GPEN11
This device allows powering a PoE capable device over the Ethernet, using the same voltage, as provided with the DC input jack.
Powering
The device accepts power from a direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) 12-57 V DC.
Power output
The device supports PoE out from the Ethernet port located under the cover. You can power Mikrotik devices that support passive powering through
Ethernet.
Mounting
Step 1:
1.
Remove the cover screw using a PH2 screwdriver;
2.
Remove the cover to access mounting points.
Step 2:
1.
Drill holes using drill bid;
2.
Insert dowels if needed;
3.
Attach the unit to the wall, using the wall, and secure with screws.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MikroTik GPEN11
Summary of Contents for MikroTik GPEN11
- Page 1 The device accepts power from a direct-input power jack (5.5 mm outside and 2 mm inside, female, pin positive plug) 12-57 V DC. Power output The device supports PoE out from the Ethernet port located under the cover. You can power Mikrotik devices that support passive powering through Ethernet.
- Page 2 Step 1.Step 2. Step 3: Plug-in the Ethernet cable going to the unit that will be powered; Plug-in power source for the GPEN. Outgoing Ethernet cable can be guided through position A or B for cable leading into the wall. Step 4: Re-attach cover;...
- Page 3 K-62 screw kit Specifications For more information about this product, specifications, pictures, downloads please visit our web page: https://mikrotik.com/product/gpen11 https://i.mt.lv/cdn/product_files/GPEN_concept_200204.pdf Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 4 DA Hermed erklærer Mikrotīkls SIA , at radioudstyrstypen RouterBOARD er i overensstemmelse med direktiv 2014/53/EU. EU- overensstemmelseserklæringens fulde tekst kan findes på følgende internetadresse: https://mikrotik.com/products DE Hiermit erklärt Mikrotīkls SIA , dass der Funkanlagentyp RouterBOARD der Richtlinie 2014/53/EU entspricht. Der vollständige Text der EU- Konformitätserklärung ist unter der folgenden Internetadresse verfügbar:...
- Page 5 MT B'dan, Mikrotīkls SIA , niddikjara li dan it-tip ta' tagħmir tar-radju RouterBOARD huwa konformi mad-Direttiva 2014/53/UE. It-test kollu tad- dikjarazzjoni ta' konformità tal-UE huwa disponibbli f'dan l-indirizz tal-Internet li ġej: https://mikrotik.com/products NL Hierbij verklaar ik, Mikrotīkls SIA , dat het type radioapparatuur RouterBOARD conform is met Richtlijn 2014/53/EU. De volledige tekst van de EU- conformiteitsverklaring kan worden geraadpleegd op het volgende internetadres: https://mikrotik.com/products...
- Page 6 Note. Information contained here is subject to change. Please visit the product page on www.mikrotik.com for the most up to date version of this document. BG. Инструкция : Свържете адаптера на захранване, за да включите устройството. Повече информация в {+}https://mt.lv/help-bg+ CS.
