www.supremainc.com

INSTALLATION GUIDE

BioStation 2
English
Version 1.3
EN 101.00.BS2 V1.30A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BioStation 2 and is the answer not in the manual?

Questions and answers

Summary of Contents for suprema BioStation 2

  • Page 1: Installation Guide

    INSTALLATION GUIDE BioStation 2 English Version 1.3 EN 101.00.BS2 V1.30A...
  • Page 2: Table Of Contents

    Contents Safety Instructions ..................3 Getting Started ....................5 Components ..............................5 Parts ................................6 Cables and Connectors ..............................8 How to Enroll a Fingerprint ........................10 Choose Ideal Fingers to Enroll ............................10 How to Enroll Fingerprints .............................10 Installation ..................... 11 Mounting the Bracket and Product ......................
  • Page 3: Safety Instructions

    If installing the product outside where the product is completely exposed, it is recommended to install the product together with the enclosure. Use a separate power supply for Secure I/O 2, electric lock and BioStation 2 respectively. • If connecting and using the power supply to these devices together, the devices may malfunction.
  • Page 4: Operating Instructions

    • This can cause a product failure. BioStation 2 uses the capacitive button. If there is much moisture (humidity) like a rainy weather or on the product, wipe with a soft and dry cloth. There is a risk of fire if batteries are replaced by an incorrect type.
  • Page 5: Getting Started

    Getting Started Getting Started Components Cable cover Wall bracket BioStation 2 PVC anchors Fixing screws Connector cables (1x2-pin, 1x -pin3, 3x4-ping, 1x5-pin) Diode Ferrite core Allen Key Drilling Template Quick Guide (For bracket) Note The components may differ depending on where the product is installed.
  • Page 6: Parts

    Getting Started Parts Microphone Arrow keys/OK button LCD screen LED lamp Speaker Fingerprint sensor Numpad/Intercom/ESC button RF card reader Function buttons Mini-USB cable port USB memory port DIP switches Ethernet TTL input (4-pin) Wiegand input (4-pin) RS-485 (4-pin) Wiegand output (4-pin) TTL output (4-pin) Relay (3-pin) Intercom (5-pin)
  • Page 7 Getting Started USB memory port Connects a USB memory stick. Mini-USB cable port To be supported later. TTL input (4-pin) Connects a TTL input/output cable. RS-485 (4-pin) Connects an RS-485 cable. TTL output (4-pin) Connects a TTL input/output cable. Relay (3-pin) Connects a relay cable.
  • Page 8: Cables And Connectors

    Getting Started Cables and Connectors Power Name Color PWR +VDC Red (White stripe) PWR GND Black (White stripe) Relay Name Color RLY NO White RLY COM Blue RLY NC Orange RS-485 Name Color 485 TRXP Blue 485 TRXN Yellow 485 GND Black SH GND Gray...
  • Page 9 Getting Started Intercom Name Color INPH +VDC INPH GND Black INPH AUD Orange INPH DTA Blue SH GND Gray...
  • Page 10: How To Enroll A Fingerprint

    Place your finger to completely cover the sensor with maximum surface. When the fingerprint recognition fails BioStation 2 can read fingerprints regardless of the change in seasons or condition of the fingers. However, the external environment or the finger's position can affect the recognition performance.
  • Page 11: Installation

    BioStation 2 is to be installed. Note If the BioStation 2 should be installed onto a concrete wall, make a hole with a drill, and then insert a PVC anchor into the hole before screwing the mounting screw.
  • Page 12: Connecting To Power

    Installation Assemble the BioStation 2 with the bracket by using the hex socket head screws on the bottom of the BioStation 2 with the allen key. Connecting to Power (Optional) Power 1 - PWR +VDC Red (White stripe) 2 - PWR GND...
  • Page 13: Connecting To A Network

    A normal CAT-5 UTP cable can be used to connect to a hub. BioStation 2 Connecting to a PC directly BioStation 2 can be connected directly to a PC by using a normal straight type CAT-5 UTP cable because it supports an automatic MDI/MDIX function. BioStation 2...
  • Page 14: Connecting To Ttl Input And Output

    3 - TTL GND Black 4 - SH GND Gray Door button Cable Shield (Optional) Door sensor BioStation 2 TTL output connection 1 - TTL OUT0 2 - TTL OUT1 Yellow 3 - TTL GND Black 4 - SH GND...
  • Page 15: Connecting To An Intercom

    Install a diode at both ends of the wire at the door lock as shown in the figure to protect the relay from the reverse current induced when the door lock operates. • Make sure that the direction of the installed diode is correct. • Install a diode close to the door lock. • Use a separate power source for the BioStation 2 from the door lock.
  • Page 16: Fail Secure Lock

    Make sure that the direction of the installed diode is correct. • Install a diode close to the door lock. • Use a separate power source for the BioStation 2 from the door lock. Connecting to an Automatic door 1 - RLY NO White...
  • Page 17: Connecting As A Standalone

    Installation Connecting as a standalone BioStation 2 can be connected directly to a door lock, a door button, and a door sensor without any additional I/O device. TTL Connection 1 - TTL IN0 2 - TTL IN1 Yellow 3 - TTL GND...
  • Page 18: Connecting To Secure I/O 2

    If it is installed in the middle of the chain, the quality of communication will be deteriorated because it re duces the signal level. If the termination resistor of the BioStation 2 is required, set the #1 DIP switch to ON.
  • Page 19: Connecting As A Wiegand Device

    1 - WG IN0 Green 2 - WG IN1 White 3 - WG GND Black 4 - SH GND Gray BioStation 2 Using as a Wiegand output device Cable Shield (Optional) Controller 1 - WG OUT0 Green 2 - WG OUT1 White...
  • Page 20: Product Specifications

    Power 9V ~ 18V Optional Dimensions (W x H x D mm) 142 x 144 x 45(38) Certificates CE, FCC, KC, RoHS, REACH, WEEE * For detailed information on our supported card list, contact Suprema technical support team at support@supremainc.com.
  • Page 21: Dimensions

    Product Specifications Dimensions (Unit: mm)
  • Page 22: Fcc Compliance Information

    FCC Compliance Information FCC Compliance Information THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 23: Appendix

    This document provides the information pertaining to Suprema's products. • The right of use is granted only to the products that are covered by the sales agreement and conditions guaranteed by Suprema. Any license of intellectual property that is not dealt within this document is not granted.
