suitable for:

1395131141385

Table of Contents

Save PDF
