BioStation 2
USER GUIDE
Version 1.41
English
EN 102.00.BS2 V1.41

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BioStation 2 and is the answer not in the manual?

Questions and answers

Related Manuals for suprema BioStation 2

Summary of Contents for suprema BioStation 2

  • Page 1 BioStation 2 USER GUIDE Version 1.41 English EN 102.00.BS2 V1.41...

  • Page 2: Table Of Contents

    CONTENTS Safety instructions Authentication Instructional icons Finger Card Introduction Components T&A Mode Name and function of each part Fingerprint Cables and connectors How to enroll a fingerprint Display & Sound Admin Menu Device All Menus Date & Time Quick Menu Daylight Saving Time User ID Type User...
  • Page 3 CONTENTS Network FCC compliance information TCP/IP Settings Server Settings EU Declaration of Conformity (CE) RS- 485 Settings Appendices Event Log Disclaimers Search Log Copyright notice Delete All Logs Open Source License View Log Usage GNU General Public License TERMS AND CONDITIONS GNU Lesser General Public License Troubleshooting OpenSSL License...

  • Page 4: Safety Instructions

    Safety instructions Please read this safety instructions before you use the product to prevent injury to yourself and others and to prevent property damage. The term ‘product’ in this manual refers to the product and any items provided with the product. Instructional icons Warning: This symbol indicates situations that could result in death or severe injury.
  • Page 5 The product may be affected by radio frequencies emitted by other products and the product may malfunction. Use the IEC/EN 62368-1 approved power adapter that supports higher power consumption than the product. It is highly recommended to use the power adapter sold by Suprema. •...
  • Page 6 Do not apply liquid directly to the surface of the product. BioStation 2 uses capacitive buttons and screen. If the environment is moist from wet weather or the product surface is smeared with a lot of water, wipe off the product with a dry towel before using it.

  • Page 7: Introduction

    When assembling the product with the bracket, you can use the included bracket fixing screw (Star Shaped) instead of the product fixing screw for enhanced security. • For more details regarding the product, visit the Suprema website (https://www.supremainc.com) and refer to the user guide.

  • Page 8: Name And Function Of Each Part

    Introduction Name and function of each part Microphone Arrow Keys/OK LCD Screen Button LED Lamp Speaker Fingerprint Sensor Numpad/Intercom/ ESC Button RF card and mobile access card Function Buttons authentication unit Mini USB Cable Slot USB Memory Slot DIP Switch Ethernet TTL Input (4 pins) Wiegand Input...
  • Page 9 Introduction Name Description Fingerprint Sensor Part to scan the fingerprint for entrance. RF card and mobile access card Part to scan a RFID card or mobile access card for entrance. authentication unit USB Memory Slot Connects USB memory. Mini USB Cable Slot Will be supported in the future.

  • Page 10: Cables And Connectors

    Introduction Cables and connectors Power Name Color PWR +VDC Red (white stripe) PWR GND Black (white stripe) Relay Name Color RLY NO White RLY COM Blue RLY NC Orange RS-485 Name Color 485 TRXP Blue 485 TRXN Yellow 485 GND Black SH GND Gray...
  • Page 11 Introduction TTL input/output Name Color TTL IN0 / OUT0 TTL IN1 / OUT1 Yellow TTL GND Black SH GND Gray Wiegand input/output Name Color WG IN0 / OUT0 Green WG IN1 / OUT1 White WG GND Black SH GND Gray Intercom Name Color...

  • Page 12: How To Enroll A Fingerprint

    How to enroll a fingerprint In order to improve the fingerprint authentication rate, register the fingerprint correctly. BioStation 2 can recognize a fingerprint even if the angle and position of a user’s fingerprint input change. If you register the fingerprint with attention to the following matters, the authentication rate can be improved.

  • Page 13: Admin Menu

    Admin Menu All Menus Press the ESC and authenticate with the Admin level credential. Select the desired menu. If the administrator has not been designated, the menu screen will be displayed when you press ESC. Quick Menu Press and hold the ESC button for more than one second and then release the button. Next, authenticate as an administrator.

  • Page 14: User

    User Registering user information The user information including credentials can be registered. Press the ESC and authenticate with the Admin level credential. → Select USER Add User, then press OK. Select an item then press the button. Press OK after configuring the item to register the user information. •...

  • Page 15: Modifying User Information

    User Modifying User Information User Management or Administrator can modify the registered user information. A fingerprint or card can be added, and PIN and level can be modified. Press the ESC and authenticate with the Admin level credential. → Select USER Search User and press OK.

  • Page 16: View User Usage

    User View User Usage You can see the number of registered users, fingerprints and cards at a glance. Press ESC and authenticate with the Admin level credential. → Select USER User Usage, then press OK.

  • Page 17: Authentication

    Authentication Finger You can set the schedule to be used for each authentication method using a fingerprint. Press ESC and authenticate with the Admin level credential. → Select AUTHENTICATION Finger, then press OK. Select an item and press the / buttons to set a schedule. •...
  • Page 18 Authentication • : Mode to authenticate with a card and then authenticate with a fingerprint or enter PIN • : Mode to authenticate with a card and then use both fingerprint authentication and PIN input. To save settings, press OK. •...

  • Page 19: T&A Mode

    Authentication T&A Mode You can set how to register T&A Mode. Press ESC and authenticate with the Admin level credential. → Select AUTHENTICATION T&A Mode, then press OK. Select an item and press / buttons to set a schedule. • T&A Mode: Set the method to use T&A mode.

  • Page 20: Fingerprint

    • Template Format: Set the fingerprint template format. SUPREMA is set as the default, and if you change the template format, all fingerprints saved previously cannot be used. Use caution when changing the Template Format.

  • Page 21: Display & Sound

    Display & Sound You can change the display and sound settings of the device. Press ESC and authenticate with the Admin level credential. Select DISPLAY & SOUND, then press OK. Select an item and press the / buttons to change the settings. •...

  • Page 22: Device

    Device Date & Time You can set date and time. Set the date and time accurately in order to collect accurate log data. Press ESC and authenticate with the Admin level credential. → Select DEVICE Date & Time, then press OK. Select an item and press the / buttons to change the settings.

  • Page 23: User Id Type

    Device User ID Type You can set the type of user ID to be registered on the device to a combination of alphabetic characters, numbers, and symbols (_, -). Press ESC and authenticate with the Admin level credential. → Select DEVICE User ID Type, then press OK.

  • Page 24: Restart Device

    Device • SanDisk: Cruzer 16GB, Cruzer Blade CZ50 4GB, Cruzer Blade CZ50 32GB, CZ48 Ultra USB 3.0 64GB, CZ80 USB3.0 64GB, CZ52 64GB, Cruzer Glide Z60 128GB, Cruzer Force CZ71 32GB • Sony: Micro Vault Click 8GB, MicroVault CLICK 16GB, USM-SA1 32GB •...

  • Page 25: Relay

    Device Relay You can set the open time and the input port of the exit button in the device. This option is useful when the device is used as a standalone. Press ESC and authenticate with the Admin level credential. →...

  • Page 26: Device Info

    Device Device Info You can view the model name, device ID, serial number, firmware version of device ID, and MAC address. Press ESC and authenticate with the Admin level credential. → Select DEVICE Device Info, then press OK. • You can view the information including Model Name, Device ID, HW, FW, Kernel, MAC, and WiFi MAC. Check the device information and press OK.

  • Page 27: Network

    Network TCP/IP Settings You can change the network settings of the device. Press ESC and authenticate with the Admin level credential. → Select NETWORK TCP/IP, then press OK. Press the / buttons to select a Type then select an item. You can select Ethernet or Wireless. •...

  • Page 28: Server Settings

    Network Server Settings Press ESC and authenticate with the Admin level credential. → Select NETWORK Server, then press OK. Select an item and change the settings. • Connection Mode: When you select Device > Server, you can send a connection signal from the device to a server with the input information directly.

  • Page 29: Event Log

    Event Log Search Log You can set a condition and search a log. Press ESC and authenticate with the Admin level credential. → Select EVENT LOG Search, then press OK. Select an item and press the / buttons to change the condition. When you press OK, a log that matches the set condition will be displayed on the screen.

  • Page 30: View Log Usage

    Event Log View Log Usage You can check the status of log usage. Press ESC and authenticate with the Admin level credential. → Select EVENT LOG Log Usage, then press OK. Press OK after checking the log usage.

  • Page 31: Troubleshooting

    I close the installation company. door. • BioStation 2 is equipped with a built-in battery but if power is not Suddenly the time has Time supplied for a long time, the built-in battery may die, causing the time to become incorrect.

  • Page 32: Product Specifications

    Image Dimension 272 x 320 pixels Image Bit Depth 8bit, 256 grayscale Fingerprint Resolution 500 dpi Template SUPREMA / ISO19794-2 / ANSI-378 Extractor / Matcher MINEX certified and compliant Max. User 500,000 Max. Credential (1:N) Fingerprint: 20,000 • Fingerprint: 500,000 Capacity •...
  • Page 33 1 A @ 30 VDC Inductive load DESFire EV2/EV3 cards are supported by having backward compatibility of DESFire EV1 cards. CSN and smart card functions are compatible with BioStation 2. RF read range will vary depending on installation environment. The number of users registered without having any credential data.

  • Page 34: Dimensions

    Product specifications Dimensions (Unit: mm)

  • Page 35: Fcc Compliance Information

    This product is CE marked according to the provisions of the Radio Equipment Directive (RED) 2014/53/EU. Hereby, Suprema Inc. declares that this product is in compliance with the essential requirements and other relevant provisions of Radio Equipment Directive (RED) 2014/53/EU.

  • Page 36: Appendices

    Information in this document is provided in connection with Suprema products. • The right to use is acknowledged only for Suprema products included in the terms and conditions of use or sale for such products guaranteed by Suprema. No license, express or implied, by estoppel or otherwise, to any intellectual property is granted by this document.

  • Page 37: Open Source License

    Appendices Open Source License • The software of this product is based on "Linux Kernel 3.x", which is licensed under GPL. As for GPL, please refer to GNU General Public License in this manual. • This product uses the "glibc" library, which is licensed under LGPL. As for LGPL, please refer to the GNU Lesser General Public License in this manual.

  • Page 38: Terms And Conditions

    Appendices TERMS AND CONDITIONS 0. Definitions. “This License” refers to version 3 of the GNU General Public License. “Copyright” also means copyright-like laws that apply to other kinds of works, such as semiconductor masks. “The Program” refers to any copyrightable work licensed under this License. Each licensee is addressed as “you”. “Licensees”...
  • Page 39 Appendices 2. Basic Permissions. All rights granted under this License are granted for the term of copyright on the Program, and are irrevocable provided the stated conditions are met. This License explicitly affirms your unlimited permission to run the unmodified Program. The output from running a covered work is covered by this License only if the output, given its content, constitutes a covered work.
  • Page 40 Appendices 6. Conveying Non-Source Forms. You may convey a covered work in object code form under the terms of sections 4 and 5, provided that you also convey the machine-readable Corresponding Source under the terms of this License, in one of these ways: a) Convey the object code in, or embodied in, a physical product (including a physical distribution medium), accompanied by the Corresponding Source fixed on a durable physical medium customarily used for software interchange.
  • Page 41 Appendices 7. Additional Terms. “Additional permissions” are terms that supplement the terms of this License by making exceptions from one or more of its conditions. Additional permissions that are applicable to the entire Program shall be treated as though they were included in this License, to the extent that they are valid under applicable law.
  • Page 42 Appendices 9. Acceptance Not Required for Having Copies. You are not required to accept this License in order to receive or run a copy of the Program. Ancillary propagation of a covered work occurring solely as a consequence of using peer-to-peer transmission to receive a copy likewise does not require acceptance.
  • Page 43 Appendices A patent license is “discriminatory” if it does not include within the scope of its coverage, prohibits the exercise of, or is conditioned on the non-exercise of one or more of the rights that are specifically granted under this License. You may not convey a covered work if you are a party to an arrangement with a third party that is in the business of distributing software, under which you make payment to the third party based on the extent of your activity of conveying the work, and under which the third party grants, to any of the parties who would receive the covered work from you, a...

  • Page 44: Gnu Lesser General Public License

    Appendices 17. Interpretation of Sections 15 and 16. If the disclaimer of warranty and limitation of liability provided above cannot be given local legal effect according to their terms, reviewing courts shall apply local law that most closely approximates an absolute waiver of all civil liability in connection with the Program, unless a warranty or assumption of liability accompanies a copy of the Program in return for a fee.
  • Page 45 Appendices 3. Object Code Incorporating Material from Library Header Files. The object code form of an Application may incorporate material from a header file that is part of the Library. You may convey such object code under terms of your choice, provided that, if the incorporated material is not limited to numerical parameters, data structure layouts and accessors, or small macros, inline functions and templates (ten or fewer lines in length), you do both of the following: a) Give prominent notice with each copy of the object code that the Library is used in it and that the Library and its...

  • Page 46: Openssl License

    Appendices 6. Revised Versions of the GNU Lesser General Public License. The Free Software Foundation may publish revised and/or new versions of the GNU Lesser General Public License from time to time. Such new versions will be similar in spirit to the present version, but may differ in detail to address new problems or concerns.

  • Page 47: Original Ssleay License

    Appendices Original SSLeay License Copyright (C) 1995-1998 Eric Young (eay@cryptsoft.com) All rights reserved. This package is an SSL implementation written by Eric Young (eay@cryptsoft.com). The implementation was written so as to conform with Netscapes SSL. This library is free for commercial and non-commercial use as long as the following conditions are adhered to. The following conditions apply to all code found in this distribution, be it the RC4, RSA, lhash, DES, etc., code;...
  • Page 48 QR code. http://www.supremainc.com/en/about/contact-us.asp © 2024 Suprema Inc. Suprema and identifying product names and numbers herein are registered trade marks of Suprema, Inc. All non-Suprema brands and product names are trademarks or registered trademarks of their respective companies.
