kozy heat Nordik 36DV Instruction Manual

Nordik 36DV
Please leave these reference guides at the installa on loca on un l the installa on is finished. See owners manual for full installa on and
finishing instruc ons before making final decisions as informa on is subject to change.
Specifica ons
(all measurements are in inches)
Model BTU
NDK-36 35,000
Framing Opening
E
A
B
C
Dimension NDK-36
A 36-5/8
B
40
C 19-1/2
72
D
4-1/4
E
Screen Front Barriers
Safety Barriers Group #1
Direct Vent Fireplace
Height
Actual Framing Actual
35-3/4
32 40
Typical Horizontal Installation
Double horizontal
header needed to
maintain combustibles.
D
Typical Vertical Installation
GAS LINE OPENING: RIGHT SIDE
•
Front Width Back Width
Framing Actual
36-5/8 22-1/4
F
G
H
I
F
G
H
Safety Barriers Group #2
• ELECTRICAL ACCESS: LEFT SIDE
Depth
Framing Actual Framing
36-5/8 19-1/2
19-1/2
Typical Corner Installation
Dimension
F
G
H
I
J
K
L
M
N
O
Safety Barriers #1 Approved for All Design Options
(Standard or Komfort Zone Kit Installations)
Safety Barriers #2 Approved for Komfort Zone Kit
Installations ONLY
IMPORTANT: The B36-PSF2 and B36-
FRSF2 (Figure 2.3) are ONLY
approved for use when the Nordik
36DV is installed with an approved
Komfort Zone Kit. The approved kits
are
#KZK-036 and #KZK-1510A.
Safety barriers group 1 shown in are
approved in all installation scenarios.
Glass Viewing
Area
32-5/8 x 26-7/8
O
N
M
K
J
L
NDK-36
1/2
19-1/2
36-5/8
8-3/4
62-3/4
36-5/8
44-1/2
1/2
30-7/8
14-1/4
8/23
