User's Manual
Color LCD Monitor
Important
Carefully read this User's Manual and Setup Manual before use to
use the monitor correctly.
• See the Setup Manual for monitor installation and connection.
• For the latest product information including the "User's Manual", refer to
our web site:
www.eizoglobal.com
Advertisement
Table of Contents
Related Manuals for Eizo DuraVision MDF2701W
Summary of Contents for Eizo DuraVision MDF2701W
- Page 1 User’s Manual Color LCD Monitor Important Carefully read this User’s Manual and Setup Manual before use to use the monitor correctly. • See the Setup Manual for monitor installation and connection. • For the latest product information including the "User’s Manual", refer to our web site: www.eizoglobal.com...
- Page 2 EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information.
-
Page 3: About This Product
When the screen becomes dark or begins to flicker, please contact your local EIZO representative. • Do not scratch or press on the LCD panel with any sharp objects, at this may result in damage to the LCD panel. -
Page 4: About The Installation
About This Product About the Installation • Dew condensation may form on the surface or interior of this product when it is brought into a cold room, when the temperature suddenly rises, or when it is moved from a cold room to a warm room. -
Page 5: Table Of Contents
CONTENTS CONTENTS About This Product ....................About the Usage of This Product ................ About the LCD Panel ..................About the Installation................... Cleaning ......................To Use the Monitor Comfortably ................. 1 Introduction ........................ Features ......................2 Basic Adjustment / Settings..................Adjusting Brightness ................... 3 Advanced Adjustment / Setting ................ - Page 6 CONTENTS 7.1.8 Transport / Storage Conditions ............... 25 7.1.9 Viewing Distance ..................25 7.1.10 Protection structure................. 25 Compatible Resolutions ..................26 Appendix ........................27 Trademark......................27 License........................ 27 Testing Standard....................27 Type Approval of Ship Classification..............27 Other Certifications ..................... 28 Warning for Radio interference ................
-
Page 7: Introduction
Introduction | 1 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1.1 Features • 27.0-inch screen • Supports 1920 x 1080 resolution • Equipped with a wide viewing angle panel • Achieves high visibility and improved screen intensity through optical bonding •... -
Page 8: Basic Adjustment / Settings
2 | Basic Adjustment / Settings 2 Basic Adjustment / Settings 2.1 Adjusting Brightness Settings: "0%" – "100%" The brightness of the screen can be adjusted to suit the installation environment or personal preference. The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel). -
Page 9: Advanced Adjustment / Setting
Advanced Adjustment / Setting | 3 3 Advanced Adjustment / Setting This chapter describes the advanced monitor adjustment and setting procedures using the Setting menu. For basic functions, see 2 Basic Adjustment / Settings [} 8]. 3.1 Basic Operation of the Setting Menu 1. -
Page 10: Setting Menu Functions
3 | Advanced Adjustment / Setting 3.2 Setting Menu Functions 3.2.1 Color The color mode settings can be adjusted according to personal preference. The adjusted settings are saved for each color mode. Functions that can be adjusted differ depending on the color mode. ✓: Adjustable, -: Not adjustable Function Color Mode... - Page 11 Advanced Adjustment / Setting | 3 Brilliance Settings: "0%" – "100%" The screen brightness is adjusted by changing the brightness of the backlight (light source from the LCD back panel). Note • The value shown in "%" is for reference. • 0% can only be set when Backlight Off Mode is set to "On". •...
-
Page 12: Signal
3 | Advanced Adjustment / Setting Advanced Settings - Hue Settings: "-100" – "100" This function allows you to adjust hue. Note • Using this function may prevent some color gradations from being able to be displayed. Advanced Settings - Saturation Settings: "-100" – "100" This function allows you to adjust color saturation. - Page 13 Advanced Adjustment / Setting | 3 • DVI/DisplayPort™ input The functions that can be set differ depending on the input signal. ✓: Can be set, -: Cannot be set. Function Input Signal DisplayPort D-SUB Picture Expansion ✓ ✓ ✓ Analog Adjustment ✓ Picture Expansion Settings: "Full Screen"...
- Page 14 3 | Advanced Adjustment / Setting Note • The auto screen adjust function will operate correctly if an image is displayed in the entire displayable area of the screen. It will not operate correctly in the following cases: – When an image is displayed in only part of a screen like the command prompt –...
-
Page 15: Preferences
Advanced Adjustment / Setting | 3 3.2.3 Preferences The monitor settings can be configured to suit your usage environment or preferences. Input Settings: "DVI" / "DisplayPort" / "D-SUB" Selects the input signal. Power Save Settings: "On" / "Off" The monitor can be set to enter power saving mode according to the state of the PC. The monitor changes to power saving mode about 15 seconds after signal input ceases to be detected. -
Page 16: Languages
3 | Advanced Adjustment / Setting 3.2.4 Languages Settings: "English" / "German" / "French" / "Spanish" / "Italian" / "Swedish" / "Japanese" / "Simplified Chinese" / "Traditional Chinese" The display language for menus and messages can be selected. 3.2.5 Information You can check the monitor information (model name, serial number (S/N), firmware version, usage time) and the input signal information. -
Page 17: Administrator Settings
Administrator Settings | 4 4 Administrator Settings This chapter describes how to configure monitor operation using the "Administrator Settings" menu. 4.1 Basic Operation of the "Administrator Settings" Menu 1. Press and hold for more than 5 seconds to turn off the monitor. 2. -
Page 18: Functions Of The "Administrator Settings" Menu
PC. On-Screen Logo Settings: "On" / "Off" When the monitor is turned on, the EIZO logo appears on the screen. When this function is set to "Off", the EIZO logo does not appear. Key Lock Settings: "Off"... - Page 19 (Except when the adjustment menu is displayed, when an input signal error is displayed, when the EIZO logo is displayed, etc.) If it is set to "Off" and "Brilliance" is set to the lowest value, the screen will not become completely black.
-
Page 20: Troubleshooting
5 | Troubleshooting 5 Troubleshooting 5.1 No Picture All control buttons do not light up • Check whether the power cord is connected properly. • Turn on the main power switch on the back of the monitor. • Turn off the main power switch on the back of the monitor, and then turn it on again a few minutes later. -
Page 21: Imaging Problems (Digital And Analog)
[} 10]). (The LCD monitor backlight has a limited life span. If the screen becomes dark or begins to flicker, contact your local EIZO representative.) The screen suddenly became dark / Even when increasing the value of "Brilliance" in the Adjustment menu, the screen does not become brighter •... -
Page 22: Imaging Problems (Analog Only)
5 | Troubleshooting 5.3 Imaging Problems (Analog only) Screen is misaligned • Use "Hor. Position" or "Ver. Position" in the Setting menu to adjust the positioning of the screen (see Analog Adjustment - Hor. Position / Ver. Position [} 14]). • If the graphics board's utility has a function to change the position of the image, use that function to adjust the position. -
Page 23: Maintenance
• This monitor is equipped with a buzzer that can produce warning sounds under system control. • It is recommended to periodically verify that the buzzer warning sound is functioning. For verification, please use the system control. Note • For more information on system control, please contact your local EIZO representative. -
Page 24: Reference
7 | Reference 7 Reference 7.1 Specifications 7.1.1 LCD Panel Backlight Size 27" (68.6 cm) Resolution 1920 dots x 1080 lines Display Size (H x V) 597.6 mm x 336.2 mm Pixel Pitch (H x V) 0.311 mm x 0.311 mm Display Colors 8-bit colors: 16.77 million colors Viewing Angle (H / V, typical) 89˚... -
Page 25: Power
Reference | 7 7.1.5 Power Input 100 V – 240 V +10 % / -15 %, 50 / 60 Hz, 0.50 A – 0.25 A 24 V +30 % / -10 %, 1.85 A Maximum Power 45 W or less Consumption 44 W or less Power Save Mode 5 W or less 5 W or less... -
Page 26: Compatible Resolutions
7 | Reference 7.2 Compatible Resolutions The monitor supports the following resolutions: ✓: Supported, -: Not supported Resolution Vertical scan DisplayPort D-Sub frequency (Hz) 640 x 480 59.940 ✓ ✓ ✓ 640 x 480 60.000 ✓ ✓ ✓ 640 x 480 72.809 ✓... -
Page 27: Appendix
Apple, macOS, Mac OS, OS X, macOS Sierra, Macintosh and ColorSync are trademarks of Apple Inc. EIZO, the EIZO Logo, ColorEdge, CuratOR, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor, and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. -
Page 28: Other Certifications
Original Purchaser or any third parties other than as provided under this Warranty. EIZO and Distributors will cease to hold or store any parts (excluding design parts) of the Product upon expiration of ten (10) years after the production of the Product is discontinued. - Page 29 The Warranty Period for any replaced and/or repaired product under this Warranty shall expire at the end of the original Warranty Period. EIZO OR DISTRIBUTORS ARE NOT RESPONSIBLE FOR ANY DAMAGE TO, OR LOSS OF, DATA OR OTHER INFORMATION STORED IN ANY MEDIA OR ANY PART OF ANY PRODUCT RETURNED TO EIZO OR DISTRIBUTORS FOR REPAIR.
- Page 30 00N0N421AZ UM-MDF2701W Copyright © 2023 EIZO Corporation. All rights reserved. 1st Edition – November, 2023...
