Air Lift WirelessONE EZ Mount Installation Manual

Introduction
DANGER
WARNING
CAUTION
MN-1077 • (032206) • ECR 10025
WirelessONE™ EZ Mount™ combines a manifold and compressor into a single,
easy-to-install unit, along with wiring harness and accessories needed to connect to
vehicle power and air springs (purchased separately).
IMPORTANT: PLEASE READ BEFORE INSTALLING
IT IS IMPORTANT TO READ AND UNDERSTAND THE ENTIRE INSTALLATION GUIDE
BEFORE BEGINNING INSTALLATION OR PERFORMING ANY MAINTENANCE,
SERVICE OR REPAIR. THE INFORMATION HERE INCLUDES A HARDWARE LIST,
STEP-BY-STEP INSTALLATION INFORMATION AND SAFETY INFORMATION.
USING THE SYSTEM
Refer to the WirelessONE™ User Guide included with this
kit to learn how to operate the system, connect the wireless
controller and connect your mobile device to the system.
Manifold
NOTATION EXPLANATION
Hazard notations highlight information that must be observed to help minimize risk of
personal injury or possible improper installation, which may render the vehicle unsafe.
INDICATES IMMEDIATE HAZARDS WHICH WILL RESULT IN SEVERE PERSONAL
INJURY OR DEATH.
INDICATES HAZARDS OR UNSAFE PRACTICES WHICH COULD RESULT IN SEVERE
PERSONAL INJURY OR DEATH.
INDICATES HAZARDS OR UNSAFE PRACTICES WHICH COULD RESULT IN DAMAGE
TO THE MACHINE OR MINOR PERSONAL INJURY.
TOOLS LIST
Description ................................................. Qty
Power drill .............................................................1
1/4", 3/8" Drill bits ..........................................1 ea.
Grinder ..................................................................1
Kit Number
25980EZ
EZ Mount Compressor System
Installation Guide
WirelessOne User Guide
Compressor
Description ................................................. Qty
3/8", 1/2", 5/16", 9/16" Sockets & ratchet .....1 ea.
Wire stripping/crimping tool .................................1
Sharp razor knife ..................................................1
User Guide
1
