Menu Button
Objective
Lens
Green LED
Slope
Indicators
Cart Magnet
6
Measure Button
Diopter Focus
Ocular Lens
Battery
Compartment

BASIC OPERATION

Battery Installation & Replacement
To insert a new battery, flip up
the finger tab on the Battery Cap
and unscrew, counterclockwise,
to remove. Insert a CR2 battery
with the positive side (+) facing
outwards. Reinstall the Battery Cap
and ensure it is tightly closed.
Power Up
Once the battery is installed,
the Blade Slope is in ready
™
condition – the normal power-off
condition when not ranging. To
power up the Blade Slope from
™
the ready condition, press and
release the "Measure" button.
The ranging screen will display.
Note: The Blade Slope will auto-shutoff after 10 seconds if no
™
buttons are pressed. While in the menu, the Blade
to the ranging screen after 30 seconds if no buttons are pressed.
BLADE
™
SLOPE
Battery Cap Battery Cap
Slope will return
™
