Setup Manual
Color LCD Monitor
Important
Carefully read this Setup Manual and User's Manual before use to
use the monitor correctly.Please retain this manual for future
reference.
• Refer to the "User's Manual" for information on the setting / adjustment
of the monitor.
• You can check the latest product information, including the Setup
Manual, from our web site.
www.eizoglobal.com
Advertisement
Table of Contents
Related Manuals for Eizo DuraVision MDF2701W
Summary of Contents for Eizo DuraVision MDF2701W
- Page 1 Setup Manual Color LCD Monitor Important Carefully read this Setup Manual and User’s Manual before use to use the monitor correctly.Please retain this manual for future reference. • Refer to the "User’s Manual" for information on the setting / adjustment of the monitor.
- Page 2 EIZO Corporation. EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information.
-
Page 3: Precautions
PRECAUTIONS PRECAUTIONS Important This product has been adjusted specifically for use in the region to which it was originally shipped. If operated outside this region, the product may not perform as stated in the specifications. To personal safety and proper maintenance, please read carefully the "PRECAUTIONS" section and the caution statements on the monitor. - Page 4 WARNING If the unit begins to emit smoke, smells like something is burning, or makes strange noises, disconnect all power connections immediately and contact your EIZO representative for advice. Attempting to use a malfunctioning unit may result in fire, electrical shock, or equipment damage.
- Page 5 PRECAUTIONS WARNING Install the product so that the user cannot touch the power input section on the back Touching the power input section may result in electric shock. Proper insulation protection must be applied to the power input section in accordance with the applicable standards for the final product after installation.
- Page 6 PRECAUTIONS WARNING To disconnect the power cord, grasp the plug firmly and pull. Tugging on the cord may damage and result in fire or electrical shock. WARNING When removing the DC power terminal block, hold the terminal block part Tugging on the cable may damage it and result in fire or electrical shock. WARNING Handle the power cord with care.
- Page 7 PRECAUTIONS CAUTION CAUTION Disconnect cables and remove accessories when moving the unit Otherwise, the cables or accessories may become detached when moving, resulting in injury. CAUTION Do not block the ventilation slots on the cabinet. • Do not place any objects on the ventilation slots. •...
-
Page 8: Table Of Contents
CONTENTS CONTENTS PRECAUTIONS ......................Important ......................Location of Caution Statement..............Symbols on the unit..................... 1 Introduction ........................ Package Contents....................Controls and Functions ..................2 Installation / Connection.................... 11 Installation ......................11 2.1.1 Installation conditions................11 2.1.2 Monitor installation conditions..............11 2.1.3 How to assemble .................. -
Page 9: Introduction
1 Introduction 1.1 Package Contents Check that all of the following items are contained in the package. If any of these are missing or damaged, contact your dealer or local EIZO representative. • Monitor • Setup Manual (this document) • Cleaning cloth 1.2 Controls and Functions... - Page 10 1 | Introduction 6. AC main power switch Turns the AC main power on or off. : On, : Off 7. AC power connector Connects the power cord. An insulation cover is attached when the product is shipped. 8. DC power connector Mounts the DC power terminal block.
-
Page 11: Installation / Connection
Installation / Connection | 2 2 Installation / Connection 2.1 Installation 2.1.1 Installation conditions Ensure there is sufficient space around the monitor, and install so that air can circulate. The installable orientations and movement range (tilt angle) are as follows: • Orientation No rotation •... -
Page 12: How To Assemble
2 | Installation / Connection (d) Allowable clearance between mounting surface and installation surface: 0 mm to 1.0 mm Mounting surface Monitor Mounting surface Mounting surface Mounting surface Monitor Monitor Monitor 2.1.3 How to assemble Attention • Mounting screws are not included with this product. Prepare M5 screws (10 pcs.) separately for the assembly enclosure. - Page 13 Installation / Connection | 2 Mounting conditions • Panel opening dimensions / Clearance between the screw mounting holes (unit: mm) Mounting hole M5 Mounting hole M5 0.2 A Mounting hole 8xM5 0.2 A B 48.5 ± 0.3 584.5 ± 0.3 Screw (nominal diameter: 5 mm)
-
Page 14: Connecting Cables
2 | Installation / Connection 3. Attach the screw cover to the monitor. Insert it into the monitor. 2.2 Connecting Cables Attention • Please make sure the cables are in good working condition before use. • Check the shapes of the connectors, and connect the cables. •... - Page 15 Installation / Connection | 2 1. Connect signal cables. Prepare and connect cables that are appropriate for your computer. DisplayPort DisplayPort DisplayPort cable D-Sub 15 pin (mini) D-Sub mini 15-pin cable D-Sub mini 15-pin DVI (DVI-D) DVI (DVI-D) cable DVI (DVI-D) 2. Connect a USB cable or RS-232C cable (straight type). This is necessary when controlling the monitor from the system.
- Page 16 2 | Installation / Connection When using the AC power connector 1. Remove the screws securing the insulation cover. 2. Lift the power plug clamp and remove the insulation cover from the AC power connector. Power plug clamp Screw Insulation cover 3. Lift the power plug clamp and connect the power cord to the AC power connector. 4.
- Page 17 Installation / Connection | 2 2. Strip the wire insulation (strip length: 7 mm ± 0.5 mm). If tip treatment is required, attach a rod terminal (ferrule). Use ferrules made by Phoenix Contact. Rod terminal 7 mm±0.5 mm 3. Insert the wires into the terminal block and tighten the clamp screws with a flat-head screwdriver with a tip width of 2.5 mm (recommended torque: 0.5 N･m to 0.6 N･m).
- Page 18 2 | Installation / Connection 4. Attach the terminal block and tighten the left and right clamp screws with a flat-head screwdriver with a tip width of 2.5 mm (recommended torque: 0.5 N･m to 0.6 N･m). DC power terminal block 5. Fasten with a cable tie so that the cables do not come off. Cable tie *1 For electrical wires For USB cable...
-
Page 19: Displaying The Screen
Installation / Connection | 2 2.3 Displaying the Screen 1. If using AC power, check if the AC main power switch is on. (It is on when the product is shipped.) When it is on, will light up in green. 2. Press to turn on the power of the monitor. -
Page 20: Ecdis Setup
To integrate it, the following information is required: • ECDIS color table specifications • Monitor control command specifications For details, contact your dealer or local EIZO representative, or refer to our web site (www.eizoglobal.com). To achieve compliance with ECDIS standards for display, settings are required on the monitor side. - Page 21 153 Shimokashiwano, Hakusan, Ishikawa 924-8566 Japan Belgrader Straße 2, 41069 Mönchengladbach, Germany 中国苏州市苏州工业园区展业路8号中新科技工业坊5B 00N0N422A1 www.eizoglobal.com SUM-MDF2701W Copyright © 2023 EIZO Corporation. All rights reserved. 1st Edition – November, 2023...
