Instructions for Use
Touch Panel Color LCD monitor
Important
Please read this "Instructions for Use", and "Installation Manual"
(separate volume) carefully to familiarize yourself with safe and
effective usage.
Please retain this manual for future reference.
• For monitor adjustment and settings, refer to the "Installation
Manual".
• For the latest product information including the "Instructions for
Use", refer to our web site :
http://www.eizoglobal.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Eizo Radiforce MS236WT
Summary of Contents for Eizo Radiforce MS236WT
- Page 1 Instructions for Use Touch Panel Color LCD monitor Important Please read this “Instructions for Use”, and “Installation Manual” (separate volume) carefully to familiarize yourself with safe and effective usage. Please retain this manual for future reference. • For monitor adjustment and settings, refer to the “Installation Manual”.
- Page 2 EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Precautions
PRECAUTIONS ● IMPORTANT • This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. • To personal safety and proper maintenance, please read carefully this section and the caution statements on the monitor. - Page 4 A unit placed on an inadequate surface may fall and result in injury or equipment damage. If the unit falls, disconnect the power immediately and ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock.
- Page 5 If the unit falls, please ask your local EIZO representative for advice. Do not continue using a damaged unit. Using a damaged unit may result in fire or electric shock. When reattaching the tilt stand, please use the same screws and tighten them securely.
- Page 6 CAUTION Handle with care when carrying the unit. Disconnect the power cord and cables when moving the unit. Moving the unit with the power cord or cables attached is dangerous and may result in injury. Carry or place the unit according to the correct specified methods. •...
-
Page 7: Notice For This Monitor
• The backlight of the LCD panel has a fixed lifetime. When the screen becomes dark or begins to flicker, please contact your local EIZO representative. • The screen may have defective pixels or a small number of light dots on the screen. This is due to the characteristics of the panel itself, and is not a malfunction of the product. -
Page 8: To Use The Monitor For A Long Time
To Use the Monitor for a Long Time ● Maintenance • The display quality of monitors is affected by the quality level of input signals and the degradation of the product. • It takes about 30 minutes for the performance of electrical parts to stabilize. Please wait 30 minutes or more after the monitor power has been turned on or the monitor has recovered from the power saving mode, and then adjust the monitor. -
Page 9: Table Of Contents
Easy-to-touch Stand Mechanism (LaidBack Stand specification) ......10 ● 10-point Multi-touch Function ......10 1-2. Package Contents ........11 ● EIZO LCD Utility Disk ........11 1-3. Controls and Functions ......12 ● Front ...............12 ● Rear ..............13 Chapter 2 Installation / Connection ....14 2-1. -
Page 10: Chapter 1 Introduction
Chapter 1 Introduction Thank you very much for choosing an EIZO color LCD monitor. 1-1. Features ● Full-flat Design The full-flat design with no steps is adopted in the bezel part. You can securely touch up to each edge of the screen even with fingertips. -
Page 11: Package Contents
1-2. Package Contents Check that all of the following items are contained in the package. If any of these are missing, contact your dealer or local EIZO representative listed on the attached sheet. Note • It is recommended that the box and packing materials be stored so that they can be used to move or transport this product. -
Page 12: Front
1-3. Controls and Functions ● Front Setting menu Indicates the monitor’s operation status. Blue: Screen display 1. Power Indicator Orange: Power saving mode OFF: Main power off / Power off Switches the touch panel enable and disable modes, or calibrates the touch button sensitivity (page 19). -
Page 13: Rear
● Rear Turns the main power on or off. 8. Main power switch | : ON, ○ : OFF 9. Power connector Connects the power cord. 10. Touch pen holder attachment Used to attach a touch pen holder. (See page 17) hole 11. -
Page 14: Chapter 2 Installation / Connection
Chapter 2 Installation / Connection 2-1. Before Installing the Product Carefully read “PRECAUTIONS” (page 3) and always follow the instructions. Attention • If you place this product on a lacquer-coated desk, the color may adhere to the bottom of the stand due to the composition of the rubber. -
Page 15: Connecting Cables
2-2. Connecting Cables Attention • Check that the monitor and the PC are powered off. • When replacing the current monitor with this monitor, see “5-2. Compatible Resolutions” (page 22) to change the PC settings for resolution and vertical scan frequency to those that are available for this monitor, before connecting the PC. -
Page 16: Turning On The Power
Plug the power cord into a power outlet and the power connector on the monitor. Insert the power cord fully into the power connector on the monitor. Attention • For a two-core power outlet, use the two-core adapter supplied with the product, and be sure to ground the earth lead (green). -
Page 17: Adjusting The Angle
2-4. Adjusting the Angle Hold left and right edges of the monitor with both hands, and adjust the vertical angle to the best condition for working. 15° 70° 216.3 mm 401.3 mm Attention • After the adjustment is finished, make sure that the cables are correctly connected. 2-5. -
Page 18: Chapter 3 Touch Panel Settings
Chapter 3 Touch Panel Settings 3-1. Touch Panel Setup First connect the USB cable. After installation is completed, run sensitivity calibration software "TPOffset". TPOffset is included on the EIZO LCD Utility Disk (CD-ROM). Note • TPOffset can also be downloaded from the EIZO website. -
Page 19: Enabling Or Disabling The Touch Panel
3-3. Enabling or Disabling the Touch Panel You can switch the touch panel enable and disable modes. This function is available, for example, to temporarily disable the touch panel function. 3-4. Calibrating the Touch Sensitivity Holding down allows you to calibrate the touch sensitivity. This calibration is available when there is a problem with touch operation. -
Page 20: Chapter 4 No-Picture Problem
• Power indicator is flashing orange. • This problem may occur when a PC is connected via the DisplayPort connector. Connect via the signal cable specified by EIZO, turn off the monitor, and then turn it on again. 2. The message below appears. -
Page 21: Chapter 5 Specifications
Chapter 5 Specifications 5-1. Specifications List LCD Panel Type Backlight Size 58.4 cm (23.0 inch) Resolution 1920 dots × 1080 lines Display Size 509.2 mm × 286.4 mm (H x V) Pixel Pitch 0.265 mm Display Colors 8-bit color: 16.77 million colors Viewing Angles 178°... -
Page 22: Compatible Resolutions
Range Humidity 10 % to 92 % R.H. (no condensation) Air Pressure 200 hPa to 1060 hPa *1 EIZO support will end when OS vendor support ends. 5-2. Compatible Resolutions The monitor supports the following resolutions. ● Analog Input (D-Sub) -
Page 23: Medical Standard
Appendix Medical Standard • It shall be assured that the final system is in compliance to IEC60601-1-1 requirement. • Power supplied equipment can emit electromagnetic waves, that could influence, limit or result in malfunction of the monitor. Install the equipment in a controlled environment, where such effects are avoided. -
Page 24: Fcc Declaration Of Conformity
Note Use the attached specifi ed cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord... -
Page 25: Declaration Of Compliance With India Rohs
Declaration of compliance with India RoHS We, EIZO Corporation, hereby declare and guarantee that this product has been designed and manufactured in compliance with the E-Waste management rule 2016 which prohibit the inclusion of the following substances except for the exemptions listed in schedule II. -
Page 26: Emc Information
Be sure to use the cables attached to the product, or cables specified by EIZO. Use of cables other than those specified or provided by EIZO of this equipment could result in increased electromagnetic emissions or decreased electromagnetic immunity of this equipment and improper operation. - Page 27 Electromagnetic immunity The RadiForce series has been tested at the following compliance levels according to the testing requirements for profes- sional healthcare facility environments defined in IEC / EN60601-1-2. Customers and users of the RadiForce series must ensure that the RadiForce series is used in the following environments: Immunity test Test level for professional Compliance level...
- Page 28 Electromagnetic immunity The RadiForce series has been tested at the following compliance levels according to the testing requirements for profes- sional healthcare facility environments defined in IEC / EN60601-1-2. Customers and users of the RadiForce series must ensure that the RadiForce series is used in the following environments: Immunity test Test level for professional Compliance level...
- Page 29 Recommended separation distances between portable or mobile RF communication equipment and the RadiForce Series The RadiForce series is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the RadiForce series can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the RadiForce series.
- Page 30 Cable Length Signal cable: PP300 Signal cable: DD300 Signal cable: MD-C87 1.8 m USB cable: UU300 Audio cable: Shield 2.1 m Headphone cable: Shield Power cord (with earth) Appendix...
- Page 31 1 Queens Square, Ascot Business Park, Lyndhurst Road, Ascot, Berkshire, SL5 9FE, UK Moosacherstrasse 6, Au, CH-8820 Wädenswil, Switzerland 00N0N025F1 www.eizoglobal.com IFU-MS236WT-6 Copyright © 2017 - 2022 EIZO Corporation. All rights reserved. 6th Edition - June 28th, 2022 Printed in Japan.
