TECO TK Series Manualline
Motor fan replacement
Hide thumbs
Also See for TK Series:
- Replacement manualline (11 pages) ,
- Replacement manuallines (11 pages) ,
- Installation manual (10 pages)
Subscribe to Our Youtube Channel
Related Manuals for TECO TK Series
Summary of Contents for TECO TK Series
- Page 1 GUIDELINE MOTOR FAN REPLACEMENT MODELS : TK500 – TK1000 – TK 2000 www.tecoonline.com www.tecous.com...
- Page 2 EQUIPMEMT Tongs Screw-driver Allen wrench (7) Allen wrench (8) Motor Fan (spare part) 5 black clamps www.tecoonline.com www.tecous.com...
- Page 3 STEP n. WARNING! Parts replacements and reparation may be carried out only by qualified persons. If this are not performed properly, they can cause electric shock, burns and fires Disconnect chiller from power supply. Never touch internal part or dismount chiller when it is connected to power supply to avoid potential electric shock.
- Page 4 STEP n. Using the screw-driver, remove the 4 screws that fix the metal grid. Then, remove the grid. www.tecoonline.com www.tecous.com...
- Page 5 STEP n. Using the allen wrench take out the fan blade screw(8). Then, remove the fan blade. ONLY FOR TK500 AND TK1000: Remove the red ring from its position. www.tecoonline.com www.tecous.com...
- Page 6 STEP n. Using the screw-driver, remove the 4 INOX screws indicated in the picture here below. www.tecoonline.com www.tecous.com...
- Page 7 STEP n. Remove the air filter grid and air filter from their position. www.tecoonline.com www.tecous.com...
- Page 8 STEP n. Remove the red fan support lifting it up from the bottom edge. Leave it on the metal cover, as you can see in the picture. www.tecoonline.com www.tecous.com...
- Page 9 STEP n. Disconnect the compressor connector, heater connector and probe connector. Probe Heater Compressor connector connector connector www.tecoonline.com www.tecous.com...
- Page 10 STEP n. Now, the fan support has been disconnected from the bottom part of the chiller. Take the fan support off and place it on a work table. In order to fix all cables in the fan support, use 5 black clamps. Cut them with the tongs.
- Page 11 www.tecoonline.com www.tecous.com...
- Page 12 STEP n. Disconnect the fan connector and remove the 4 nuts with the allen wrench (7). www.tecoonline.com www.tecous.com...
- Page 13 STEP n. Lift out the motor fan assembly and replace it with the new one. Using the allen wrench (7) screw the 4 nuts and connect the fan connector. www.tecoonline.com www.tecous.com...
- Page 14 STEP n. Take the 5 black clamps and use it to fix all electrical cable, as before. www.tecoonline.com www.tecous.com...
- Page 15 STEP n. Reconnect all connectors. Then take the fan support and fix it at the bottom part of chiller. Attention: the front panel side must be insert in the aluminum profile! Rebuild the top part of the chiller following the indicated sequence: 4 INOX screw (fix the fan support on metal cover)
