- Page 1 1x4 HDMI 1.3 with Multi-channels Splitter Operation Manual...
- Page 2 Back up display image. System Requirements HDMI input source equipment and output HDTVs. Features HDMI 1.3, HDCP1.1 and DVI1.0 compliant. Deep color video up to 12bit, 1080p@(24/60)Hz. One HDMI source that can connect up to four HDMI displays simultaneously.
- Page 3 Operating Functions Controls Front Panel ① HDMI Outputs 1: Connect each of the output ports to the HDMI display. When more than one output connected, the HDMI outputs play identical video signal simultaneously. ② HDMI Input: Connect input port to the HDMI or DVI output of your source equipment such as DVD player or set-top-box.
- Page 4 Rear Panel ① HDMI Outputs 2/3/4: Connect each of the output ports to the HDMI display. When more than one output connected, the HDMI outputs play identical video signal simultaneously. Connection and Installation Specifications Input Ports 4 x HDMI Output Ports 2 x HDMI Power Supply 5V/1A DC (US/EU standards, CE/FCC/UL certified)
