Page 2: Table Of Contents
Contents Safety precautions Product components Optional accessories Names of each parts Product Dimension Cables and Connectors Power Connection LAN Connection RS485 Connection Relay Connection Digital Input Connection Wiegand Input/Output Installation of Wall-mount Bracket Installation of Extended Bracket Installation Reference Specification Electrical Specification FCC Rules... -
Page 3: Safety Precautions
Safety precautions Do not install the device in a Do not place the device next place subject to direct sun to heating equipments. light, humidity, dust or soot. Do not place a magnet In cleaning, do not splash near the product. water on the device but wipe it out with smooth cloth or towel. - Page 4 Safety precautions Do not drop the device. Do not disassemble, repair or alter the device. The warranty does net apply to any product damage cause by an arbitrary installation or repair. Do not let children touch the Do not use the device for device without supervision.
-
Page 5: Product Components
Product components Basic components Xpass Slim Bracket Wall mounting screws Knife Blocks Shrinkable Tubes Software CD (2 ea) (2 ea) The components shown above may differ depending on the installation environment. -
Page 6: Optional Accessories
Optional accessories Extended Bracket Adaptor Secure I/O Plastic stand... -
Page 7: Names Of Each Parts
Names of each parts... - Page 8 LED status...
- Page 9 Initialization of network setting When you install the Xpass Slim or forget the network setting’s value of Xpass Slim in use, can initial the network setting’s value (TCP/IP address, RS-485 setting) in the switch of Xpass Slim’s back side as...
-
Page 10: Product Dimension
Product Dimension (unit : mm) < Front View > < Side View > < Bracket > < Extended bracket > -10-... -
Page 11: Cables And Connectors
Cables and Connectors Pin Name Description Color ETH TXN ETH TXN (LAN) ETH TXP ETH TXP (LAN) Black ETH RXN ETH RXN (LAN) Green ETH RXP ETH RXP (LAN) Yellow SWIN 0 Switch Input 0 Purple SWIN 1 Switch Input 1 Brown SW GND Switch GND... -
Page 12: Power Connection
Power Connection Pin Name Color PWR IN PWR GND Black (white string) Recommended power supply 12V ± 10%, at least 500mA. Comply with standard IEC/EN 60950-1. To share the power with other devices, use a power supply with higher current ratings. -12-... -
Page 13: Lan Connection
LAN Connection -13-... - Page 14 LAN Connection (Direct connection with PC) -14-...
-
Page 15: Rs485 Connection
RS485 Connection for Host Communication Pin Name Color 485 TRX+ Blue (white string) 485 TRX- Yellow (black string) 485 GND White (black string) -15-... - Page 16 RS485 Connection for Secure I/O Pin Name Color 485 TRX+ Blue (white string) 485 TRX- Yellow (black string) 485 GND White (black string) Max number of devices Maximum eight(8) devices (including Master) interworks in an RS485 loop. -16-...
-
Page 17: Relay Connection
Relay Connection – Fail safe lock Pin Name Color RLY COM Green (white string) RLY NC Orange (black string) -17-... - Page 18 Relay Connection – Fail secure lock Pin Name Color RLY NO Gray (white string) RLY COM Green (white string) -18-...
- Page 19 Relay Connection - Automatic door Pin Name Color RLY NO Gray (white string) RLY COM Green (white string) -19-...
-
Page 20: Digital Input Connection
Digital Input Connection (Alarm, Emergency S/W) Pin Name Color SWIN 0 Purple SWIN 1 Brown SW GND Gray -20-... - Page 21 Digital Input Connection (RTE, Door sensor) Pin Name Color SWIN 0 Purple SWIN 1 Brown SW GND Gray -21-...
-
Page 22: Wiegand Input/Output
Wiegand Input/Output Wiegand Input Pin Name Color WGD D0 Green WGD D1 White WGD GND Black Wiegand Output Pin Name Color WGD D0 Green WGD D1 White WGD GND Black -22-... -
Page 23: Installation Of Wall-Mount Bracket
Installation of Wall-mount Bracket Fix wall mount bracket on a wall using Hook Xpass Slim on the wall mount bracket wall mounting screws Fix Xpass Slim and wall mounting bracket using a wall mounting screw -23-... -
Page 24: Installation Of Extended Bracket
Installation of Extended Bracket Assemble the extended bracket using Mount the extended bracket to the screws desired location using screws Fix Xpass Slim and the extended Hook Xpass Slim on the extended bracket bracket using screws -24-... -
Page 25: Installation Reference
Installation Reference 1 - Standalone -25-... - Page 26 Installation Reference 2 – Standalone (Secure) -26-...
- Page 27 Installation Reference 3 – Network -27-...
-
Page 28: Specification
Specification 32 bit Micro-processor Memory 8MB FLASH + 16MB SDRAM 13.56 MHz ISO14443A/B, ISO15693, Mifare/DesFire(CSN), Inside(CSN), RF Card Felica(IDM) User Capacity 40,000 user Log Capacity 50,000 log Network interfaces Interfaces : TCP/IP, RS485, Wiegand In or Out IP Rate IP 65 class Sound Multi-tone buzzer Multi-color LED... -
Page 29: Electrical Specification
Electrical Specification Min. Typ. Max. Notes Power Voltage (V) 10.8 13.2 Use regulated DC power adaptor only Current (mA) Switch Input VIH (V) VIL (V) Pull-up resistance (Ω) 4.7k The input ports are pulled up with 4.7k resistors TTL/Wiegand Output VOH (V) VOL (V) The outputs ports are open drain type, pulled up with... -
Page 30: Fcc Rules
FCC Rules Changes or modifications not expressly approved by the manufacturer Caution responsible for compliance could void the user’s authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the Warning following two conditions: (1) This device may not cause harmful interface, and (2) this device must accept any interface received, including interference that may cause undesired operation.
