- Page 1 GUIDELINE OVERHEATING PROBE REPLACEMENT MODELS : TK500 – TK1000 – TK 2000 www.tecoonline.com www.tecous.com...
- Page 2 EQUIPMEMT 1 black clamps Screw-drivers Tongs Overheating Probe (spare part) Allen wrench (7) www.tecoonline.com www.tecous.com...
- Page 3 STEP n. Disconnect the chiller from power supply. Never touch internal part or dismount chiller when it is connected to power supply to avoid potential electric shock. Remove the conveyor from the top part of the chiller. You can see the metal black grid and the red fan support.
- Page 4 STEP n. Remove the air filter grid and air filter from their position. www.tecoonline.com www.tecous.com...
- Page 5 STEP n. Using the screw-driver, remove the 4 INOX screws indicated in the picture here below. www.tecoonline.com www.tecous.com...
- Page 6 STEP n. Remove the red fan support lifting it up from the bottom edge. Leave it on the metal cover, as you can see in the picture. www.tecoonline.com www.tecous.com...
- Page 7 STEP n. Disconnect the compressor connector, heater connector and probes connector. Probe Compressor Heater connector connector connector www.tecoonline.com www.tecous.com...
- Page 8 STEP n. Cut the black clamps inside the chiller that embrace probe’s wire. Then with the small screw driver, disconnect the old overheating probe wire from the small green connector. Pay attention to not confuse overheating probe with water probe. Water probe wire comes from the bottom of exchanger.
- Page 9 STEP n. Before replacing overheating probe, wait for compressor and other parts to stop to be hot. Then remove the old overheating probe from the drier filter and place the new one. www.tecoonline.com www.tecous.com...
- Page 10 STEP n. Connect the new probe wire to the green connector using the screw-driver. Take a new black plastic clamp and pinch the probe cable around the exchanger’s pipe insulation, as showed in the picture. www.tecoonline.com www.tecous.com...
- Page 11 STEP n. Disconnect the compressor connector, heater connector and probes connector. Probe Compressor Heater connector connector connector www.tecoonline.com www.tecous.com...
- Page 12 STEP n. Take the fan support Assembly. Reconnect all connectors (compressor connector) and fix it at the chiller’s body. Attention: the front panel side must be insert in the aluminum profiles! Rebuild the top part of the chiller following the indicated sequence: 4 INOX screw (fix the fan support on the metal cover)
