- Page 1 GUIDES Controller RESET MODELS : TK3000 – TK3000H TK6000 – TK6000H TK9000 – TK9000H www.tecoonline.com www.tecous.com...
- Page 2 EQUIPMEMT Screw-driver www.tecoonline.com www.tecous.com...
- Page 3 If this are not performed properly, they can cause electric shock, burns and fires WARNING! TECO S.r.l. decline any responsibility in case of damages caused by a wrong installation Disconnect the chiller from power supply. Never touch internal part or dismount chiller when it is connected to power supply to avoid potential electric shock.
- Page 4 STEP n. Using the screw-driver, remove the screws indicated in the picture here below (n°16 screws) www.tecoonline.com www.tecous.com...
- Page 5 STEP n. Disconnect ground wire from the cover Remove the cover www.tecoonline.com www.tecous.com...
- Page 6 STEP n. Find on PCB the RESET pins Take a picture of “reset”, “uv” and “heater”pins (the same as below) in order to remember how jumpers were placed www.tecoonline.com www.tecous.com...
- Page 7 STEP n. Remove the jumper from “Heater” or “UV” pins Place the jumper on RESET pins www.tecoonline.com www.tecous.com...
- Page 8 STEP n. Reassemble the chiller: place the metal cover of the chiller in its own place and don’t foget to connect ground wire to metal fairing Connect chiller to power supply Turn on the chiller for 5 seconds, then turn it off Disconnect the chiller from power supply Dismount the metal cover (step 1 and 2) Move the jumper from Reset pins to its original position (you took...
- Page 9 STEP n. Reassemble the chiller: place the fairing in its own place. Don’t foget to connect ground wire to metal fairing ATTENTION: Connect chiller to power supply when metal fairing is already placed and when water is already circulating www.tecoonline.com www.tecous.com...
