MikroTik GPEN11 Manual

GPEN11
Safety Warnings
Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
The Installation of the equipment must comply with local and national electrical codes.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.
Use only the power supply and accessories approved by the manufacturer, which can be found in the original packaging of this product.
Read the installation instructions before connecting the system to the power source.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your
own risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
It is the customer's responsibility to follow local country regulations. All Mikrotik devices must be professionally installed.
Powering
The device accepts power from a direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) 12-57 V DC.
Power output
The device supports PoE out from the Ethernet port located under the cover. You can power Mikrotik devices that support passive powering through
Ethernet.
Mounting
Step 1:
1. Remove the cover screw using a PH2 screwdriver;
2. Remove the cover to access mounting points.
Step 2:
1. Drill holes using drill bid;
2. Insert dowels if needed;
3. Attach the unit to the wall, using the wall, and secure with screws.
