- Page 1 BZ-MVS8x8-4K 8x8 Seamless UHD Matrix Warning ⚫ Do not expose this device to Rain, Moisture, and Dripping ⚫ Only use accessories specified by the manufacture ⚫ Unplug this device during Lightning Storms ⚫ Product specifications may be subject to technical upgrades without further...
- Page 2 1. Introduction BZ-MVS8x8-4K is a seamless UHD matrix switcher with 8x HDMI inputs and 8x HDMI outputs. Audio extract or insert can also be enabled on this device. IR matrix routing on this video matrix is followed with video routing.
-
Page 3: Front Panel Control
2. Front Panel Control OUTPUT/INPUT buttons ⚫ Press buttons OUTPUT n + INPUT m+ TAKE by sequence, user can switch matrix routing Press button POWER, to make the matrix enter or release standby state. When standby, ⚫ the power LED will be lighted Press button LOCK, to lock or un-lock front buttons. -
Page 4: Back Panel
3. Back Panel LAN (10M/100M), RS232 are for PC control ⚫ Analog Audio IN/OUT ports are bond with corresponding HDMI ports. ⚫ For example, if INPUT HDMI 1 signal is DVI, matrix will use analog AUDIO IN 1 as HDMI 1 audio source Note, Analog AUDIO IN is only available when the corresponding video input is DVI signal. - Page 5 Relationship between video and IR routing IR extender connectors (not as accessories)
- Page 6 4. PC Tool and RS232/LAN Control 4.1 RS232 connector RS-232 control, baud rate 9600, DB9 connector ⚫ Pins configuration as bellow. User need use the corresponding cable, directly link cable ⚫ Index Tx( Matrix →PC ) Rx( Matrix ←PC ) Baud rate 9600 4.2 Ethernet control and connection Note：Factory default network setting：...
-
Page 7: Uart Control
4.3 PC Tool The PC tool needs no installation, support serial control and network control. Please note, Fine Tune/OSD CTRL/TV Wall pages are reserved for future used ⚫ 4.3.1 UART Control Control steps as follows: 1. Connect PC and device with a straight serial port cable 2. -
Page 8: Network Control
The UI after connected successfully will be as follows: ⚫ 4.3.2 Network Control Direct connection via Ethernet cable ⚫ Control steps as follows: 1. Connect the PC and device directly via an Ethernet cable 2. Manually setting up the IP address of the PC, and the IP address of the PC and the device should be in a same network segment (The default IP address of the device is 192.168.0.247, and the default network mask of the device is 255.255.255.0). - Page 9 Manually setting up the IP address of the PC 3. Run the PC control software (If the IP address of the PC changed after running the software, you should close it and run it again) 4. Click to switch "Ctrl Mode" to "Network" 5.
- Page 10 read the network configuration such as network port and so on of the device automatically) 7. Click the ‘Disconnected’ button (which is right to "Status") to connect to the device 8. If connected successfully, "Disconnected" button will show "Connected" The UI after connected successfully will be as follows: Connection via LAN ⚫...
- Page 11 3. Run the PC control software (If the IP address of the PC changed after running the software, you should close it and run it again) 4. Click to switch "Ctrl Mode" to "Network" 5. Click the "Search Device" button 6.
- Page 12 2. Configuration via Network Setp A: Switch to Ctrl Mode to "Network" page Setp B：Click the "Search Device" button to search devices Setp C：Click the device you want to configure in the result list (When you click it, the software will read the network configuration of the device automatically) Setp D：Modify the IP address or the IP address type or other configuration.
- Page 13 NOTE： 1. Select the device, will display the matrix's network board information. User can edit the device’s name, in order to better identify matrix. User can set dynamic IP/ static IP, subnet mask, gateway and other network information. At the same time, user can also set the device port.
-
Page 14: Matrix Switch
⚫ 4.3.4 Matrix Switch When the PC-tool connect to the matrix via UART or Network, the PC-tool will display the matrix’s input and output information. 1. User can click the mouse to switch the input; Can edit the input source name (for example, the user can edit the input 1 name to set-top box);... -
Page 15: Signal Setting
⚫ 4.3.5 Signal Setting Only the red field can be changed for different output resolution, others are only for read... -
Page 16: Edid Control
⚫ 4.3.6 EDID control Click the ‘EDID’button on "Matrix Switch" page, open EDID control Window 1. Read EDID： Select the output port, then click the "Read " button to read EDID 2. Write EDID： First read a EDID from output port，or open a EDID file that saved before，then select the input port，and click the "Write"... - Page 17 5. Control via Web If do not know the matrix IP address: Click on the Network Settings page, and then click ⚫ Search Device, and then select the device that found, click Open Website to open the web control web site, or can input the IP on the web browser , then enter the username: admin Password: admin, then can control the matrix switch function use the website;...
-
Page 18: Electrical Parameters
6. Electrical parameters Electrical parameter Interface HDMI-A HDMI /DP /VGA Version HDMI2.0, HDCP2.2 Bandwidth 18Gbps Video Resolution 800x600@60Hz,1024x768@60Hz, 1280x768@60Hz,1280x800@60Hz, 1280x1024@60Hz,1360x768@60Hz, 1366x768@60Hz,1400x1050@60Hz, Input 1440x900@60Hz,1600x1200@60Hz, 1680x1050@60Hz, 1920x1200@60Hz. 480p,576p,720p,1920x1080i,1920x1080p, 3840x2160@24Hz/25Hz/30Hz/50Hz/60Hz, 4096x2160@24Hz/25Hz/30Hz/50Hz/60Hz. Output 1920x1080@60Hz, 3840x2160@30Hz, 3840x2160@60Hz, 1280x720@60Hz, 1024x768@60Hz, 1360x768@60Hz, 1600x1200@60Hz, 1920x1200@60Hz, HDMI Amplitude T.M.D.S +/- 0.4Vpp Differential impedance 100±15ohm RS232/Ethernet control... -
Page 19: Package Contents
We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank. BZB Gear is the solution for small to medium-sized applications requiring the latest professional products in AV. -
Page 20: Warranty Information
9. Warranty Information BZB Gear | Second Year Assurance BZB Gear wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*.
